Campbell Hausfeld DG190300CK Operating Instructions And Parts Manual

Notes
Notes
Notas
DG190300CK
16
See Warranty on page 5 for important information about commercial use of this product.
Operating Instructions and Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain
the product described. Protect yourself and others by observing all safety information. Failure to comply with
instructions could result in personal injury and/or property damage! Retain instructions for future reference.
BUILT TO LAST

Description

The hand drill is made for drilling,
honing, reaming, hole sawing and wire
brushing. The drill operates at high
speed making the tool useful in drilling
metal and pilot holes to reduce wood
splitting when installing screws. The
keyless chuck provides fast and
convenient drill bit changes.

Unpacking

When unpacking this product,
carefully inspect for any damage that
may have occurred during transit.
General Safety
Information
This manual contains information that is
very important to know and understand.
This information is provided for SAFETY
WARNING
and to PREVENT EQUIPMENT PROBLEMS.
!
To help recognize this information,
power cord contains chemicals known
observe the following symbols.
to the State of California to cause
cancer and birth defects or other
Danger indicates
DANGER
!
reproductive harm. Wash hands after
an imminently
handling.
hazardous situation which, if not avoided,
will result in death or serious injury.
The following safety precautions must
Warning indicates be followed at all times along with any
WARNING
!
a potentially
other existing safety rules.
hazardous situation which, if not avoided,
1. Read all manuals
could result in death or serious injury.
included with this
Caution indicates a
CAUTION
!
potentially product carefully. Be
hazardous situation which, if not avoided,
thoroughly familiar
may result in minor or moderate injury.
with the controls and
Notice indicates
NOTICE the proper use of the equipment.
important
2. Only persons well acquainted with
information, that if not followed, may
cause damage to equipment.
these rules of safe operation should
be allowed to use this tool.
CALIFORNIA PROPOSITION 65
You can
DANGER
!
create WARNING
!
dust when you cut, sand, drill
glasses and ear protection
or grind materials such as
must be worn during
wood, paint, metal, concrete,
Operation.
cement, or other masonry.
This dust often contains chemicals
known to cause cancer, birth defects, or
other reproductive harm. Wear
protective gear.
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2006 Campbell Hausfeld/Scott Fetzer
For parts, product & service information
visit www.chpower.com
DG190300CKk
Hand Drill
3. Do not wear loose fitting clothing,
This product or its
scarves, or neck ties in work area.
Loose clothing may become caught
in moving parts and result in serious
personal injury.
4. Do not wear jewelry when
operating any tool. Jewelry may
become caught in moving parts and
result in serious personal injury.
5. Always use attachments designed
for use with this tool. Do not use
damaged or worn attachments.
MANUAL
6. Never trigger the tool when not
applied to a work object.
Attachments must be securely
attached. Loose attachments can
cause serious injury.
Specifications
Tool
Safety
Voltage 120V 60Hz
Power Rating 4 Amp
No Load Speed 0 - 2600 rpm
Chuck Size 3/8"
Max Bit Size 3/8"
IN713201AV 10/06
