- Page 1 COMMERCIAL SERIES TUBULAR RACK SYSTEM INSTALLATION & MAINTENANCE WARNING PROTECT EYES FROM UV LIGHT TURN OFF UNIT OR DISCONNECT BEFORE SERVICING...
-
Page 2: Installation And Maintenance
TUBULAR RACK SYSTEM INSTALLATION & MAINTENANCE The Fresh-Aire UV® Tubular Rack System is designed for installation into commercial air handling units for the purpose of surface or airborne disinfection using ultraviolet germicidal irradiation. For maximum installation flexibility and cost-effectiveness the UV lamps are mounted onto a framework of standard 0.5”... -
Page 3: System Configuration
• The distance between end to end UV lamps should not exceed 12” • The distance of UV lamp ends to the edge of irradiated surface should not exceed 6” Coil Fresh-Aire UV offers a free system configuration consultation service for commercial projects. Contact Fresh-Aire UV for details. 12” Lamp to Coil 3. - Page 4 Assemble Conduit Framework 2. Mount L-bracket and Tubing 1. Measure and cut tubing to length then slide on conduit/ lamp clamps (do not fully tighten bolts yet). 1. Slide On Hardware Conduit 1a. Optional UV Shield 3. Optional 12” Stand-off Conduit 3a.
- Page 5 Install UV Lamps Snap UV Lamps into the Lamp/conduit Clamps. Be sure to clamp to the rubber lamp connector on one end and the ceramic lamp tip on the other end. DO NOT clamp onto the lamp glass. Use Black Nylon Zip-Ties to secure lamp cables to Tubular Rack components and/or supports.
-
Page 6: Sight Glass Installation
32” 1 Year Lamp Lamp Replacement Part# TUVCL-232HO 32” 2 Year Lamp - High Output Fresh-Aire UV® lamps are rated for either one or two years Part# TUVCL-232-TF 32” 2 Year Lamp - Teflon® germicidal effectiveness. The lamps will continue to glow Part# TUVCL-146 46”... - Page 7 Lifetime of the equipment. How Long Does The Coverage Last? 1) Fresh-Aire UV Power Supply: For as long as you own the real property where the product is installed. 2) TUVCL-1XX Series Ultraviolet Lamp is warranted for germicidal output for one-year from the date of installation.
