Instructions
Injecto-Flo II Single Line
Pumps with No Control
- For feeding volumetric dosing meters in a single-line system -
Part No.: See page 2
OIL: 435 psi (3.0 MPa, 30 bar) Maximum Working Pressure
GREASE: 580 psi (4.0 MPa, 40 bar) Maximum Working Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
- Not for use in hazardous locations -
313839F
EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Graco Injecto-Flo II Single Line
Summary of Contents for Graco Injecto-Flo II Single Line
- Page 1 Instructions Injecto-Flo II Single Line 313839F Pumps with No Control - For feeding volumetric dosing meters in a single-line system - - Not for use in hazardous locations - Part No.: See page 2 OIL: 435 psi (3.0 MPa, 30 bar) Maximum Working Pressure GREASE: 580 psi (4.0 MPa, 40 bar) Maximum Working Pressure...
-
Page 2: Oil Systems
Models Models Oil Systems Reservoir Flow Model Gal (liters) GPM (lpm) Level Switch Refill System 122545 0.8 (3.0) 0.05 (0.2) None Screw Cap 122546 0.8 (3.0) 0.05 (0.2) None Straight Connector ( 10 pipe) 122547 0.8 (3.0) 0.13 (0.5) None Screw Cap... - Page 3 Models Reservoir Flow Model Gal (liters) GPM (lpm) Level Switch Refill System 122574 1.6 (6.0) 0.05 (0.2) Dual w/DIN Screw Cap 122575 1.6 (6.0) 0.05 (0.2) Dual w/DIN Straight Connector ( 10 pipe) 122576 1.6 (6.0) 0.13 (0.5) Dual w/DIN Screw Cap...
- Page 4 Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risk. Refer back to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where applicable.
-
Page 5: Pressure Relief Procedure
Warnings Grounding The equipment must be grounded. Grounding reduces the risk of static and electric shock by providing an escape wire for the electrical current due to static build up or in the event of a short circuit. Pressure Relief Procedure To relieve pressure, loosen outlet fitting connection to bleed air and relieve pressure. -
Page 6: Installation
Installation Installation Component Identification Hydraulic Diagram Key: Grease Models Tank Oil Models* Electric Motor (includes all items A - H and also the following) Gear Pump Electric Level Switch Suction Filter Pressure Limiting Valve Relief Valve Filling Cap-Filter Pressure Outlet 313839F... -
Page 7: Refilling Options
Installation Refilling Options Level Switch Connector Options 313839F... -
Page 8: Wiring Diagram
Installation Instructions The control of these units is external (without control) programming by the machine automatism or external control (CNC, Automatic device, etc.). It can be equipped with an electrical level (minimum level) control in the tank. Wiring Diagram Level Switch Function Diagrams 313839F... - Page 9 Parts Oil Parts Oil Part No. Description 122901 PUMP, electric motor, oil, 0.2L/min 122902 PUMP, electric motor, oil, 0.5L/min 122903 SWITCH, min level w/din, 3L 122904 SWITCH, min level w/din, 6L SWITCH, min, pre-alarm level, w/din, 122905 SWITCH, min, pre-alarm level, w/din, 122906 SWITCH, min level w/M12, top connec- 122907...
- Page 10 Parts Grease Parts Grease Parts Special Fluid Grease Part No. Description 122916 PUMP, electric motor, grease, 3L Part No. Description 122917 PUMP, electric motor, grease, 6L 122916 PUMP, electric motor, grease, 3L 122918 SWITCH, min level w/din, 3L 122917 PUMP, electric motor, grease, 6L 122919 SWITCH, min level w/din, 6L 122922 SWITCH, min level w/din, 3L 122920 SWITCH, min, M12, top connector, 3L...
- Page 11 Parts Special Fluid Grease Dimensions: 3 Liter Tanks 313839F...
- Page 12 Parts Special Fluid Grease Dimensions: 6 Liter Tanks 313839F...
-
Page 13: Technical Data
Technical Data Technical Data Tank Capacity Models: Oil ....... . . 0.8 - 1.6 gallons (3 - 6 liters) Models: Grease . -
Page 14: Graco Standard Warranty
