- Page 1 Preface Introduction Installing the Subscriber Unit RUGGEDCOM WIN5214 Device Management Technical Specifications Certification Installation Guide 10/2018 RC1130-EN-07...
- Page 2 Warranty Siemens warrants this product for a period of five (5) years from the date of purchase, conditional upon the return to factory for maintenance during the warranty term. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void.
-
Page 3: Table Of Contents
RUGGEDCOM WIN5214 Installation Guide Table of Contents Table of Contents Preface ......................Alerts ..............................v Related Documents ..........................vi Training .............................. vi Customer Support ..........................vi Chapter 1 Introduction ..................... 1.1 Feature Highlights ........................2 1.2 Description ........................... 2 1.3 Required Tools and Materials ...................... - Page 4 RUGGEDCOM WIN5214 Table of Contents Installation Guide Chapter 3 Device Management ..................3.1 Configuring the Subscriber Unit ....................25 Chapter 4 Technical Specifications .................. 4.1 Power Consumption ........................27 4.2 Radio and Modem Specifications ....................27 4.3 Operating Environment ....................... 28 4.4 Mechanical Specifications ......................28 4.5 IDU to ODU Cable Specifications ....................
-
Page 5: Preface
Preface Preface This guide describes the RUGGEDCOM WIN5214. It describes the major features of the subscriber unit, installation, commissioning and important technical specifications. It is intended for use by subscriber unit installers and operators, and assumes readers have a working knowledge of WiMAX technologies and procedures. -
Page 6: Related Documents
Siemens Sales representative. Customer Support Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general information, contact Siemens Customer Support through any of the following methods: Online Visit http://www.siemens.com/automation/support-request... -
Page 7: Introduction
Introduction Introduction The RUGGEDCOM WIN5214 subscriber unit is part of the RUGGEDCOM WIN family, a line of mobile WiMAX broadband wireless access systems based on the IEEE 802.16e mobile WiMAX standard. The RUGGEDCOM WIN5214 is a high-performance, self-learning subscriber. It automatically detects the base station on the best signal available, allowing for plug-and-play installation and maintenance free operation. -
Page 8: Feature Highlights
The subscriber unit supports both IP convergence sublayer for wireless Internet service providers or Ethernet Convergence Sublayer, ideal for mission critical private networks. Section 1.2 Description The RUGGEDCOM WIN5214 features various ports, controls and indicator LEDs on the bottom panel for connecting, configuring and troubleshooting the subscriber unit. Feature Highlights... - Page 9 RUGGEDCOM WIN5214 Chapter 1 Installation Guide Introduction ETH/PWR RSSI W.LINK PWR RSSI W.LINK PWR Figure 1: RUGGEDCOM WIN5214 1. RSSI LEDs 2. W.LINK LED 3. PWR LED 4. ETH/PWR Port 5. Chassis Ground RSSI LEDs Indicates the received signal strength. RSSI Level < -90 -85 to -90...
-
Page 10: Required Tools And Materials
Section 2.6, “Grounding the Subscriber Unit”. Section 1.3 Required Tools and Materials The following tools and materials are required to install the RUGGEDCOM WIN5214: Kits Greases • Class I, Division 2 Kit (P/N MKIT0090) – For hazardous • Marine grease (for marine applications only) -
Page 11: Installing The Subscriber Unit
WARNING! Safety hazard – risk of serious personal injury and/or damage to equipment. Installing the RUGGEDCOM WIN5214 can pose a serious safety hazard. Be sure to take precautions to avoid the following: • Exposure to high voltage lines during installation •... -
Page 12: General Procedure
Chapter 2 RUGGEDCOM WIN5214 Installing the Subscriber Unit Installation Guide IMPORTANT! This product should be installed in a restricted access location where access can only be gained by authorized personnel who have been informed of the restrictions and any precautions that must be taken. -
Page 13: Unpacking The Subscriber Unit
Configure the subscriber unit. For more information, refer to Section 3.1, “Configuring the Subscriber Unit”. Section 2.2 Unpacking the Subscriber Unit The following items are included in the RUGGEDCOM WIN5214 package: Item Quantity RUGGEDCOM WIN5214 Subscriber Unit RUGGEDCOM WIN1010 AC Power Injector Radio Frequency (RF) antenna cables, 5 m (16.4 ft) long... - Page 14 • Always use the most appropriate mounting method for the site and the equipment being installed. For assistance, contact a Siemens representative. • Always assume an overhead line can cause serious injury or death. Note that electric power lines and phone lines look alike.
-
Page 15: Installing The Subscriber Unit In Hazardous Locations
Installing the Subscriber Unit in Hazardous Locations The RUGGEDCOM WIN5214 is designed to comply with the safety standards for Class I, Division 2, Zone 2 hazardous locations where concentrations of flammable gases, vapors or liquids may be present, as opposed to normal operating environments. -
Page 16: Mounting The Subscriber Unit To A Wall Or Tower
Chapter 2 RUGGEDCOM WIN5214 Installing the Subscriber Unit Installation Guide When choosing the mounting location for the unit, consider the available mounting structures and antenna clearance. Site Survey Most wireless networks include many subscriber/base stations installed in various locations in an overlapping radio-cell pattern. - Page 17 RUGGEDCOM WIN5214 Chapter 2 Installation Guide Installing the Subscriber Unit Figure 3: Mounting the Subscriber Unit to a Wall or Tower 1. Subscriber Unit 2. Mounting Kit 3. Wall Holder/Pole Mount 4. M8 × 25 mm Hex Screw 5. M8 Spring Washer 6. M8 Flat Washer 7. M8 Nut 8. M5 Flat Washer 9. NS 1/4" × 1/2" HEX Chipboard Screw 10. Wall Anchor Liberally apply an anti-corrosion spray to all galvanized steel components, including mounting brackets, washers and screws.
-
Page 18: Mounting The Subscriber Unit To A Pole
If the subscriber unit is not synchronized with the base station, make sure the subscriber unit is properly configured. For more information, refer to the RUGGEDCOM WIN User Guide for the RUGGEDCOM WIN5214. If the expected link quality still cannot be achieved, try to improve the reception quality by placing the subscriber unit at a higher point or in an alternate location. - Page 19 RUGGEDCOM WIN5214 Chapter 2 Installation Guide Installing the Subscriber Unit Figure 5: Mounting the Subscriber Unit to a Small Pole 1. Subscriber Unit 2. Pole 3. Clamping Bracket 4. Mounting Bracket 5. M8-25 Hex Screw 6. M8 Spring Washer 7. M8 Flat Washer 8. M8 Nut 9. M8-70 Hex Screw Liberally apply an anti-corrosion spray to all galvanized steel components, including mounting brackets, nuts, washers and screws.
-
Page 20: Grounding The Subscriber Unit
Chapter 2 RUGGEDCOM WIN5214 Installing the Subscriber Unit Installation Guide 10. Tighten the screws connecting the clamping bracket to the mounting bracket. Make sure the screws are torqued to 14 N·m (10 lbf-ft). Section 2.6 Grounding the Subscriber Unit When connecting the ground cable to the subscriber unit, make sure to use a 10 AWG grounding cable and torque the screw to 15 N·m (11 ft. -
Page 21: Connecting The Ruggedcom Win1010
Electrical hazard – risk of damage to equipment. The power cord provided with the data adapter is safety certified according to national rules. Do not use a power cord that has not been approved by Siemens for use with the data adapter. To connect power and data to the subscriber unit, do the following: CAUTION! Crushing hazard –... -
Page 22: Connecting To A Ruggedcom Rp100 Or Rp110
Connecting to a RUGGEDCOM RP100 or RP110 The RUGGEDCOM RP100 and RP110 are optional power injectors for powering and providing data to the RUGGEDCOM WIN5214. The RUGGEDCOM RP100 and RP110 meet a wider temperature and voltage range than the standardRUGGEDCOM WIN1010. - Page 23 RUGGEDCOM WIN5214 Chapter 2 Installation Guide Installing the Subscriber Unit • The RJ45 connector kit (included). Contains an RJ45 connector and loading bar. • CAT-5e cable of suitable length for your application. For information on cable specifications, refer to Section 4.5, “IDU to ODU Cable Specifications”.
- Page 24 Chapter 2 RUGGEDCOM WIN5214 Installing the Subscriber Unit Installation Guide Figure 10: Folding Back the Foil 1. Foil 2. Twisted-Pair Wires 3. Drain Wire Bend the drain wire back over the jacket. Figure 11: Bending the Drain Wire 1. Foil 2. Drain Wire 3. Twisted-Pair Wires Partially untwist each wire pair, making sure to retain a half twist at the end.
- Page 25 RUGGEDCOM WIN5214 Chapter 2 Installation Guide Installing the Subscriber Unit Color Description Number White/Orange ETH Data TP0+ Orange ETH Data TP0- White/Green ETH Data TP1+ Figure 13: CAT-5e PoE Cable Pin-Out Blue 48 V TP2+ 1. Pin 1 2. Pin 8 White/Blue 48 V...
-
Page 26: Installing The Hazardous Location Kit
An approved Power-over-Ethernet (PoE) injector is required when the subscriber unit is installed in a hazardous location. The RUGGEDCOM WIN5214 is certified for installation in Class I, Division 2 Groups A, B, C and D hazardous locations when installed using the Class I, Division 2 kit (P/N MKIT0090). The Class I, Division 2 kit contains the following items: •... -
Page 27: Weatherproofing The Subscriber Unit
Most outdoor subscriber unit, antenna and cable problems are caused by coaxial cable connections loosened by vibration, allowing moisture to penetrate the connector interface. Siemens strongly recommends weatherproofing all outdoor cable connections to prevent the ingress of water and help secure connections. -
Page 28: Weatherproofing A Cable
Chapter 2 RUGGEDCOM WIN5214 Installing the Subscriber Unit Installation Guide IMPORTANT! The method of weatherproofing described in this section must be completed on all external connections. If surge arrestors are used, all associated connections and arrestors must be completely wrapped with splicing tape or self-amalgamating tape. -
Page 29: Applying Self-Amalgamating Tape
RUGGEDCOM WIN5214 Chapter 2 Installation Guide Installing the Subscriber Unit Hold the tube against the subscriber unit chassis and start rotating it clockwise while gently pulling out the core. Stop rotating once the front end of the cold shrink has begun to form around the cable end. - Page 30 Chapter 2 RUGGEDCOM WIN5214 Installing the Subscriber Unit Installation Guide Applying Self-Amalgamating Tape...
-
Page 31: Device Management
RUGGEDCOM WIN5214 Chapter 3 Installation Guide Device Management Device Management This section describes how to connect to and manage the subscriber unit. CONTENTS • Section 3.1, “Configuring the Subscriber Unit” Section 3.1 Configuring the Subscriber Unit Once the subscriber unit is installed and connected to the network, it must be configured. The RUGGEDCOM WIN5214 features a Web-based User Interface (UI) for all configuration management. - Page 32 Chapter 3 RUGGEDCOM WIN5214 Device Management Installation Guide Configuring the Subscriber Unit...
-
Page 33: Technical Specifications
RUGGEDCOM WIN5214 Chapter 4 Installation Guide Technical Specifications Technical Specifications This section provides important technical specifications related to the subscriber unit. CONTENTS • Section 4.1, “Power Consumption” • Section 4.2, “Radio and Modem Specifications” • Section 4.3, “Operating Environment” • Section 4.4, “Mechanical Specifications”... -
Page 34: Operating Environment
-20 to 100 dBm Dynamic Range (Transmitter) -20 to 27 dBm Section 4.3 Operating Environment The RUGGEDCOM WIN5214 is rated to operate under the following environmental conditions. Ambient Operating -40 to 75 °C (-40 to 167 °F) Temperature Ambient Storage Temperature -40 to 75 °C (-40 to 167 °F) - Page 35 RUGGEDCOM WIN5214 Chapter 4 Installation Guide Technical Specifications Conductor Size 0.52 mm Outer Jacket Material UV resistant FR-PVC Outer Diameter 7.9 mm (0.31 in) nominal Weight 68.0 kg/km IDU to ODU Cable Design and Materials Conductor Material Bare Copper Conductor Size...
-
Page 36: Dimension Drawings
Chapter 4 RUGGEDCOM WIN5214 Technical Specifications Installation Guide Dielectric Strength to Shield 700 V/minute Minimum Bend Radius 70 mm (2.8 in) Operating Temperature Range -40 to 70 °C (-40 to 158 °F) Section 4.6 Dimension Drawings NOTE All dimensions are in millimeters, unless otherwise stated. -
Page 37: Certification
RUGGEDCOM WIN5214 Chapter 5 Installation Guide Certification Certification The RUGGEDCOM WIN5214 ODU SU has been thoroughly tested to guarantee its conformance with recognized standards and has received approval from recognized regulatory agencies. CONTENTS • Section 5.1, “Approvals” • Section 5.2, “Environmental Type Tests”... -
Page 38: Csa
Chapter 5 RUGGEDCOM WIN5214 Certification Installation Guide • CAN/CSA-C22.2 No. 213-M1987 Non-Incendive Electrical Equipment for Use in Class I, Division 2 Hazardous Locations The subscriber unit is marked with an MET classified mark that indicates compliance with both Canadian and U.S. -
Page 39: European Union (Eu)
Mobile Operation in Licensed Bands Section 5.1.6 RoHS This device is declared by Siemens Canada Ltd to meet the requirements of the following RoHS (Restriction of Hazardous Substances) directives for the restricted use of certain hazardous substances in electrical and electronic equipment: •... -
Page 40: Environmental Type Tests
Installation Guide A copy of the Material Declaration is available online at https://support.industry.siemens.com/cs/ww/en/ view/109738831. Section 5.2 Environmental Type Tests The RUGGEDCOM WIN5214 has passed the following environmental tests. Test Description Test Levels IEC 60068-2-1 Low Temperature -25 °C for 72 hours -40 °C (-40 °F) for 16 hours... - Page 41 RUGGEDCOM WIN5214 Chapter 5 Installation Guide Certification Test Description Test Levels 100 shocks in each direction IEC 60068-2-32 Free Fall Height: 1 m (3.3 ft) Nebs: GR63 One fall on 3 faces, 3 edges and 4 corners IEC 60068-2-30 Humidity (Cycling) 30 °C (86 °F) @ 90 to 100% for 2 cycles...
- Page 42 Chapter 5 RUGGEDCOM WIN5214 Certification Installation Guide Environmental Type Tests...
