Summary of Contents for Safeline GL1
- Page 1 GL1 manual GSM gateways Reliability – brought to you from Tyresö Sweden www.safeline-group.com 09.2020 © 2020 SafeLine and all the SafeLine products and GL1 & GL1-4G v.2.1.1 EN accessories are copyrighted by law.
- Page 2 Weight: 220 gram SIM card Micro SIM: 15 x 12 x 0,76 mm Unit is beeing delivered with a 3 m antenna cable, SMA contact (male). This product is intended for use in EMEA countries. GL1 & GL1-4G v.2.1.1 EN...
-
Page 3: Table Of Contents
Content General information Overview Installation Connecting the unit Network services Using the SIM card LED Indication Services Increase RX audio level Trouble shooting Interference/poor sound quality Declaration of Conformity GL1 & GL1-4G v.2.1.1 EN... -
Page 4: General Information
Declaration of conformity Download ”The declaration of conformity” at our website: www.safeline-group.com GL1 & GL1-4G v.2.1.1 EN... -
Page 5: Overview
Overview Holder It is possible to attach the GL1 with either the DIN holder or the optional holder. Mini USB Use the mini USB connection and the SLPro to update SW. LED’s There are three LED indicators. Refer to "LED Indication". -
Page 6: Installation
Installation Connecting the To avoid GSM interference: Place the GL1, the lift emergency telephone and the GSM antenna at least 1,5 m apart. unit >>1.5 m >>1.5 m >>1.5 m 0,1m ² Network Only applicable for *GL1: before you can start using a new SIM card, the card has to be prepared and support 2G network. -
Page 7: Using The Sim Card
Make a call from your phone to verify that the SIM card is active, before you move it to the SafeLine GL1. Also make a call to SafeLine GL1 after insertion of the SIM card, to check that it is possible to get a proper connection. -
Page 8: Led Indication
Handset not applied to/put on the (100/100/100/2200 ms) unit correctly. Signal Strength = 100 % = 85 % = 70 % = 55 % = 30 %* = 15 % = 0 % *Minimum signal strength for using GSM interface. GL1 & GL1-4G v.2.1.1 EN... -
Page 9: Services
When the desired level is reached, turn off the power. Then restart the unit. The new GSM receiving audio level is now stored. RX audio level = 0 % = 25 % = 50 % = 75 % = 100 % GL1 & GL1-4G v.2.1.1 EN... -
Page 10: Trouble Shooting
• Place the antenna where the highest field intensity is obtained according to the table ("LED Indication") for the unit. • When a call is connected try placing the antenna in different places to find where the best receiving/sending position is. GL1 & GL1-4G v.2.1.1 EN... -
Page 11: Declaration Of Conformity
Your partner in lift safety EU Declaration of Conformity GL1 V3.0 EU Declaration of Conformity Product: Mobile network emulator Type / model: Safeline GL1 Article no: *GL1, *GL1-4G Manufacturer: SafeLine Sweden AB Year: 2020 We herewith declare under our sole responsibility as manufacturer that the products referred to above... - Page 12 Support: +32 (0)4 85 89 08 95 SafeLine Deutschland GmbH Kurzgewannstraße 3 · D-68526 Ladenburg · Germany Tel.: +49 (0) 6203 840 60 03 · sld@safeline.eu SafeLine Group UK Unit 47 · Acorn Industrial Park · Crayford · Kent · DA1 4AL · United Kingdom Tel.: +44 (0) 1322 52 13 96 ·...
