- Page 1 2400 TRS Owner’s Manual Revised May 2020 Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631...
- Page 2 Thank you for choosing a Pathfinder boat to transport you to your angling dreams. We believe the Pathfinder 2400 TRS is the best all-purpose boat on the market, and we’re sure that you’ll be completely satisfied with the unmatched performance, quality and fishability of your new boat.
-
Page 3: Table Of Contents
Wiring ................................. 18 Standard Features ..........................20 Optional Features ..........................23 2400 TRS Optional Trolling Motor with Battery Charger and Wire Routing......24 2400 TRS Reinforcements ........................25 2400 TRS Power Pole Plate ........................26 Upholstery Care & Cleaning Guide ....................27 Warranty .............................. -
Page 4: 2400 Trs Specifications
2400 TRS Specifications L.O.A........................23’ 11” BEAM..............………………….…....8’ 06” DRAFT..........................12” DEADRISE……………………………………………………………………………….15 DEG. WEIGHT W/ ENGINE..................3,300 LBS. FUEL CAPACITY....................73 GAL. MAXIMUM H.P......................300 MAX CAPACITIES…………………………………..…...…….…9 PERSONS OR 2,000 LBS. Fuel Fill Leaning Anchor Locker Livewell Post Locking Rod Storage Livewell Aft Deck Flip-Up Cooler with... -
Page 5: Pre-Operation Checklist
Pre-Operation Checklist We recommend you print this document and store it at the helm station. Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 6: Maintenance & Cleaning
Maintenance & Cleaning Maintenance Pathfinder advises owners that maintenance and repairs should be performed at an authorized Pathfinder Dealer. The following information is general in nature and should not be considered a repair manual or guidelines set forth by Maverick Boat Group. -
Page 7: Engine Break-In Period
DO NOT operate the boat if the engine stop switch system does not function properly. Go to a Pathfinder Dealer to have this resolved immediately. The lanyard should be securely attached to the boat operator at all times that the engine is on. -
Page 8: Switch Panel & Helm
Helm & Switch Panel Gauges The instrument panel on your Pathfinder 2600 TRS is composed of one Yamaha digital gauge and a series of dual activation switches. The switches come with accessory plug- ins for wiring additional electronics, pumps or electrical circuits. -
Page 9: Fuel-Water Separator & Drain
Various Accessories Manuals Fuel-Water Separator & Drain Fuel-Water Separator Each Pathfinder 2400 TRS is equipped with a fuel water separator to ensure maximum performance and protect the outboard engine from contaminated gasoline. The fuel separator is a metal, cylindrical unit secured to the transom section of your starboard aft rigging box. -
Page 10: Bilge
Bilge Bilge The bilge of your Pathfinder should always be checked before and after a launch. While checking the bilge, note that a small amount of water in the bilge is normal. However, a large amount of water or any signs of fuel or oil requires immediate attention. If such a situation exists, the boat should be taken to a certified marine technician immediately. - Page 11 switch through the “BILGE” breaker on the battery switch panel. When functioning properly, the float switch activates the bilge pump to pump water overboard once water in the bilge reaches a level that submerges the switch. If the bilge pump does not come on when the float switch is submerged, attempt to manually turn it on through your switch panel.
-
Page 12: Systems
Systems Ball Valves Ball valves can be used to serve several purposes. They allow seawater to enter the boat, in the case of livewells, and they also act as a safeguard to stop water from entering. To tell which position a ball valve is in, open or closed, look at the valve and determine the direction of flow. -
Page 13: Backing Plates & Trolling Motor Wiring
Your Pathfinder is rigged at the factory so that the primary battery or "house battery" is tied to setting “1” on the battery switch. When the switch is in this position, your main breaker LED light should be illuminated. - Page 14 will close the circuit and should result in the LED light coming on. In the event there is still no main power, this could be an indication of a dead battery, loose connection from this battery to the battery switch, or the need for a new 50-amp breaker. All Pathfinders are rigged standard with a 36 volt trolling motor wiring system.
-
Page 15: Ladder & Props
Ladder & Props Stainless Boarding Ladder The 2400 TRS comes with the Swim/Dive Platform mounted in the stern of the boat. This platform provides for an easier and safer entry and exit from the boat. To operate the platform simply lift the metal ladder from the platform, extend the ladder to its full length, and let the ladder fall into the water. -
Page 16: Fuel System
Self-Bailing Cockpit & Livewell Self-Bailing Cockpit The cockpit on the Pathfinder 2400 TRS is designed to be self-bailing, meaning that all the water that comes into the cockpit will be directly drained overboard. This keeps the boat from acquiring standing water and allows the boat to drain at all times, including while the boat is docked. - Page 17 Livewell System The new and improved livewell system on the 2400 TRS keeps bait alive longer than any other system on the market. It has a dual inflow system and a unique drain system that prevents dead zones and quickly expels any harmful chemicals (such as ammonia) from the water.
-
Page 18: Wiring
Wiring A wiring diagram of your Pathfinder has been included to help troubleshoot any electrical problems or to add additional electronics or electrical connections. We recommend you use a trained marine electrician for all electrical issues. - Page 19 Pathfinder Main Harness To Console Pin # Function Wire Color Nav Lts (Instrumentation) Grey Nav Lts Grey Anc Lt (Console) Grey/White Anc Lt (T‐TOP) Grey/White Pin C T‐Top Recept Horn Orange/White Spreader Lt Blue/Black Pin A T‐Top Recept Overhead Lts Blue/Green Pin B T‐Top Recept...
-
Page 20: Standard Features
Pushing the bottom of the switch (Up) will raise the tabs and lift the bow out of the water for better running performance. To achieve the best running performance with your Pathfinder 2400 TRS, use the engine trim in conjunction with your trim tabs to find the perfect amount of lift and a safe, comfortable ride. - Page 21 Salt Water Wash-Down Salt-water washdown is standard on the 2400 TRS. The pump is located in the bilge forward of the livewell pump and is accessible through the splashwell hatch or the aft port hatch. To operate, hook a hose to the raw water receptacle in the aft section of the rod locker.
- Page 22 Leaning Post The leaning post comes standard with the Pathfinder 2400 TRS and includes a folding footrest, four rod holders, two drink holders, and cushions. A storage tray is located beneath the cushion. Leaning Post Jackplates A standard jackplate has been installed on your Pathfinder 2400 TRS to improve shallow water performance.
-
Page 23: Optional Features
Optional Features Optional JL Stereo System If you chose the stereo option, your 2400 TRS came with a JL Audio Stereo system Media Master 50 with four matching speakers. Please refer to the JL Audio Owner’s Manual in your duffel bag for operation. Even if your boat didn’t come with the stereo, it is pre-wired for four speakers in the cockpit and two speakers in the hardtop. -
Page 24: 2400 Trs Optional Trolling Motor With Battery Charger And Wire Routing
2400 TRS Optional Trolling Motor with Battery Charger and Wire Routing Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 25: 2400 Trs Reinforcements
2400 TRS Reinforcements *reference only 2400 TRS Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 26: 2400 Trs Power Pole Plate
2400 TRS Power Pole Plate 2400 TRS PM POWER POLE PLATE 5 ” ” x 8” x 3/8” Aluminum Starboard Side Only 5 ” Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 27: Upholstery Care & Cleaning Guide
Upholstery Care & Cleaning Guide Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 28: Warranty
Your relationship with your local Pathfinder dealer should never end with the delivery of your new boat. Your local Pathfinder dealership is where you will take your boat for service and repair, as well as to address any warranty issues.
