- Page 1 178 019 54 Providing sustainable energy solutions worldwide Installation- and maintenance instruction B 40 A2.2...
- Page 3 DESCRIPTION Components 1. Shrouded disc 9. Electric panel 17. Damper motor 2. Nozzle 10. Cover, inspection glass 18. Connecting pipe Stage 2 3. Ignition electrodes 11. Indicating lamp (Burner with two nozzles) 4. Nozzle assembly 12. Change-over switch 19. Air damper 5.
-
Page 4: Technical Data
TECHNICAL DATA Type designation B40A2 ø114 Dimensions 200-230 Burner tube Length of burner tube Measure B Output range and nozzles recommended Recommended Recommended Burner tube Oil capacity Nozzle Pump pressure kg/h Mcal/h Angle Type 8,0-29,5 95-350 82-301 45° - 60° S, B, R, PLP The net caloriic value of 11,86 kWh/kg for light oil has been used. -
Page 5: General Instructions
GENERAL INSTRUCTIONS Maintenance General Rules The boiler/burner should be examined nozzles than older models. The installation of an oil burner should This increases the eficiency but also regularly for any signs of malfunction be carried out in accordance with local or oil leakage. - Page 6 AIR ADJUSTMENT WITH DAMPER MOTOR The damper motor turns the damper Low capacity: Note! between 3 preset positions: fully Adjust the operating switch to high The blue cam is the limit position for closed, low capacity and high capa- capacity (II). fully closed damper and it is normally city.
-
Page 7: Maintenance
MAINTENANCE Warning: Before doing any service switch off power at the main switch and cut off the oil supply. Open the cover and disconnect Service of burner head the connecting pipes by loosening screw A and nut B. 1. Loosen or swing out the burner from the boiler. - Page 8 (1)(2) * If the boiler is not equipped with wired contacts, connect the enclosed contacts to terminals X4 and X6 in accordance with wiring diagram. 1N ~ 50/60Hz 230 V...
-
Page 9: Electric Equipment
ELECTRIC EQUIPMENT List of components A1 Oil burner control B1 Photoresistor F1 Fuse H1 Lamp, low capacity H2 Lamp, high capacity H3 Lamp, lock-out signal 220 V M1 Burner motor M2 Damper motor SQN75.244A21B P1 Time meter, low capacity (optional) P2 Time meter, high capacity (optional) S1 Operating switch S2 Operating switch, high/low capacity... - Page 10 ELECTRIC EQUIPMENT Function Switch on operating switch and twin thermostat A spark is formed. The air damper motor opens the damper to low load position. The burner motor starts, the prepurge goes on till the prepurge period expires and the solenoid valve 1 opens (2) Solenoid valve 1 opens Oil mist is formed and ignited.
- Page 11 INSTRUCTIONS PUMP TYPE SUNTEC A2L 65C - 75C Technical data One or two-pipe system. Viscosity range: 2-12 mm Pressure range: 8-15 bar Rated voltage of coil: 220/240V 50/60 Hz Oil temperature: max 60°C Components 1. Nozzle outlet G 1/8" Stage 2 2.
- Page 12 INSTRUCTIONS PUMP TYPE SUNTEC A2L 65C - 75C Pump operating principle for Solenoid valve 2 (NC) closed Solenoid valve 1 (NC) closed A2L 65C - 75C Solenoid valve 2 Solenoid valve 1 (NC) open (NC) open The SUNTEC A2L oil pump has two nozzle outlets.
-
Page 13: Nozzle Table
NOZZLE TABLE Pump pressure bar kg/h Mcal/h kg/h Mcal/h kg/h Mcal/h kg/h Mcal/h 0,40 1,33 1,41 1,49 1,56 0,50 1,66 1,76 1,86 1,95 0,60 2,00 2,12 2,23 2,34 0,65 2,16 2,29 2,42 2,54 0,75 2,49 2,65 2,79 2,93 0,85 2,83 3,00 3,16 3,32... - Page 14 NOZZLE TABLE Pump pressure bar kg/h Mcal/h kg/h Mcal/h kg/h Mcal/h kg/h Mcal/h 0,40 1,63 1,70 1,76 1,82 0,50 2,04 2,12 2,20 2,28 0,60 2,45 2,55 2,64 2,73 0,65 2,65 2,75 2,86 2,96 0,75 3,08 3,18 3,30 3,42 0,85 3,47 3,61 3,74 3,87...
-
Page 15: Fault Location
FAULT LOCATION Burner fails to start Possible causes Situation Remedies Motor runs Flame instability Burner pre-purges Check nozzle to burner head dimension Incorrect head settings and electrode position Low oil pressure Check oil pressure Flame occurs Excess air Adjust air damper Burner locks out Check that photocell is clean and unobstructed... - Page 16 EU direktiv. Enertech AB declares under sole responsibility that the above mentioned product is in conformity with the following standards or other normative documents and follows the provisions of applicable parts in the following EU Directives.
- Page 17 OIL BURNERS MAINTENANCE INSTRUCTIONS General information If the burner starts but does not ignite Keep the boiler room clean. Ensure that the boiler Make an attempt to start the burner. room has permanent fresh air intake. Switch off before Never make close repeated start attempts. dismantling the oil burner.
- Page 20 Enertech AB. P.O Box 309, SE-341 26 Ljungby. www.bentone.se, www.bentone.com...
