Planning Information
Pro 24"
Deep Wall Ventilation Hood
(610)
M O D E L P W 3 6 2 4 1 8 ( R )
Model PW362418
Model PW362418R
Rail Option
Wolf Pro 24" (610) deep wall hoods
are available in the classic stainless steel
finish. Rail option hoods (R) come with a
classic stainless steel decorative rail and
stand-offs. Optional platinum or brass
rails match dual fuel range bezels. Pro
wall hoods are sold as a shell only;
internal, in-line and remote blower
options are available.
Dimensions in parentheses are in
millimeters unless otherwise specified.
7/07
Hand finished
craftsmanship
Stainless steel
baffle filters
Location of
rating plate
Welded seams
and hemmed edges
Halogen lighting
Model PW362418R shown with decorative rail.
W
olf Pro wall hoods provide the ultimate in
ventilation. With standard elements like heat sentry
and dual setting halogen lighting, Wolf elevates the
need for ventilation to an enjoyable perk.
Pro 24" (610) deep wall hoods are available in the
classic stainless steel finish. You also have the option
of a decorative rail. While a classic stainless steel rail
is standard on (R) models, platinum or brass rails are
available to match the bezels of our dual fuel ranges
and sealed burner rangetops.
Pro wall ventilation hoods are recommended for use
with all Wolf cooking appliances. For optimal perform-
ance, a Pro 27" (686) deep wall hood is recommended
for use with ranges and rangetops that contain a
charbroiler or griddle.
Classic stainless
steel finish
Decorative rail
(optional)
Recessed easy-
access controls
Infinite-speed
blower control
1

Advertisement

loading

Summary of Contents for Wolf PW362418

  • Page 1 Planning Information Pro 24" Deep Wall Ventilation Hood (610) M O D E L P W 3 6 2 4 1 8 ( R ) Stainless steel Model PW362418 baffle filters Location of rating plate Model PW362418R Rail Option Welded seams and hemmed edges Wolf Pro 24"...
  • Page 2 O V E R A L L D I M E N S I O N S 18" (457) OVERALL HEIGHT 36" (914) OVERALL WIDTH Model PW362418 4" (102) 36" (914) OVERALL WIDTH Model PW362418R with Rail Unit dimensions may vary by ±...
  • Page 3 Planning Information Pro 24" Deep Wall Ventilation Hood (610) M O D E L P W 3 6 2 4 1 8 ( R ) B L O W E R O P T I O N S 600 CFM Internal Blower 810559 900 CFM Internal Blower 811131...
  • Page 4 Planning Information Pro 24" Deep Wall Ventilation Hood (610) M O D E L P W 3 6 2 4 1 8 ( R ) I N S T A L L A T I O N S P E C I F I C A T I O N S LOCATION OF ELECTRICAL 36"...
  • Page 5 Planning Information Pro 24" Deep Wall Ventilation Hood (610) M O D E L P W 3 6 2 4 1 8 ( R ) I N S T A L L A T I O N N O T E S Refer to the illustrations and specifications for overall dimensions and installation specifics.
  • Page 6 Planning Information Pro 24" Deep Wall Ventilation Hood (610) M O D E L P W 3 6 2 4 1 8 ( R ) D U C T I N G C O N S I D E R A T I O N S Wolf Pro 24"...
  • Page 7 Planning Information Pro 24" Deep Wall Ventilation Hood (610) M O D E L P W 3 6 2 4 1 8 ( R ) W O L F B L O W E R A S S E M B L I E S A ventilation system must include a blower assembly.
  • Page 8 P R O V E N T I L A T I O N C F M R E C O M M E N D A T I O N S Pro 24" (610) Deep Wall Hoods Model PW302418 PW362418 PW422418 PW482418 PW542418 PW602418 PW662418 DF304 / R304 / SRT304 DF366 / R366 / SRT366 / RT366...
