- Page 1 INSTALLATION GUIDE Pro Wall Chimney Ventilation Hoods READ AND SAVE THESE INSTRUCTIONS...
-
Page 2: Table Of Contents
Contents Important Note Wolf Pro Wall Chimney Ventilation Hoods ..3 To ensure the safe and efficient use of Wolf equipment, please take note of the following types of highlighted Safety Instructions ......4 information throughout this guide: Installation Considerations . -
Page 3: Wolf Pro Wall Chimney Ventilation Hoods
Pro Wall Chimney Hood Installation IMPORTANT NOTE: This installation must be completed Wolf Pro Wall Chimney Hood by a qualified installer or Wolf authorized service center Model Number technician. Serial Number Read this entire installation guide prior to installation and save for the local inspector’s reference. -
Page 4: Safety Instructions
Install the pro ventilation hood only with a blower • C) Clean ventilation fans frequently. Grease should manufactured by Wolf. not be allowed to accumulate on fan or filter. When cutting or drilling into wall or ceiling, do not •... -
Page 5: Installation Considerations
Wolf pro wall chimney hoods are recommended for use BLOWER ASSEMBLIES with all Wolf cooking appliances and should be at least as Wolf pro ventilation hoods are shipped without the blower wide as the cooking surface. The ventilation hood should assembly. -
Page 6: Pro Wall Chimney Hood Specifications
Pro Wall Chimney Hood Specifications Overall Dimensions PRO WALL CHIMNEY HOODS 18" " WIDTH MINUS (457) (343) 18" (457) OVERALL HEIGHT 4" (102) 24" 36" , 42" , 48" (610) (914) (1067) (1219) 54" OVERALL DEPTH (1372) WIDTHS Installation Specifications PRO WALL CHIMNEY HOODS 6"... - Page 7 Installation Specifications Electrical Requirements The illustration below provides dimensions critical for Wolf pro ventilation hoods require a separate, grounded proper installation of the pro wall chimney hood. Dimen- 120 V AC, 60 Hz power supply. The service should have its sions A and B in the illustration will vary with the width of own 15 amp circuit breaker.
-
Page 8: Pro Wall Chimney Hood Installation
To reduce the risk of fire, use only metal ductwork. IMPORTANT NOTE: Pro ventilation hoods must exhaust to the outdoors. Wolf recommends that the pro wall chimney hood be DUCTWORK INSTALLATION THROUGH ROOF installed 30" (762) to 36" (914) above the countertop. - Page 9 Pro Wall Chimney Hood Installation wolfappliance.com/specs Wall Framing IMPORTANT NOTE: A minimum 10" (254) opening in the ceiling is required to accommodate the ductwork neces- Due to the weight of the hood, make sure the wood sary for proper ventilation. mounting strip is attached to all available wall studs and blocking.
- Page 10 Pro Wall Chimney Hood Installation Hood Preparation 1) Remove the filters of the pro wall chimney hood by IMPORTANT NOTE: For wall chimney hoods using a pushing each filter up at the angle it is placed in, 600 CFM or 900 CFM internal blower, the internal blower then rotate the bottom of the filter down.
- Page 11 Pro Wall Chimney Hood Installation wolfappliance.com/specs Duct Cover IMPORTANT NOTE: If an optional duct cover is to be used DUCT COVER INSTALLATION with the pro wall chimney hood, it must be attached IMPORTANT NOTE: For wall chimney hoods using a before installing the hood.
- Page 12 Pro Wall Chimney Hood Installation Hood Installation 2) Using the #8 x 2" (51) screws (provided with hood), secure the hood to the wood mounting strip. Refer to Due to the weight of the hood, be sure to have the illustration below. adequate assistance for installation.
- Page 13 1) Remove the hood electrical box cover. Run Romex ® able through your authorized Wolf dealer. For local dealer wire from a 120 V AC, 15 amp circuit to the hood information, visit the find a showroom section of our installation location.
- Page 14 Pro Wall Chimney Hood Installation Internal Blowers IMPORTANT NOTE: Refer to specific installation instruc- BLOWER INSTALLATION (1200 CFM) tions provided with each blower assembly for additional 1) Discard the hex nut provided with the blower. mounting and wiring instructions. 2) Lift the blower assembly into position inside the hood. 3) Engage the two tabs on the blower into the two slots in BLOWER INSTALLATION (600 CFM AND 900 CFM) the top plate of the wall chimney hood.
- Page 15 Pro Wall Chimney Hood Installation wolfappliance.com/specs In-Line and Remote Blowers WIRING FOR IN-LINE OR REMOTE BLOWER 1) Remove the hood electrical box cover. Run Romex ® Before making electrical connections, make sure the wire from a 120 V AC, 15 amp circuit to the hood electrical power is turned off at the service panel.
- Page 16 Refer to the illustrations below for overall dimensions of Wolf in-line and remote blowers. Installation instructions Locate the blower so that the length of the duct run and shipped with each Wolf ventilation product provide number of elbows and transitions are kept to a minimum.
- Page 17 INSTALL FILTERS LOGO NAMEPLATE Reinstall the internal frame on the wall chimney hood. The Wolf logo nameplate does not come installed on the Refer to hood preparation on page 10. wall chimney hood since there are various locations that the nameplate can be attached.
-
Page 18: Service Information
• Verify that electrical power is being supplied to the ventilation hood. To obtain the name and number of a Wolf authorized service center, check the contact & support section of our • Check electrical connections to ensure that the website, wolfappliance.com or call Wolf customer service... - Page 19 Wolf Appliance, Inc. ©Wolf Appliance, Inc. all rights reserved. Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf Appliance, Inc.
- Page 20 WOLF APPLIANCE, INC. P. O. BOX 44848 MADISON, WI 53744 WOLFAPPLIANCE.COM 800.332.9513 817002 REV-A 8/ 2010...
