Page 1
Instructions Injecto-Flo II Single Line 313839C Pumps with No Control - For feeding volumetric dosing meters in a single-line system - - Not for use in hazardous locations - Part No.: See page 2 OIL: 435 psi (3.0 MPa, 30 bar) Maximum Working Pressure GREASE: 580 psi (4.0 MPa, 40 bar) Maximum Working Pressure Important Safety Instructions Read all warnings and instructions in this...
Page 2
Models Models Oil Systems Reservoir Flow Model Gal (liters) GPM (lpm) Level Switch Refill System ✓ 122545 0.8 (3.0) 0.05 (0.2) None Screw Cap ∅ ✓ 122546 0.8 (3.0) 0.05 (0.2) None Straight Connector ( 10 pipe) ✓ 122547 0.8 (3.0) 0.13 (0.5) None Screw Cap...
Page 4
Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risk. Refer back to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where applicable.
Warnings Grounding The equipment must be grounded. Grounding reduces the risk of static and electric shock by providing an escape wire for the electrical current due to static build up or in the event of a short circuit. Pressure Relief Procedure To relieve pressure, loosen outlet fitting connection to bleed air and relieve pressure.
Installation Installation Component Identification Doser Hydraulic Diagram Doser Key: Grease Models Tank Oil Models* Electric Motor (includes all items A - H and also the following) Gear Pump Electric Level Switch Suction Filter Pressure Limiting Valve Relief Valve Filling Cap-Filter Pressure Outlet 313839C...
Installation Refilling Options Oil Systems (F . 2) Grease Systems (F . 3) Screw Cap Option Elbow Connector Option Screw Cap Strainer Basket (Oil Models Only) Down Tube (Oil Models Only) Vent (additional information) Elbow Connector Vent (F . 4) NOTE: A vent is included with all units with refilling sys- tems using a connector (G).
Page 8
Installation Level Switch Connector Options Grease Systems Oil Systems Standard Connector Option: Minimal level with standard DIN connector; Minimum + Prealarm level with standard DIN connector. M12 Connector Top Entry Option: Minimum level with M12 connector top entry; Minimum + Premalarm level with M12 connector top entry.
Electrical Diagram Electrical Diagram MIN. MIN. PRE. Grease 313839C...
Page 10
Replacement Parts Available from Graco Replacement Parts Available from Graco Part No. Description Part No. Description 122921 SWITCH, min, prealarm level, w/din, 6L 122901 PUMP, electric motor, oil, 0.2L/min 122922 SWITCH, min level w/M12, 3L 122902 PUMP, electric motor, oil, 0.5L/min...
Technical Data Technical Data Tank Capacity Models: Oil ....... . . 0.8 - 1.6 gallons (3 - 6 liters) Models: Grease .
Page 12
Technical Data Dimensions 5.37 in. (136.5 mm) 11.3 in. (289 mm) 6 in. (152.5 mm) 8.6 & 9.0 in. 5.59 in (220 & 230 mm) (142 mm) 9.65 in. (245 mm) 313839C...
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
