Fresh-Aire UV Commercial Series Installation & Maintenance

PROTECT EYES FROM UV LIGHT
TURN OFF UNIT OR DISCONNECT
A
B
D

Parts Included

TUVCL-246-TF
UV Lamp (
A
Lamp Cable
B
Lamp Mounting Bracket
C
Power Supply
D
In-Line Fuse
E
Safety Interlock Switch
F
Hex Bolt 3/8" - 16 x 1.000
G
Spring Locking Washer 3/8"
H
Hex Nut 3/8" - 16
I
Hex Head Self Tapping Screw 1/4"-14 x .875
J
Hex Head Self Tapping Screw #8-18 x .750
K
Flat Head Self Tapping Screw #6-20 x .500
L
Panel Mount Bushing
M
Washer Flat 3/8"
N
Zip Tie
O
Adhesive Zip Tie Mount
P
Sight Glass 1"
Q
COMMERCIAL SERIES
UV LIGHT BUS KIT
The Fresh-Aire UV Bus Kit is designed to reduce biological fouling of a/c coils and
blowers in commercial buses. Germicidal UV light improves indoor air quality and
reduces maintenance costs by keeping coils clean. CX model buses have two a/c
systems and will require two Fresh-Aire UV Bus Kits, one for each system.
WARNING
BEFORE SERVICING
E
)
G
J
N
• Only qualified technicians should install this product*
• Read instructions carefully including safety warnings
H
K L
O
Q
Installation
& MAINTENANCE
