- Page 1 2200 TRS Owner’s Manual Revised March 2020 Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631...
- Page 2 Thank you for choosing a Pathfinder boat to transport you to your angling dreams. We believe the Pathfinder 2200 TRS is the best all-purpose boat on the market, and we’re sure that you’ll be completely satisfied with the unmatched performance, quality and fishability of your new boat.
-
Page 3: Table Of Contents
Self-Bailing Cockpit & Livewell ......................16 Wiring ................................. 18 Standard Features ..........................20 Optional Features ..........................21 2200 TRS Optional Trolling Motor ......................24 2200 TRS Reinforcements ........................25 2200 TRS Power Pole Plate ........................26 Upholstery Care & Cleaning Guide ..................27 Warranty .............................. -
Page 4: 2200 Trs Specifications
2200 TRS Specifications L.O.A........................22’ 01” BEAM..............………………….…....8’ 06” DRAFT..........................11” WEIGHT W/ ENGINE..................2,850 LBS. FUEL CAPACITY....................55 GAL. DEADRISE @ TRANSOM..................15 DEG. MAXIMUM H.P......................250 MAX CAPACITIES…………………………………..…...………7 PERSONS OR 1,400 LBS. Locking Rod Cushioned Anchor Locker Aft Deck Flip- Storage Seat/Cooler Up Seating Boarding... -
Page 5: Pre-Operation Checklist
Pre-Operation Checklist We recommend you print this document and store it at the helm station. Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 6: Maintenance & Cleaning
Maintenance & Cleaning Maintenance Pathfinder advises owners that maintenance and repairs should be performed at an authorized Pathfinder Dealer. The following information is general in nature and should not be considered a repair manual or guidelines set forth by Maverick Boat Group. -
Page 7: Engine Break-In Period
DO NOT operate the boat if the engine stop switch system does not function properly. Go to a Pathfinder Dealer to have this resolved immediately. The lanyard should be securely attached to the boat operator at all times that the engine is on. -
Page 8: Switch Panel & Helm
To the right of the steering wheel you have your two trim tab switches, which are standard on the 2200 TRS. The boat also comes standard with a compass mounted on top of the console. -
Page 9: Fuel-Water Separator & Drain
Various Accessories Manuals Fuel-Water Separator & Drain Fuel-Water Separator Each Pathfinder 2200 TRS is equipped with a fuel water separator to ensure maximum performance and protect the outboard engine from contaminated gasoline. The fuel separator is a metal, cylindrical unit secured to the transom section of your starboard aft rigging box. -
Page 10: Bilge
Bilge Bilge The bilge of your Pathfinder should always be checked before and after a launch. While checking the bilge, note that a small amount of water in the bilge is normal. However, a large amount of water or any signs of fuel or oil requires immediate attention. If such a situation exists, the boat should be taken to a certified marine technician immediately. - Page 11 Large quantities of water in the bilge may be an indication of a leak or that the bilge pump and/or automatic float switch is not functioning properly due to a jam, clog or electrical issue. The automatic float switch is wired to the 24-hour side of the battery switch through the “BILGE”...
-
Page 12: Systems
Systems Ball Valves Ball valves can be used to serve several purposes. They allow seawater to enter the boat, in the case of livewells, and they also act as a safeguard to stop water from entering. To tell which position a ball valve is in, open or closed, look at the valve and determine the direction of flow. -
Page 13: Backing Plates & Trolling Motor Wiring
Backing Plates & Trolling Motor Wiring Backing Plates The diagrams on pages 25-26 show all the screw-retention backing plates (trolling motor, T-Top, Leaning Post) originally placed in the deck of a Pathfinder 2200 TRS during the construction process. Trolling Motor/Wiring System Your Pathfinder 2200 TRS comes standard with a 24V trolling motor wiring system. - Page 14 Your Pathfinder is rigged at the factory so that the primary battery or "house battery" is tied to setting “1” on the battery switch. When the switch is in this position, your main breaker LED light should be illuminated. If that is not the case, determine if the breaker has been tripped by pressing in the right side of 50-amp switch labeled with the “I”.
-
Page 15: Ladder & Props
Props Prop selection on your 2200 TRS is determined by your local Pathfinder Dealer, but all props are based on recommendations from Pathfinder Boat Company and Yamaha Marine in order to give your boat maximum overall performance. The needs of your prop will determine the prop design and size that best fits your performance requirements. -
Page 16: Fuel System
Self-Bailing Cockpit & Livewell Self-Bailing Cockpit The cockpit on the Pathfinder 2200 TRS is designed to be self-bailing, meaning that all the water that comes into the cockpit will be directly drained overboard. This keeps the boat from acquiring standing water and allows the boat to drain at all times, including while the boat is docked. - Page 17 Livewell System The new and improved livewell system on the 2200 TRS keeps bait alive longer than any other system on the market. It has a dual inflow system and a unique drain system that prevents dead zones and quickly expels any harmful chemicals (such as ammonia) from the water.
-
Page 18: Wiring
Wiring A wiring diagram of your Pathfinder 2200 TRS has been included to help troubleshoot any electrical problems or to add additional electronics or electrical connections. We recommend you use a trained marine electrician for all electrical issues. - Page 19 Pathfinder Main Harness To Console Pin # Function Wire Color Nav Lts (Instrumentation) Grey Nav Lts Grey Anc Lt (Console) Grey/White Anc Lt (T‐TOP) Grey/White Pin C T‐Top Recept Horn Orange/White Spreader Lt Blue/Black Pin A T‐Top Recept Overhead Lts Blue/Green Pin B T‐Top Recept...
-
Page 20: Standard Features
We also run a string aft to the rigging box. Standard Features Trim Tabs Trim tabs are standard on the Pathfinder 2200 TRS. We use integrated 9 X 12-inch Bennett electric trim tabs which can enhance the boat’s performance. Because the tabs are... -
Page 21: Optional Features
Optional Features Optional JL Stereo System If you chose the stereo option, your 2200 TRS came with a JL Audio Stereo system Media Master 50 with four matching speakers. Please refer to the JL Audio Owner’s Manual in your duffel bag for operation. Even if your boat didn’t come with the stereo, it is pre-wired for four speakers in the cockpit and two speakers in the hardtop. - Page 22 Pathfinder Duffel Bag. Salt Water Wash-Down Salt-water washdown is an option on the 2200 TRS. The pump is located in the bilge forward of the livewell pump and is accessible through the splashwell hatch or the aft port hatch. To operate, hook a hose to the raw water receptacle in the aft section of the rod locker.
- Page 23 Jackplates Your Pathfinder 2200 TRS may have an optional jackplate to improve shallow water performance. A jackplate allows the motor to be trimmed straight up as opposed to the angled trimming of the stock engine trim motor, thus allowing more prop to remain in the water while running.
-
Page 24: 2200 Trs Optional Trolling Motor
2200 TRS Optional Trolling Motor with Battery Charger and Wire Routing Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 25: 2200 Trs Reinforcements
2200 TRS Reinforcements PW Spring Line Cleat Backing Board Port and Starboard Side < ------- Transom Bow ------ > Whaleboard 8 ” x 8” x 3/8” 36 ” 7 ” ” to center of the board “to center of the board measured from... -
Page 26: 2200 Trs Power Pole Plate
2200 TRS Power Pole Plate 8” x 8” x ¼” Starboard Side Only Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 27: Upholstery Care & Cleaning Guide
Upholstery Care & Cleaning Guide Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • Pathfinderboats.com (772)-465-0631... -
Page 28: Warranty
Your relationship with your local Pathfinder dealer should never end with the delivery of your new boat. Your local Pathfinder dealership is where you will take your boat for service and repair, as well as to address any warranty issues.
