Ag Leader Technology
NOTE: Indented items indicate parts
Instruction Kit – Case 2055
Arm Assy (18in rod, S-hook, 16 in. chain, spring)
Header Sensor – Standard
Cable Kit – Case 2055
Header Extension Cable – 18 in.
Sensor Distribution Cable – Case Monitor 2 Rows
Cotton Distribution Cable – 8 in.
Cotton F/G/P Cable – 4 ft
Cotton Cab Cable – Case 2055
Cable Inst. Kit – Cotton 2055
Drill Bit – Steel – 1/4 in.
Hole Saw – 1-3/8 in.
Silicone Rubber Adhesive Sealant – Black – 2.8 oz.
Fuse – Blade – 20 amp
Alcohol Swab Pack
Grey Plastic Cable Clamps
Cable Tie – 15 in. – Black
Cable Tie – 6 in. – Black
Adhesive Mounting Base – 2 way
Grommet – Rubber – 3/4 in. ID X1-3/8 in. PHD
Parts Kit Cotton – Case 2055
Header Sensor Inst. Kit – Generic, Case
Transfer Punch – 11/32 in.
File – Square – 5/16 in.
File Handle
Monitor Bracket Inst. Kit
Drill Bit – Tin Coated – 13/64 in.
Hex Hd Capscrew, Coarse Thd, Gr 5, ZP 1/4 x 3/4 in.
Hex Nut, Coarse Thd, ZP 1/4 in.
Split Lockwasher, ZP 1/4 in.
Flat Washer, Standard, ZP 1/4 in.
Self Tapping Hex Slotted Hd Screw, Coarse Thd, Gr 5, 1/4 x 3/4 in.
Fastener Kit – (1/2 in, 35 pcs)
Pen – Black – Permanent – Fine
Post Bracket
Hood Adapter Assembly 2055 Outer Double
included in an assembly
Part name/Description
November 2002
Parts List for Cotton Picker
CaseIH 2055
Part No.
2006200-1
2000311-2
20003221-1
2001238
2000453-1
2100006-1
2100007-1
2100008-1
2100010-1
2000901-20
2001001-25
2001002-138
2001011
2001012
2002811
2002812
2002817-15
2002817-6
2002821-2
2002824-75
2001336-1
2000330-4
2001003-34
2001006
2001019
2001304-9
2001000-20
2002001-25075
2002051-25
2002061-25
2002071-25
2002075-25075
2001337-1
2002813
3000693
3000273
Quantity
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
5
10
15
5
1
1
1
1
1
1
1
2
2
2
4
4
1
1
1
2
8-1
Advertisement
Related Manuals for Ag Leader Technology CaseIH 2055
Summary of Contents for Ag Leader Technology CaseIH 2055
- Page 1 Parts List for Cotton Picker Ag Leader Technology CaseIH 2055 NOTE: Indented items indicate parts included in an assembly Part name/Description Part No. Quantity Instruction Kit – Case 2055 2006200-1 Arm Assy (18in rod, S-hook, 16 in. chain, spring) 2000311-2 Header Sensor –...
- Page 2 Parts List for Cotton Picker Ag Leader Technology CaseIH 2055 NOTE: Indented items indicate parts included in an assembly Part name/Description Part No. Quantity Emitter Assembly – 5 Position 3000287 Serrated Flange Nut – SS, BZP, 1/4 in.-20 2002249-25 Emitter Sensor Assembly, 5 Lens 3000219 Sensor Plate –...
- Page 3 You will save time and prevent wrong installation of components by closely following these step-by-step instructions. If you have any questions call Ag Leader Technology at 515-232-5363. Signal words (CAUTION, IMPORTANT and NOTE) are provided to draw attention to information that is important for the safe/correct installation and operation of this product.
- Page 4 Parts List for Cotton Picker Ag Leader Technology CaseIH 2055 Parts required for this procedure: Installing Monitor in Cab • Monitor Unit • Post Bracket • U-Bracket • Screw-mount cable-tie base, mounting screw and cable ties. • Monitor Bracket Install Kit (screws, bolts, washers and nuts) Step-by-Step 1.
- Page 5 Cotton Picker Installation Ag Leader Technology CaseIH 2055 Figure 2: Bracket Mounting Location (with mirror) 3. Using the post bracket as a template, mark the two mounting holes on the cab post. A third hole can be drilled through the bracket and post for additional support.
- Page 6 Parts List for Cotton Picker Ag Leader Technology CaseIH 2055 Center punch and drill the mounting holes with the provided 13/64 inch drill bit. 5. Attach the post bracket to the cab post with three 1/4x3/4 inch self- tapping screws.
- Page 7 Cotton Picker Installation Ag Leader Technology CaseIH 2055 Parts required for this procedure: Installing Cab and Distribution • Distribution Cable Cables • Cab Cable Step-by-Step 1. Remove the interior panel at the front of the right hand console secured by three wing nuts.
- Page 8 Cotton Picker Installation Ag Leader Technology CaseIH 2055 7. Cable clamps may be used to secure the cable to the window. 8. From the exterior access panel, route the 24-pin connector end of the cab cable towards the back wall of the cab.
- Page 9 Cotton Picker Installation Ag Leader Technology CaseIH 2055 Attaching location for pigtail. Figure 7. Junction Block 13. Seal the area around the grommet with the provided black silicone sealant as needed. 14. At the junction block on the bottom left of the back cab wall, attach the long pigtail with ring connector and 5-amp fuse to either terminal of the junction box.
- Page 10 Cotton Picker Installation Ag Leader Technology CaseIH 2055 Parts required for this procedure: Installing Switched Power, • Switched power, Fan Speed, Ground Speed (FGP) cable (identified by a 9-pin Fan Speed, tee connector on one end and a 4-pin shroud on the other end)
- Page 11 Cotton Picker Installation Ag Leader Technology CaseIH 2055 FGP Cable Figure 9. FGP cable attached to cab cable. Parts required for this procedure: Installing GPS Coax Cable • 10 ft coax cable used inside the cab • 15 ft coax cable used to connect the antenna to bulkhead connector •...
- Page 12 Cotton Picker Installation Ag Leader Technology CaseIH 2055 Bulkhead Connector Figure 10. GPS bulkhead connector installed. 2. Position the 10-ft coax so the right angle connector attaches to the monitor and the other end attaches to the bulkhead connector. Attach 10-ft coax cable.
- Page 13 Cotton Picker Installation Ag Leader Technology CaseIH 2055 Part required for this procedure: Installing Hood Adapters • Sensor Install Kit • 9/32 in. drill bit • Electric drill or hand punch Step-by-Step 1. Remove the double outer hoods from the picker by loosening the four nuts holding the hood and chute together.
- Page 14 Cotton Picker Installation Ag Leader Technology CaseIH 2055 4. Use a saber saw, plasma cutter or any good cutting device to cut along the inside of the marks. 5. Use a file to remove burrs and rough edges. 6. Place the hood adapter flanges inside the hood. Mark the 14 hole positions on hood.
- Page 15 Cotton Picker Installation Ag Leader Technology CaseIH 2055 8. Attach the hood adapter to the hood using the flange nuts and truss head bolts provided. NOTE: The flange nuts should be on the outside of the hood so it doesn’t protrude into the flow of the cotton.
- Page 16 Cotton Picker Installation Ag Leader Technology CaseIH 2055 Parts required for this procedure: Installing Flow Sensors and • Four, 5 Position Emitters Sensor Cable • Four, 5 Position Detectors • Sensor Distribution Cable • Installation Kit Emitter – sensor block that is thicker and has a right angle connector coming out of Description the top cover with a two foot long cable.
- Page 17 Cotton Picker Installation Ag Leader Technology CaseIH 2055 3. Start routing the sensor distribution cable at the right side of the picker. Ensure to get the correct end of the cable. It has an extended cable with the AMP CP14 pin, which will run to the main distribution cable on the backside of the cab.
-
Page 18: Drill Bit
Cotton Picker Installation Ag Leader Technology CaseIH 2055 Parts required for this procedure: Installing Header Sensor • Header Sensor • Threaded Arm Assembly • Drill bit Step-by-Step 1. Attach threaded rod assembly to sensor pivot on the header sensor. Procedure 2. - Page 19 Cotton Picker Installation Ag Leader Technology CaseIH 2055 Mounting Holes Figure 16. Header Sensor mounting holes. 5. Attach header sensor with two 5/16 x 1-inch hex head cap screws. 6. Attach S-hook to existing bolt on the back of the center picking unit. See Figure 17.
-
Page 20: Final Inspection
Cotton Picker Installation Ag Leader Technology CaseIH 2055 Figure 18. Header Sensor installed. 7. Connect header sensor cable to distribution cable. Tie up extra cable away from moving parts. 8. You will have to use the 18-inch header extension cable to reach the distribution cable properly. - Page 21 Cotton Picker Installation Ag Leader Technology CaseIH 2055 Refer to the Display Items section in the Operation Section for Operational instructions on how to display different items on the screen. Checkout Step-by-Step 1. Start engine. Procedure 2. Verify the monitor powers up/down properly.
- Page 22 Cotton Picker Installation Ag Leader Technology CaseIH 2055 NOTE: RPM may NOT be accurate, because fan pulses/revolution have not yet been set for your machine. 4. Display "Ground Speed" on the screen. Move the machine slowly to verify the monitor measures MPH at low speeds (below 1 mph).
- Page 23 Record of Changes Ag Leader Technology CaseIH 2055 Installation Summary of Changes Revision 1 April 2001 Changed the monitor mount procedure, added the Operational Checkout and corrected typographical errors. Revision 2 November 2002 Changes to include the PFadvantage. November 2002...
