- Page 1 2200 Tournament Edition Owner’s Manual Revised March 2020 Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631...
- Page 2 Welcome to the Pathfinder Family! Thank you for choosing a Pathfinder boat to transport you to your angling dreams. We believe the Pathfinder 2200 Tournament Edition is the best all- purpose boat on the market, and we’re sure that you’ll be completely satisfied with the unmatched performance, quality and fishability of your new boat.
-
Page 3: Table Of Contents
Self-Bailing Cockpit & Livewell ......................16 Wiring ................................. 18 Standard Features ..........................20 Optional Features ..........................23 2200 Tournament Edition Optional Trolling Motor ................. 25 2200 Tournament Edition Reinforcements ..................26 2200 Tournament Edition Power Pole Plate ..................27 Upholstery Care & Cleaning Guide ..................28 Warranty .............................. -
Page 4: 2200 Tournament Edition Specifications
2200 Tournament Edition Specifications L.O.A........................22’ 02” BEAM..............………………….…....8’ 06” DRAFT..........................11” WEIGHT W/ ENGINE..................3,075 LBS. FUEL CAPACITY....................55 GAL. MAXIMUM H.P......................250 MAX CAPACITIES…………………………………..…...………7 PERSONS OR 1,400 LBS. In Deck Storage Leaning Rigging Post Access Locking Rod Anchor Locker Storage Livewell Storage Rod Rack... -
Page 5: Pre-Operation Checklist
Pre-Operation Checklist We recommend you print this document and store it at the helm station. Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 6: Maintenance & Cleaning
Maintenance & Cleaning Maintenance Pathfinder advises owners that maintenance and repairs should be performed at an authorized Pathfinder Dealer. The following information is general in nature and should not be considered a repair manual or guidelines set forth by Maverick Boat Group. -
Page 7: Engine Break-In Period
DO NOT operate the boat if the engine stop switch system does not function properly. Go to a Pathfinder Dealer to have this resolved immediately. The lanyard should be securely attached to the boat operator at all times that the engine is on. -
Page 8: Switch Panel & Helm
Gauges The instrument panel on your Pathfinder 2600 TRS is composed of one Yamaha digital gauge and a series of dual activation switches. The switches come with accessory plug- ins for wiring additional electronics, pumps or electrical circuits. -
Page 9: Fuel-Water Separator & Drain
Various Accessories Manuals Fuel-Water Separator & Drain Fuel-Water Separator Each Pathfinder 2200 Tournament Edition is equipped with a fuel water separator to ensure maximum performance and protect the outboard engine from contaminated gasoline. The fuel separator is a metal, cylindrical unit secured to the transom section of your starboard aft rigging box. -
Page 10: Bilge
Bilge Bilge The bilge of your Pathfinder should always be checked before and after a launch. While checking the bilge, note that a small amount of water in the bilge is normal. However, a large amount of water or any signs of fuel or oil requires immediate attention. If such a situation exists, the boat should be taken to a certified marine technician immediately. - Page 11 Large quantities of water in the bilge may be an indication of a leak or that the bilge pump and/or automatic float switch is not functioning properly due to a jam, clog or electrical issue. The automatic float switch is wired to the 24-hour side of the battery switch through the “BILGE”...
-
Page 12: Systems
Systems Ball Valves Ball valves can be used to serve several purposes. They allow seawater to enter the boat, in the case of livewells, and they also act as a safeguard to stop water from entering. To tell which position a ball valve is in, open or closed, look at the valve and determine the direction of flow. -
Page 13: Backing Plates & Trolling Motor Wiring
Backing Plates & Trolling Motor Wiring Backing Plates The diagrams on pages 26-27 show all the screw-retention backing plates (trolling motor, T-Top, Leaning Post) originally placed in the deck of a Pathfinder 2200 Tournament Edition during the construction process. Trolling Motor/Wiring System Your Pathfinder 2200 Tournament Edition comes standard with a 24V trolling motor wiring system. - Page 14 Your Pathfinder is rigged at the factory so that the primary battery or "house battery" is tied to setting “1” on the battery switch. When the switch is in this position, your main breaker LED light should be illuminated. If that is not the case, determine if the breaker has been tripped by pressing in the right side of 50-amp switch labeled with the “I”.
-
Page 15: Ladder & Props
Props Prop selection on your 2200 Tournament Edition is determined by your local Pathfinder Dealer, but all props are based on recommendations from Pathfinder Boat Company and Yamaha Marine in order to give your boat maximum overall performance. The needs of your prop will determine the prop design and size that best fits your performance requirements. -
Page 16: Fuel System
Self-Bailing Cockpit & Livewell Self-Bailing Cockpit The cockpit on the Pathfinder 2200 Tournament Edition is designed to be self-bailing, meaning that all the water that comes into the cockpit will be directly drained overboard. This keeps the boat from acquiring standing water and allows the boat to drain at all times, including while the boat is docked. - Page 17 Pathfinder Dealer immediately. Refer to page 10 for further information regarding bilge pump operation and maintenance.
-
Page 18: Wiring
Wiring A wiring diagram of your Pathfinder has been included to help troubleshoot any electrical problems or to add additional electronics or electrical connections. We recommend you use a trained marine electrician for all electrical issues. - Page 19 Pathfinder Main Harness To Console Pin # Function Wire Color Nav Lts (Instrumentation) Grey Nav Lts Grey Anc Lt (Console) Grey/White Anc Lt (T‐TOP) Grey/White Pin C T‐Top Recept Horn Orange/White Spreader Lt Blue/Black Pin A T‐Top Recept Overhead Lts Blue/Green Pin B T‐Top Recept...
-
Page 20: Standard Features
We also run a string aft to the rigging box. Standard Features Trim Tabs Trim tabs are standard on the Pathfinder 2200 Tournament Edition. We use integrated 9 X 12-inch Bennett electric trim tabs which can enhance the boat’s performance. - Page 21 Pushing the bottom of the switch (Up) will raise the tabs and lift the bow out of the water for better running performance. To achieve the best running performance with your Pathfinder 2200 Tournament Edition, use the engine trim in conjunction with your trim tabs to find the perfect amount of lift and a safe, comfortable ride.
- Page 22 Under Gunwale Rod Storage The 2200 Tournament Edition comes standard with under gunwale rod racks on both the port and starboard sides. These give you space to safely store an additional 4 rods for your fishing needs. Forward Console Storage...
-
Page 23: Optional Features
Optional Features Optional JL Stereo System If you chose the stereo option, your 2200 Tournament Edition came with a JL Audio Stereo system Media Master 50 with four matching speakers. Please refer to the JL Audio Owner’s Manual in your duffel bag for operation. Even if your boat didn’t come with the stereo, it is pre-wired for four speakers in the cockpit and two speakers in the hardtop. - Page 24 Transom supporting devices can be purchased from your local Pathfinder dealer or boating and trailer supply stores.
-
Page 25: 2200 Tournament Edition Optional Trolling Motor
2200 Tournament Edition Optional Trolling Motor with Battery Charger and Wire Routing Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 26: 2200 Tournament Edition Reinforcements
2200 Tournament Edition Reinforcements ” X 15” ½” CORE STRBD only ” 28 ” 4 - ” X 8” X ¼” 3 - 6 ” x 6” ALUMINUM 15 ” ” ” OUT AND 1” IN Aluminum 2 - ” X 6”... -
Page 27: 2200 Tournament Edition Power Pole Plate
2200 Tournament Edition Power Pole Plate 8” x 8” x ¼” Starboard Side Only Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 28: Upholstery Care & Cleaning Guide
Upholstery Care & Cleaning Guide Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 29: Warranty
Your relationship with your local Pathfinder dealer should never end with the delivery of your new boat. Your local Pathfinder dealership is where you will take your boat for service and repair, as well as to address any warranty issues.
