- Page 1 2300 HPS Owner’s Manual Revised May 2020 Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631...
- Page 2 Thank you for choosing a Pathfinder boat to transport you to your angling dreams. We believe the Pathfinder 2300 HPS is the best all-purpose boat on the market, and we’re sure that you’ll be completely satisfied with the unmatched performance, quality and fishability of your new boat.
-
Page 3: Table Of Contents
Self-Bailing Cockpit & Livewell ......................16 Wiring ................................. 17 Standard Features ..........................19 Optional Features ..........................23 2300 HPS Optional Trolling Motor ....................... 24 2300 HPS Reinforcements ........................25 Upholstery Care & Cleaning Guide ..................26 Warranty ..............................27 Maverick Boat Group 3207 Industrial 29th St. -
Page 4: 2300 Hps Specifications
2300 HPS Specifications L.O.A........................23’ 06” BEAM..............………………….…....8’ 04” DRAFT..........................12” WEIGHT W/ ENGINE..................3,075 LBS. FUEL CAPACITY....................61 GAL. MAXIMUM H.P......................300 MAX CAPACITIES…………………………………..…...…….…8 PERSONS OR 1,500 LBS. Cooler with Leaning Seat Cushion Post Locking Rod Rigging Anchor Locker Storage Access Forward Storage Fuel Fill... -
Page 5: Pre-Operation Checklist
Pre-Operation Checklist We recommend you print this document and store it at the helm station. Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 6: Maintenance & Cleaning
Maintenance & Cleaning Maintenance Pathfinder advises owners that maintenance and repairs should be performed at an authorized Pathfinder Dealer. The following information is general in nature and should not be considered a repair manual or guidelines set forth by Maverick Boat Group. -
Page 7: Engine Break-In Period
DO NOT operate the boat if the engine stop switch system does not function properly. Go to a Pathfinder Dealer to have this resolved immediately. The lanyard should be securely attached to the boat operator at all times that the engine is on. -
Page 8: Switch Panel & Helm
Helm & Switch Panel Gauges The instrument panel on your Pathfinder 2300 HPS is composed of one Yamaha digital gauge and a series of dual activation switches. The switches come with accessory plug- ins for wiring additional electronics, pumps or electrical circuits. -
Page 9: Fuel-Water Separator & Drain
Various Accessories Manuals Fuel-Water Separator & Drain Fuel-Water Separator Each Pathfinder 2300 HPS is equipped with a fuel water separator to ensure maximum performance and protect the outboard engine from contaminated gasoline. The fuel separator is a metal, cylindrical unit secured to the transom section of your starboard aft rigging box. -
Page 10: Bilge
Bilge Bilge The bilge of your Pathfinder should always be checked before and after a launch. While checking the bilge, note that a small amount of water in the bilge is normal. However, a large amount of water or any signs of fuel or oil requires immediate attention. If such a situation exists, the boat should be taken to a certified marine technician immediately. - Page 11 Large quantities of water in the bilge may be an indication of a leak or that the bilge pump and/or automatic float switch is not functioning properly due to a jam, clog or electrical issue. The automatic float switch is wired to the 24-hour side of the battery switch through the “BILGE”...
-
Page 12: Systems
Systems Ball Valves Ball valves can be used to serve several purposes. They allow seawater to enter the boat, in the case of livewells, and they also act as a safeguard to stop water from entering. To tell which position a ball valve is in, open or closed, look at the valve and determine the direction of flow. -
Page 13: Backing Plates & Trolling Motor Wiring
Backing Plates & Trolling Motor Wiring Backing Plates The diagram on page 25 shows all the screw-retention backing plates (trolling motor, T- Top, Leaning Post) originally placed in the deck of a Pathfinder 2300 HPS during the construction process. Trolling Motor/Wiring System Your Pathfinder 2300 HPS comes standard with a 36V trolling motor wiring system. -
Page 14: Ladder & Props
Ladder & Props Stainless Boarding Ladder The 2300 HPS comes with the Swim/Dive Platform mounted in the stern of the boat. This platform provides for an easier and safer entry and exit from the boat. To operate the platform simply lift the metal ladder from the platform, extend the ladder to its full length, and let the ladder fall into the water. -
Page 15: Fuel System
Props Prop selection on your 2300 HPS is determined by your local Pathfinder Dealer, but all props are based on recommendations from Pathfinder Boat Company and Yamaha Marine in order to give your boat maximum overall performance. The needs of your prop will determine the prop design and size that best fits your performance requirements. -
Page 16: Self-Bailing Cockpit & Livewell
Self-Bailing Cockpit & Livewell Self-Bailing Cockpit The cockpit on the Pathfinder 2300 HPS is designed to be self-bailing, meaning that all the water that comes into the cockpit will be directly drained overboard. This keeps the boat from acquiring standing water and allows the boat to drain at all times, including while the boat is docked. -
Page 17: Wiring
Your Pathfinder 2300 HPS comes with two standpipes and a pacifier-style drain plug to control water levels inside the livewell. The smaller standpipe is for use with crustaceans like shrimp and crabs that prefer a lower water level. - Page 18 Inside the console on the starboard side is the ground terminal and the breaker panel is located in the glove box. All the grounds lead to the ground terminal and then to the battery via a large diameter black wire. Pathfinder Main Harness To Console Pin #...
-
Page 19: Standard Features
We also run a string aft to the rigging box. Standard Features Trim Tabs Trim tabs are standard on the Pathfinder 2300 HPS. We use integrated 9 X 12-inch Bennett electric trim tabs which can enhance the boat’s performance. - Page 20 Pushing the bottom of the switch (Up) will raise the tabs and lift the bow out of the water for better running performance. To achieve the best running performance with your Pathfinder 2300 HPS, use the engine trim in conjunction with your trim tabs to find the perfect amount of lift and a safe, comfortable ride.
- Page 21 Under Gunwale Rod Storage The 2300 HPS comes standard with under gunwale rod racks on both the port and starboard sides. These give you space to safely store an additional 4 rods for your fishing needs. Forward Console Storage The forward console cushion doubles as a...
- Page 22 Jackplates A standard jackplate has been installed on your Pathfinder 2300 HPS to improve shallow water performance. A jackplate allows the motor to be trimmed straight up as opposed to the angled trimming of the stock engine trim motor, thus allowing more prop to remain in the water while running.
-
Page 23: Optional Features
Optional Features Optional JL Stereo System If you chose the stereo option, your 2300 HPS came with a JL Audio Stereo system Media Master 50 with four matching speakers. Please refer to the JL Audio Owner’s Manual in your duffel bag for operation. Even if your boat didn’t come with the stereo, it is pre-wired for four speakers in the cockpit and two speakers in the hardtop. -
Page 24: 2300 Hps Optional Trolling Motor
2300 HPS Optional Trolling Motor with Battery Charger and Wire Routing Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 25: 2300 Hps Reinforcements
2300 HPS Reinforcements 48” to center of the board measured 7” to center of the board measured from the front cockpit wall from the gunwale board landing Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com... -
Page 26: Upholstery Care & Cleaning Guide
Upholstery Care & Cleaning Guide Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 27: Warranty
Your relationship with your local Pathfinder dealer should never end with the delivery of your new boat. Your local Pathfinder dealership is where you will take your boat for service and repair, as well as to address any warranty issues.
