- Page 1 GL6 manual GSM gateways Innovation brought to you from Tyresö Sweden www.safeline-group.com 09.2020 © 2020 SafeLine and all the SafeLine products and SafeLine GL6 v.2.1.1 EN accessories are copyrighted by law.
- Page 2 - Requires SW 1.30 or later - Supports 2G, 3G and 4G (800/900/1800/2100/2600 MHz) - This product is intended for use in EMEA countries. SIM card size: Micro SIM Operating temperature: +5 - 40C Air humidity: 30 - 90 % RH SafeLine GL6 v.2.1.1 EN...
-
Page 3: Table Of Contents
General information Introduction Overview Wiring diagram Relay output Intercom Network services Activating the SIM card Indication LED GSM field strength Reset button Configuration Configuration with PC SafeLine Pro Operation Troubleshooting Interference/poor sound quality Avoid GSM interference SafeLine GL6 v.2.1.1 EN... -
Page 4: General Information
If it is to be used It is extremely important that for any other purpose, SafeLine these installation instructions must be contacted in advance. are made available at all times... -
Page 5: Introduction
Introduction Overview SafeLine GL6 is a line emulator that simulates a standard telephone line. It can be used together with all SafeLine telephones or any other PSTN (Public Switched Telephone Network) telephone. Easy to install and suitable as both temporary or permanent installation. -
Page 6: Wiring Diagram
Wiring diagram 1 2 3 5 6 7 +12 VDC SafeLine GL6 v.2.1.1 EN... -
Page 7: Relay Output
Relay is active when battery test has failed. System failure Relay is active when GL6 has GSM network coverage. Relay deactivates when GSM network is missing for more than 15 seconds or when mains power has been off for more than 15 minutes. -
Page 8: Intercom
12 VDC output and intercom indication output. Use of intercom When an intercom call is generated the GL6 rings up to 16 times, waiting for a phone that is connected to the GL6 to answer. LED3 indicates when a ringing call expires, and when the call time counter is activated. -
Page 9: Network Services
Contact your service provider for more information about 4G and VoLTE in your specific region. Activating the The GL6 can only recognize the PIN code if the code is set to “1234”, “0000”, “1111” or if it is deactivated. If set to anything else, SIM card the GL6 cannot use the SIM card. -
Page 10: Indication Led
Incoming call. Flashing red Searching for GSM network. Continuous red No SIM card. * Hash, ”#”, must be generated for the phone to disconnect the call. Please ask the operator to press ”#” before hanging up. SafeLine GL6 v.2.1.1 EN... -
Page 11: Gsm Field Strength
Turn off when using battery power Press for 3 sec Check GSM network signal strength Press 3 times Start a battery test manually Press once Cancel battery test Press once Turn on when using battery power SafeLine GL6 v.2.1.1 EN... -
Page 12: Configuration
Configuration Configuration The unit can be configured at the office prior to the installation or on site after installation. with PC The configuration software SafeLine Pro can be downloaded from www.safeline-group.com. SafeLine SafeLine SafeLine Pro Use the latest version of SafeLine Pro. The software... - Page 13 E.g. 10 min, 10 sec or 10 pulses before activating an event. 3. Relay output Sets the output relay operating mode. • None The output relay is not enabled (default). • Battery failure The output relay is activated if the battery test has failed. SafeLine GL6 v.2.1.1 EN...
- Page 14 • System failure The output relay is activated when the GL6 has a GSM network. The output relay is deactivated when the GSM network has been lost for more than 15 seconds, or when the power has been off for more than 15 minutes.
- Page 15 Message: the limit for the message text is 128 characters maximum. 5. Miscellaneous Resets all input fields to their default value. Puts SafeLine Pro in basic mode execution, empties phone fields etc. 6. Connection Test With a computer directly to GL6.
- Page 16 Depending on network module, select the wireless net. 9. File Open a previously saved GL6 parameter file, or save the current GL6 parameters to a file. E.g. IDD12345678.gl6. Save the GL6 parameter file for use elsewhere, for example if you have several GL6 with the same settings.
-
Page 17: Operation
• Battery discharge protection When the GL6 runs on battery power, the battery saver function will turn off the GL6 when the battery level reduces to 10.7 volts. When the mains power is reconnected the GL6 powers up again. Mains power control The GL6 is constantly monitoring the mains power. -
Page 18: Troubleshooting
Call cannot be connected. Error message from telephone operator. • To make a call, area code must always be used. Interference/ • Bear in mind that the wiring between GL6 and the lift tele- phone/ phone is basically a “standard” PSTN-line and can poor sound therefore not be placed within the lift travelling cable together with high voltage. - Page 19 Your partner in lift safety EU Declaration of Conformity GL6 V3.0 EU Declaration of Conformity Product: Mobile network emulator Type / model: Safeline GL6 Article no: *GL6, *GL6-4G, *GL6-FC, *GL6-FC-4G Manufacturer: SafeLine Sweden AB Year: 2020 We herewith declare under our sole responsibility as manufacturer that the products referred to above...
- Page 20 Support: +32 (0)4 85 89 08 95 SafeLine Deutschland GmbH Kurzgewannstraße 3 · D-68526 Ladenburg · Germany Tel.: +49 (0) 6203 840 60 03 · sld@safeline.eu SafeLine Group UK Unit 47 · Acorn Industrial Park · Crayford · Kent · DA1 4AL · United Kingdom Tel.: +44 (0) 1322 52 13 96 ·...
