Smart Home Collection Hub
Set-Up Instructions for Android
The Smart Home Collection Hub connects to home networks to unlock the luxury of shade control. Experience customization with
scene and timer options as well as voice control via Google Assistant Amazon Alexa.
THE APP ALLOWS FOR:
1.
Individual and group control – Group of shades by room and conveniently control them accordingly.
2.
Remote connectivity - Control shades remotely, whether home or away on a local network or an internet connection.
3.
Scene control - Personalize shade control and organize how your shades operate by specific daily events.
4.
Timer functionality - Set and forget. Lower, raise and activate shade scenes automatically at the optimal time.
5.
Sunrise and Sunset - Utilizing time zone and location, the Pulse 2 can automatically raise or lower shades according to the
position of the sun.
6.
Compatible IoT Integrations:
-
IFTTT via applets
-
Amazon Alexa devices
-
Google Home
-
Smart Things
GETTING STARTED:
•
In order to experience your shade control through the SHC app, you will need to have:
•
Downloaded the free app via the Google Play Store.
•
Purchased one or more Hub's depending on the size of the area you would like to cover.
•
Familiarized yourself with the app navigation guide below.
•
Created a Location then pair hub to that location. Our step by step guide will explain in more detail.
WI-FI HUB TECHNICAL SPECIFICATIONS:
Radio Frequency range: 98 feet or 30 meters - (no obstructions).
•
Radio Frequency: 433 MHz
•
Wi-Fi 2.4 GHz or Ethernet Connectivity (CAT 5).
•
•
Power: 5V DC.
•
For Indoor Use Only.
SETUP BEST PRACTICES:
•
The Hub must be within signal range of both the shades and the connected via Lan or Wi-Fi router.
•
If you chose to use the Wi-Fi network, certify that it must be visible.
•
Environments with multiple WAPs (wireless access points) may need all but the main router temporarily disabled.
Security settings may need to be temporarily disabled.
•
CAPABILITIES:
Motors per Hub: 20
•
Locations per account: 5
•
Hub's per location: 5
•
•
Rooms per Location: 30
•
Scenes per Location: 15
Timers per Location: 15
•
budgetblinds.com
Smart Home Collection

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart Home Hub and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for rollease acmeda Smart Home Hub

Summary of Contents for rollease acmeda Smart Home Hub

  • Page 1 Smart Home Collection Hub Set-Up Instructions for Android The Smart Home Collection Hub connects to home networks to unlock the luxury of shade control. Experience customization with scene and timer options as well as voice control via Google Assistant Amazon Alexa. THE APP ALLOWS FOR: Individual and group control –...

  • Page 2: What's In The Box

    WHAT’S IN THE BOX? USB Power 32” (80cm) USB Quick Start Guide Ethernet cable The Smart Home Supply Power Cord Collection Hub UNPACKING THE HUB 2.0 1. Unpack the Hub. 2. Check the Box Contents. 4. Connect the Micro 5. Plug the Power 3.

  • Page 3: Creating A Location

    SETTING UP: STEP 1 – Open App STEP 3 – Sign Up STEP 4 – Sign In STEP 2 – Sign Up Creating an account will require Open the SHC mobile App. If required, create a new If you already have an account an email address and password.
  • Page 4 CONFIGURING A HUB: STEP 10 - Configure a Hub STEP 11 - Configure a Hub STEP 8 - Configure a Hub STEP 9 - Configure a Hub Follow on the screen Pressing the P button for ~2 Click on “ADD NEW HUB” to Select the location desired to add a secs until the Blue LED begins start the process to setting up...
  • Page 5 STEP 18 - Configure a Hub STEP 19 - Configure a Hub STEP 16 - Configure a Hub STEP 17 - Configure a Hub Press the ‘NEXT’ button to forward Wait while the hub connects to your Verify your Wi-Fi network is listed. Enter your Wi-Fi networks password.
  • Page 6 HOW TO PAIR A MOTOR TO THE APP: We recommend setting up your motors with a remote prior to syncing with the App. STEP 24 – Pair a motor STEP 25 – Pair a motor STEP 26 – Pair a motor STEP 27 –...
  • Page 7 STEP 35 – Pair a motor STEP 36 – Shade Details STEP 37 – Pair a motor STEP 38 – Shade Ready If the pairing process was successful, Press Input the desired device name. Press The “New Device” will now be added Shade is now ready for operation ‘NEXT’...
  • Page 8 HOW TO CREATE A ROOM: STEP 1 – Create a Room STEP 2 – Create a Room STEP 3 – Create a Room STEP 4 – Create a Room Once the Shades are paired to the Select the ‘ROOM NAME’ to enter the Enter the Room Name and click “OK”.
  • Page 9 STEP 9 -Add Shades to a Room STEP 10 – Operate a Room STEP 11 – Operate a Room Select the Room to operate All shades Wait for the App to conclude the Operate all shades in the Room with that have been added to the room at the three button options available: process of room set up.
  • Page 10 STEP 5 – Create a Scene STEP 6 – Create a Scene STEP 8 – Create a Scene STEP 7 – Create a Scene Select the icon that represents your Select ‘UPDATE SCENE DEVICES’ to Choose custom heights (by %) or set Set the shade height percentage if necessary.

  • Page 11: Programming Timers

    PROGRAMMING TIMERS: You can program timers to trigger the specific operation of your shades and scenes at your desired times throughout the day. STEP 2 – Create a Timer STEP 3 – Create a Timer STEP 4 – Create a Timer STEP 1 –...
  • Page 12 HOW TO CREATE FAVORITE: STEP 1 – Create a Favorite Device STEP 3 – Create a Favorite Scene STEP 2 – Edit a Favorite Device STEP 4 – Create a Favorite Scene Select the “Plus” icon to add a Select ‘EDIT’ in the upper right corner Select the “Plus”...
  • Page 13 STEP 5 – Setting Limits STEP 6 – Setting Limits STEP 7 – Setting Limits STEP 8 – Setting Limits To move your shade a little bit, press The app will configure the new top Press the ‘Bottom Position’ to change To move your shade a little bit, press the arrow buttons or slide the double position...
  • Page 14 HOW TO SHARE THE HUB: STEP 1 - Share a Hub STEP 2 - Share a Hub STEP 3 - Share a Hub STEP 4 - Share a Hub In the ‘Add a Hub’ Screen, it is The HUB must have been shared The shared Hub will be listed on the After it is added, the shared hub will possible to connect to a shared hub.
  • Page 15 LED STATUS INDICATION: COLOR RESPONSE STATUS Blue LED blinks Automate Pulse 2 Hub is in pairing mode. Blue LED short blinks Automate Pulse 2 is configuring via the App. Blue LED long blinks Automate Pulse 2 is Connected to Wi-Fi. Blue LED short blinks Automate Pulse 2 is getting a Firmware Updating.
  • Page 16 MEANING OF ICONS: COLOR RESPONSE STATUS Signal Icon The Shade is connected with the HUB and works properly. Battery Icon Green The Battery Level is over than 70%. Battery Icon Yellow The Battery Level is between 50% and 70%. Battery Icon Red The Battery Level is less than 50%.

  • Page 17: Troubleshooting

    TROUBLESHOOTING: The following scenarios are common issues that may cause connectivity problems during the Smart Home Collection Hub pairing process. If you cannot achieve success connecting the Smart Home Collection Hub to your network, please reference the below most common pairing roadblocks. I CANNOT CONNECT TO MY HIDDEN WI-FI NETWORK.
