SERVICE & OPERATING MANUAL
ORIGINAL INSTRUCTIONS
1 1/2" Elima-Matic Bolted
with Metal Center Section
E4 Metal Pumps
• Stainless Steel
• Hastalloy
VERSAMATIC
®
Warren Rupp, Inc. • A Unit of IDEX Corporation
800 North Main Street, Mansfield, OH 44902 USA
Phone: (419) 526-7296 • www.versamatic.com
E4
© Copyright 2019
Warren Rupp, Inc. All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Versamatic E4 Series
Summary of Contents for Versamatic E4 Series
- Page 1 E4 Metal Pumps • Stainless Steel • Hastalloy VERSAMATIC 800 North Main Street, Mansfield, OH 44902 USA ® © Copyright 2019 Warren Rupp, Inc. • A Unit of IDEX Corporation Phone: (419) 526-7296 • www.versamatic.com Warren Rupp, Inc. All rights reserved...
- Page 2 EN ISO 80079-36 : 2016 section 6.7.5 table 8, the following protection methods must be applied - Equipment is always used to transfer electrically conductive fl uids or - Explosive environment is prevented from entering the internal portions of the pump, i.e. dry running. versamatic • Model E4 Bolted Metal e4mdlAsmMB-rev1219...
- Page 3 -20°C to +150°C Note: The ambient temperature range and the process temperature range should not exceed the operating temperature range of the applied plastic parts as listed in the manuals of the pumps. Model E4 Bolted Metal • versamatic e4mdlAsmMB-rev1219...
- Page 4 • Composite Drawings • Parts List • Materials Code SECTION 4: WARRANTY & CERTIFICATES ..15 • Warranty • EU Declaration of Conformity - Machinery Directive • EU Declaration of Conformity - ATEX Directive versamatic • Model E4 Bolted Metal e4mdlAsmMB-rev1219...
- Page 5 C Carbon Steel w/ PTFE O-Rings UL UL Listed H Alloy C w/ PTFE O-Rings OB Oil Bottle T PTFE Encapsulated Silicone O-Rings Y FDA Santoprene *More than one option may be specified for a particular pump model. Model E4 Bolted Metal • versamatic e4mdlAsmMB-rev1219...
- Page 6 Note: This document is a high level guide. Please be aware that not all model and or material combinations are possible for all sizes. Please consult factory or your distributor for specific details. versamatic • Model E4 Bolted Metal e4mdlAsmMB-rev1219...
- Page 7 Capacity in Liters Per Minute NOTE: Performance based on the following: PTFE fitted pump, flooded suction, water at ambient conditions. The use of other materials and varying hydraulic conditions may result in deviations in excess of 5%. Model E4 Bolted Metal • versamatic e4mdlAsmMB-rev1219...
- Page 8 STYLE FLANGE 11.30 SUCTION PORT 1 1/2" ANSI / 40m 7.24 STYLE FLANGE 3.13 1.50 10.28 6.27 2.82 3.13 1.50 10.28 6.27 2.82 8.78 8.78 7.00 5.94 7.00 5.94 4X .44 4X .44 versamatic • Model E4 Bolted Metal e4mdlAsmMB-rev1219...
- Page 9 STYLE FLANGE 11.30 SUCTION PORT 1 1/2" ANSI / 40mm DIN 7.24 STYLE FLANGE 3.13 1.50 10.28 6.27 2.82 3.13 1.50 10.28 6.27 2.82 8.78 8.78 7.00 5.94 7.00 5.94 4X .44 4X .44 Model E4 Bolted Metal • versamatic e4mdlAsmMB-rev1219...
- Page 10 (flooded suction condition), pipe the exhaust higher than the product source to prevent siphoning spills. 1" DIAMETER AIR EXHAUST PIPING LIQUID LEVEL SUCTION LINE versamatic • Model E4 Bolted Metal e4mdlAsmMB-rev1219...
- Page 11 To start the pump, slightly open the air shut-off valve. After the pump primes, the air valve can be opened to increase air flow as desired. If opening the valve increases cycling rate, but does not increase the rate of flow, cavitation has occurred. The valve should be closed slightly to obtain the most efficient air flow to pump flow ratio. Model E4 Bolted Metal • versamatic e4mdlAsmMB-rev1219...
- Page 12 Inspect check valves and seats for wear and proper setting. Replace if necessary. Entrained air or vapor lock in chamber(s). Purge chambers through tapped chamber vent plugs. For additional troubleshooting tips contact After Sales Support at service.warrenrupp@idexcorp.com or 419-524-8388 versamatic • Model E4 Bolted Metal e4mdlAsmMB-rev1219...
- Page 13 Composite Repair Parts Drawing 16 Ft-Lbs (XX N-m) 30 Ft-Lbs (XX N-m) 60 In-Lbs (XX N-m) Model E4 Bolted Metal • versamatic e4mdlAsmMB-rev1219...
- Page 14 1.) The outer diaphragm plate material is to match the material of the water chamber. (When built using V163F no outer plate is required) 2.) When built using V163F no inner diaphragm plate is required 3.) Requires (4) qty seat o-rings. 4.) TC=PTFE Coated components, NP=Nickel Plated Components versamatic • Model E4 Bolted Metal e4mdlAsmMB-rev1219...
- Page 15 The recyclability of 360..Nitrile Rubber Color coded: RED 666..FDA Nitrile Diaphragm, Versamatic products is a vital part of Warren Rupp’s 363..FKM (Fluorocarbon) PTFE Overlay, Balls, and Seals commitment to environmental stewardship.
- Page 16 Versamatic warrants to the original end-use purchaser that no product sold by Versamatic that bears a Versamatic brand shall fail under normal use and service due to a defect in material or workmanship within five years from the date of shipment from Versamatic’s factory.
- Page 17 EU Declaration of Conformity Manufacturer: Versamatic A Unit of IDEX Corporation 800 North Main Street Mansfi eld, OH 44902 USA Warren Rupp, Inc declares that Air Operated Double Diaphragm Pumps (AODD) and Surge Suppressors listed below comply with the requirements of Directive 2014/34/EU and all the applicable standards.
