SPYDER
Electric Pressure Washer
Assembly, Care and Use Instructions
SPY1800P
SPY1800PC
Read carefully. Retain these instructions and
attach receipt to manual for future reference.
IMPORTANT: NEVER use an extension cord with this
unit. It may cause damage to the motor and VOID the
warranty.
ALWAYS WEAR EYE PROTECTION TO
PREVENT INJURY TO EYES WHEN
OPERATING THE POWER WASHER.
Questions, problems, missing parts?
Before returning to your retailer, call our customer service department at 1-855-770-7529,
9:00 a.m. - 5:00 p.m., EST, Monday - Friday. www.powerplaypro.com
SPY1800P/PC-02
Advertisement
Table of Contents
Related Manuals for Powerplay SPYDER SPY1800P
Summary of Contents for Powerplay SPYDER SPY1800P
- Page 1 SPYDER Electric Pressure Washer Assembly, Care and Use Instructions SPY1800P SPY1800PC Read carefully. Retain these instructions and attach receipt to manual for future reference. IMPORTANT: NEVER use an extension cord with this unit. It may cause damage to the motor and VOID the warranty.
-
Page 2: Table Of Contents
Table of Contents Package Contents ..........................Product Specifications ........................Safety Information ..........................GFCI ..............................Preparation ............................Assembly Instructions........................Operating Instructions ........................Care and Maintenance ........................Troubleshooting ..........................One Year Limited Consumer Warranty ..................Replacement Parts List ........................ -
Page 3: Package Contents
Package Contents SPY1800PC SPY1800P O-Ring Part Description Quantity Part Description Quantity O-Ring Replacement Kit Upper Spray Gun Holder Lower Spray Gun Holder Hose Casters Spray Gun Power Washer Unit Spray Gun Safety Lock Hose Holder Lance Product Specifications Max PSI Max GPM Model (lbs/sq. -
Page 4: Safety Information
Safety Information Please read and understand this entire manual before • DO NOT use your power washer when you are under attempting to assemble, operate, or install the product. the influence of alcohol or drugs. Use this power tool carefully and only when you are alert. This manual contains information that relates to Watch your balance and footing while using your •... -
Page 5: Gfci
NEVER use lances or other parts that are not • • NEVER leave the power washer “ON” while it is compatible for this specific Powerplay unit. unattended. NEVER spray any electrical outlet with your power • •... -
Page 6: Preparation
Preparation Before beginning assembly of product, make sure all parts Estimated Assembly Time: 10 minutes are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, 855-770-7529 contact customer service at attempt DO NOT to assemble the product. - Page 7 Assembly Instructions Slide upper spray gun holder (A) tab into slot on left side of power washer unit (D). From below, slide lower spray gun holder (B) tabs into slots on bottom left side of power washer unit (D). Hold back the collar at one end of the end of the hose (G).
- Page 8 Assembly Instructions Hold back the collar at the other end of the hose (G). Push firmly to connect hose fitting to spray gun (H). Twist collar clockwise to secure. Confirm hose is locked into spray gun by slightly pulling on them. To remove the hose, twist collar counter clockwise then pull back to release the hose (G) connection from the spray gun (H).
- Page 9 Assembly Instructions Insert lance (J) into spray gun (H) and turn clockwise to tighten (DO NOT overtighten). Note: ALWAYS engage the safety lock (I) when changing lances ensure that they do not accidentally eject with force during removal. Attach a garden hose to the garden hose adapter on the back of the power washer unit (D).
-
Page 10: Operating Instructions
Operating Instructions Using High/Low Nozzle 1. Turn on water supply at the faucet. 2. Make sure the “ON/OFF” switch is in the “OFF” The spray pattern and intensity can be adjusted for each position. The power switch has international task by twisting the spray nozzle at the far end of the lance. symbols: On (|) Off (O). - Page 11 Operating Instructions Operation Tips • When using detergent, fill bottle with a properly formulated detergent-to-water ratio, following instructions on the container. • DO NOT use thick, gel-like detergents, as they will clog the power washer and can cause damage. • It is normal to hear the motor run intermittently when the trigger is not being squeezed.
-
Page 12: Care And Maintenance
Care and Maintenance Cleaning Nozzles Storage A clogged or partially clogged nozzle can cause significant 1. When the pressure washing session is complete, turn reduction of water pressure coming out of the nozzle off the power switch. and/or cause the unit to pulsate while spraying. 2. -
Page 13: Troubleshooting
Troubleshooting If you have any questions regarding the product, please call customer service at 1-855-770-7529. Problem Corrective Action Unit will not turn on. 1. Make sure the power washer is OFF. Plug the electrical cord into a grounded 120 volt outlet (no electrical extension cord should be used). -
Page 14: One Year Limited Consumer Warranty
Warranty The one year limited consumer warranty of this product is covered by Powerplay Corporation. This product has a 1 (one) year limited consumer warranty. Please read the following carefully to understand what the warranty entails: This product is under warranty to the original retail consumer against defects in material and workmanship for a period 1(one) year. -
Page 15: Replacement Parts List
Replacement Parts 1-855-770-7529. For replacement parts, call our customer service department at 9:00 a.m. - 5:00 p.m., EST, Monday - Friday or order online at www.powerplaypro.com. SPY1800P O-Ring Part Description Part # Part Description Part # Lance PWXA023 Caster PWXA093 GFCI Assembly PWXA092 Hose Holder...
