Ag Leader Technology
NOTE: Indented items indicate parts
Instruction Kit – Case 1822,1844,2022, 2044
Arm Assy (18in rod, S-hook, 16 in. chain, spring)
Header Sensor – Standard
Cable Kit – Case 2055
Header Extension Cable – 18 in.
Sensor Distribution Cable – Case Monitor 2 Rows
Cotton Distribution Cable – 8 in.
Cotton F/G/P Cable – 4 ft
Cotton Cab Cable – Case 2055
Cable Inst. Kit – Cotton 2055
Drill Bit – Steel – 1/4 in.
Hole Saw – 1-3/8 in.
Silicone Rubber Adhesive Sealant – Black – 2.8 oz.
Fuse – Blade – 20 amp
Alcohol Swab Pack
Grey Plastic Cable Clamps
Cable Tie – 15 in. – Black
Cable Tie – 6 in. – Black
Adhesive Mounting Base – 2 way
Grommet – Rubber – 3/4 in. ID X1-3/8 in. PHD
Parts Kit Cotton – Case 2055
Header Sensor Inst. Kit – Generic, Case
Sensor Install Kit – Case
File – Square – 5/16 in.
File Handle
Serrated Flange Nut – SS, BZP, 1/4 in.-20
Truss head Slotted, SS, BZP, 1/4 in.-20 x 1/2 in.
Pen – Black – Fine
Monitor Bracket Inst. Kit
Drill Bit – Tin Coated – 13/64 in.
Hex Hd Capscrew, Coarse Thd, Gr 5, ZP 1/4 x 3/4 in.
Hex Nut, Coarse Thd, ZP 1/4 in.
Split Lockwasher, ZP 1/4 in.
Flat Washer, Standard, ZP 1/4 in.
Self Tapping Hex Slotted Hd Screw, Coarse Thd, Gr 5, 1/4 x 3/4 in.
Post Bracket
Hood Adapter Assembly 2055 Outer Double
included in an assembly
Part name/Description
November 2002
Parts List for Cotton Picker
CaseIH 1822, 1844, 2022, 2044
Part No.
2006200-4
2000311-2
20003221-1
2001238
2000453-1
2100006-1
2100007-1
2100008-1
2100010-1
2000901-20
2001001-25
2001002-138
2001011
2001012
2002811
2002812
2002817-15
2002817-6
2002821-2
2002824-75
2001336-1
2000330-4
2001337-1
2001006
2001019
2002249-25
2002250-25050
2002813
2001304-9
2001000-20
2002001-25075
2002051-25
2002061-25
2002071-25
2002075-25075
3000693
3000273
Quantity
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
5
10
15
5
1
1
1
1
1
1
30
30
1
1
1
2
2
2
4
4
1
2
8-1
Advertisement
Related Manuals for Ag Leader Technology CaseIH 1822
Summary of Contents for Ag Leader Technology CaseIH 1822
- Page 1 Parts List for Cotton Picker Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 NOTE: Indented items indicate parts included in an assembly Part name/Description Part No. Quantity Instruction Kit – Case 1822,1844,2022, 2044 2006200-4 Arm Assy (18in rod, S-hook, 16 in. chain, spring) 2000311-2 Header Sensor –...
- Page 2 Parts List for Cotton Picker Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 NOTE: Indented items indicate parts included in an assembly Part name/Description Part No. Quantity Emitter Assembly – 5 Position 3000287 Serrated Flange Nut – SS, BZP, 1/4 in.-20...
- Page 3 You will save time and prevent wrong installation of components by closely following these step-by-step instructions. If you have any questions call Ag Leader Technology at 515-232-5363. Signal words (CAUTION, IMPORTANT and NOTE) are provided to draw attention to information that is important for the safe/correct installation and operation of this product.
- Page 4 Parts List for Cotton Picker Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Parts required for this procedure: Installing Monitor in Cab • Monitor Unit • Post Bracket • U-Bracket • Screw-mount cable-tie base, mounting screw and cable ties. • Monitor Bracket Install Kit (screws, bolts, washers and nuts) Step-by-Step 1.
- Page 5 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Figure 2: Bracket Mounting Location (with mirror) 3. Using the post bracket as a template, mark the two mounting holes on the cab post. A third hole can be drilled through the bracket and post for additional support.
- Page 6 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Center punch and drill the mounting holes with the provided 13/64 inch drill bit. 5. Attach the post bracket to the cab post with three 1/4x3/4 inch self- tapping screws.
- Page 7 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Parts required for this procedure: Installing Cab and Distribution • Distribution Cable Cables • Cab Cable Step-by-Step 1. Remove the interior panel at the front of the right hand console secured by three wing nuts.
- Page 8 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 7. Cable clamps may be used to secure the cable to the window. 8. From the exterior access panel, route the 24-pin connector end of the cab cable towards the back wall of the cab.
- Page 9 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Attaching location for pigtail. Figure 7. Junction Block 13. Seal the area around the grommet with the provided black silicone sealant as needed. 14. At the junction block on the bottom left of the back cab wall, attach the long pigtail with ring connector and 5-amp fuse to either terminal of the junction box.
- Page 10 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Parts required for this procedure: Installing Switched Power, • Switched power, Fan Speed, Ground Speed (FGP) cable (identified by a 9-pin Fan Speed, tee connector on one end and a 4-pin shroud on the other end)
- Page 11 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 FGP Cable Figure 9. FGP cable attached to cab cable. Parts required for this procedure: Installing GPS Coax Cable • 10 ft coax cable used inside the cab • 15 ft coax cable used to connect the antenna to bulkhead connector •...
- Page 12 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Bulkhead Connector Figure 10. GPS bulkhead connector installed. 2. Position the 10-ft coax so the right angle connector attaches to the monitor and the other end attaches to the bulkhead connector. Attach 10-ft coax cable.
- Page 13 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 1. Remove the specified chute or chute extension from the picker. This will make Cotton Flow it easier to work on each chute. Sensor Overview 2. Positioning of the sensors depends on if you are attaching to the chute extensions, main chute or on the ladder ducts.
- Page 14 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Step-by-Step 1. Remove chutes from the machine and take to your workshop. Procedure 2. On a chute extension center the sensor bracket on the chute. See Figure 13. 3. On a main chute of a 1822/1844 measure down 18 inches from the top on the front and back of chute.
- Page 15 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Chute Extension Figure 12. Model 2022 Chute Extension 4. Use the sensor bracket as a template to mark the opening and holes. See Figure IMPORTANT: Ensure this is done first to the front side of the chute since you will mount the emitter to the front side first.
- Page 16 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 7. Center punch and drill the hole marks with a 9/32 inch drill bit. Use a rat-tail file to remove any burrs. 8. On the chute extension attach the brackets using the flange nuts and truss head bolts provided.
- Page 17 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 10. Once the shims (if used) are in place and the mounting plate is securely fastened to the front side of the duct, attach the hinged template to the mounting plate as seen in Figure 15.
- Page 18 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Figure 15. Attaching template to mounting plate. Mounting Plate U-shaped Template Figure 16. U-shaped template and Mounting Plate 9-16 November 2002 2006200-4...
- Page 19 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 13. Mark the holes and rectangular hole from the template. Remove the mounting plate and template from the chute. 14. Center-punch and drill the holes. 15. Use a suitable cutting device and cut the center rectangular hole.
- Page 20 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 1. Position the sensor and bracket on the chute between the ladder rungs. (See Installing Sensors Figure 18) If there is a chute extension attach the sensor to the extension.
- Page 21 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 2. Rotate the sensor down to ensure the sensor will clear the ladder rungs. IMPORTANT: Before proceeding with this procedure, ensure there is no obstruction that would have to be mounted around in front or behind the chute.
- Page 22 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 12. Center punch and drill the hole marks with a 9/32 inch drill bit. Use a rat-tail file to remove any burrs. 13. Securely fasten the mounting plate using six 1/4 x 3/4 inch truss head screws and six serrated flange nuts.
- Page 23 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Figure 19. Attaching template strap to 2 mounting plate. Figure 20. Attaching template to mounting plate. November 2002 2006200-4 9-21...
- Page 24 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 19. Use a suitable cutting device and remove the 10-inch portion of ladder support marked in Step 4. (See Figure 21.) 20. Before reinstalling the chutes, double check your installation to ensure there is nothing that cotton will catch on.
- Page 25 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Parts required for this procedure: Installing Flow Sensors and • Four, 5 Position Emitters Sensor Cable • Four, 5 Position Detectors • Sensor Distribution Cable • Installation Kit Emitter – sensor block that is thicker and has a right angle connector coming out of Description the top cover with a two foot long cable.
- Page 26 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 3. Start routing the sensor distribution cable at the right side of the picker. Ensure to get the correct end of the cable. It has an extended cable with the AMP CP14 pin, which will run to the main distribution cable on the backside of the cab.
-
Page 27: Drill Bit
Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Parts required for this procedure: Installing Header Sensor • Header Sensor • Threaded Arm Assembly • Drill bit Step-by-Step 1. Attach threaded rod assembly to sensor pivot on the header sensor. - Page 28 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Mounting Holes Figure 25. Header Sensor mounting holes. 5. Attach header sensor with two 5/16 x 1-inch hex head cap screws. 6. Attach S-hook to existing bolt on the back of the center picking unit. See Figure 26.
- Page 29 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Figure 27. Header Sensor installed. 7. Connect header sensor cable to distribution cable. Tie up extra cable away from moving parts. 8. You will have to use the 18-inch header extension cable to reach the distribution cable properly.
- Page 30 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Installation is now complete. Do a walk around of the machine and Final Inspection complete the following: • All cable connections have been made. • Excess cable has been tied out of the way, so there is no potential interference.
- Page 31 Cotton Picker Installation Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 3. Display “Fan Speed” on the screen. 3a. Verify that Fan RPM stays at zero with the Fan OFF. 3b. Engage the fan and verify the monitor measures fan RPM.
-
Page 33: Record Of Changes
Record of Changes Ag Leader Technology CaseIH 1822, 1844, 2022, 2044 Installation Summary of Changes Revision 1 May 2001 Initial release of this set of instructions. Revision 2 November 2002 Changes to include the PFadvantage. 9-30 November 2002 2006200-4...
