Powerplay SPYDER Assembly, Care And Use Instructions

Electric pressure washer
Hide thumbs Also See for SPYDER:

Advertisement

Table of Contents

SPYDER
Electric Pressure Washer
Assembly, Care and Use Instructions
SPY203COS
Read carefully. Retain these instructions and
attach receipt to manual for future reference.
IMPORTANT: NEVER use an extension cord with this
unit. It may cause damage to the motor and VOID the
warranty.
ALWAYS WEAR EYE PROTECTION TO
PREVENT INJURY TO EYES WHEN
OPERATING THE POWER WASHER.
Questions, problems, missing parts?
Before returning to your retailer, call our customer service department at 1-855-770-7529,
9:00 a.m. - 5:00 p.m., EST, Monday - Friday. www.powerplaypro.com
SPY203COS-07 REV. 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPYDER and is the answer not in the manual?

Questions and answers

Cathie Wauchope
May 29, 2025

Hello, Regarding the purchase of part PWXA013 for poweplay spyder 2000 Can I purchase at any box store? What is the cost? Thx

0

Subscribe to Our Youtube Channel

Related Manuals for Powerplay SPYDER

Summary of Contents for Powerplay SPYDER

  • Page 1 SPYDER Electric Pressure Washer Assembly, Care and Use Instructions SPY203COS Read carefully. Retain these instructions and attach receipt to manual for future reference. IMPORTANT: NEVER use an extension cord with this unit. It may cause damage to the motor and VOID the warranty.

  • Page 2: Table Of Contents

    Table of Contents Package Contents ..........................Product Specifications ........................Safety Information ..........................Preparation ............................Assembly Instructions........................Important Initial Startup ......................... Operating Instructions ........................Care and Maintenance ........................Troubleshooting ..........................One Year Limited Consumer Warranty ..................Replacement Parts List ........................

  • Page 3: Package Contents

    Package Contents O-Ring Soap – Black 0˚ – Red 15˚ – Yellow 25˚ – Green Part Description Quantity Part Description Quantity Upper Spray Gun Holder Hose Spray Gun Lower Spray Gun Holder Spray Gun Safety Lock Casters Lance Power Washer Unit Hose Holder Spray Tips O-Ring Replacement Kit...

  • Page 4: Safety Information

    Safety Information Please read and understand this entire manual before • DO NOT use your power washer when you are under attempting to assemble, operate, or install the product. the influence of alcohol or drugs. Use this power tool carefully and only when you are alert. This manual contains information that relates to Watch your balance and footing while using your •...

  • Page 5: Preparation

    • NEVER use lances or other parts that are not NEVER leave the power washer “ON” while it is compatible for this specific Powerplay unit. • unattended. • NEVER spray any electrical outlet with your power ALWAYS turn the water supply “ON ”...

  • Page 6: Assembly Instructions

    Assembly Instructions Slide caster (C) tab into slot on bottom corner of power washer unit (D). Repeat for the remaining casters. Slide hose holder (E) onto tab on the right side of power washer unit (D). Slide foam cannon bracket (M) onto tab on back of power washer unit (D).
  • Page 7 Assembly Instructions Slide upper spray gun holder (A) tab into slot on left side of power washer unit (D). From below, slide lower spray gun holder (B) tabs into slots on bottom left side of power washer unit (D). Hold back the collar at one end of the end of the hose (G).
  • Page 8 Assembly Instructions Hold back the collar at the other end of the hose (G). Push firmly to connect hose fitting to spray gun (H). Twist collar clockwise to secure. Confirm hose is locked into spray gun by slightly pulling on them. To remove the hose, twist collar counter clockwise then pull back to release the hose (G) connection from the spray gun (H).
  • Page 9 Assembly Instructions Insert lance (J) into spray gun (H) and turn clockwise to tighten (DO NOT overtighten). Note: ALWAYS engage the safety lock (I) when changing lances and spray tips to ensure that they do not accidentally eject with force during removal. Attach spray tips (K) or foam cannon (L) into end of lance (J) by pressing selected tip into place.

  • Page 10: Important Initial Startup

    Assembly Instructions Attach a garden hose to the garden hose adapter on the back of the power washer unit (D). Note: Flush out garden hose before connecting to garden hose adapter. Assembly is now complete. Read and observe all safety instructions before turning on the power washer.
  • Page 11 Operating Instructions Operation Tips Using the Foam Cannon • When using detergent, fill bottle with a properly 1. Unscrew fluid tank from foam cannon valve assembly. formulated detergent-to-water ratio, following 2. Fill fluid tank with water (for best results, use warm instructions on the container.

  • Page 12: Care And Maintenance

    Care and Maintenance Detergents Cleaning Spray Tips • Use detergents designed for power washers. Hardware A clogged spray tip can significantly reduce water stores or home centers may offer detergents for pressure and/or cause the unit to pulsate while spraying. different cleaning projects.
  • Page 13 Care and Maintenance Storage 1. When the pressure washing session is complete, turn off the power switch. 2. Unplug the power cord from the outlet. 3. Turn off the water supply. Pull the trigger on the spray gun 2-3 times to drain out excess water and to release any remaining water pressure.

  • Page 14: Troubleshooting

    Troubleshooting If you have any questions regarding the product, please call customer service at 1-855-770-7529. Problem Corrective Action Unit will not turn on. 1. Make sure the power washer is OFF. Plug the electrical cord into a grounded 120 volt outlet (no electrical extension cord should be used).

  • Page 15: One Year Limited Consumer Warranty

    Warranty The one year limited consumer warranty of this product is covered by Powerplay Corporation. This product has a 1 (one) year limited consumer warranty. Please read the following carefully to understand what the warranty entails: This product is under warranty to the original retail consumer against defects in material and workmanship for a period 1(one) year.

  • Page 16: Replacement Parts List

    Replacement Parts 1-855-770-7529. For replacement parts, call our customer service department at 9:00 a.m. - 5:00 p.m., EST, Monday - Friday or order online at www.powerplaypro.com. Soap – Black 0˚ – Red 15˚ – Yellow 25˚ – Green O-Ring Part Description Part # Part...
