Menu Item Description

The LCD Display Code Setting (AV15), a 4-digit value (ABCD) configures local
display and button handling as follows:
N
OTE
making it unnecessary to write GCL+ programs for display and button handling.
Whenever an application is selected, a matching default Display Code is also set
automatically (typically 1237), but this can be set to something else if so desired.
Document Edition 4.2
Line 1 (Top Left – i.e., Outside Value): 1 to 4
A
1 - Disabled
2 - Value from AV5 (i.e., remote value such as OAT)
3 - Value from AI2 (i.e., external sensor)
4 - Value from AI3 (i.e., Humidity)
Line 2 (Center – i.e., Inside Value): 1 to 4
B
1 - Disabled
2 - Temperature from AI1
3 - Humidity from AI3
4 - Alternates between Temperature (AI1) & Humidity (AI3)
5 - Value from AI2 (i.e., external sensor)
6 - Value from AV5 (i.e., remote value
7 - Setpoint
8 - Setpoint with adjust
9 - User Setpoint with adjust (-3 to +3 degrees)
Line 3 (Bottom – i.e., Setpoint Value): 1 to 5
C
1 - Disabled
2 - No Setpoint until an arrow button is pressed (adjustable)
3 - Setpoint is always displayed (adjustable)
4 - No Setpoint until an arrow button is pressed (not adjustable)
5 - Setpoint is always displayed (not adjustable)
6 - Temperature from AI1
7 - Value from AI2
8 - Humidity from AI3
– CO2 from AI4
9
D House & Day/Night Mode Icons: 1 to 9
H O
OUSE UTLINE
1 No
2 No
3 No
4 No
5 Yes
6 Yes
7 Yes
8 Yes
9 Yes
: When connected to MS/TP, the Display Code may be set to any valid value –
O /O T M
N FF EXT AN
No No
Flash No
Yes No
No No
No No
Yes No
Yes Yes
No Yes
No No
Delta Controls
S /M
UN OON
No
No
No
Yes
No
No
No
No
Yes
