Dino lift Dino 180XT Operation Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

DINO 180
OPERATION INSTRUCTIONS
Raikkolantie 145
FI-32210 LOIMAA
Tel. +358 2 762 5900
Fax. +358 2 762 7160
dino@dinolift.com
www.dinolift.com
XT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dino 180XT and is the answer not in the manual?

Questions and answers

Related Manuals for Dino lift Dino 180XT

Summary of Contents for Dino lift Dino 180XT

  • Page 1 DINO 180 OPERATION INSTRUCTIONS Raikkolantie 145 FI-32210 LOIMAA Tel. +358 2 762 5900 Fax. +358 2 762 7160 dino@dinolift.com www.dinolift.com...
  • Page 2 DINO 180XT...
  • Page 3 DINO 180XT OPERATION INSTRUCTIONS 18154 Valid from serial number...

  • Page 4: Table Of Contents

    DINO 180XT CONTENTS REACH DIAGRAM (M, KG)......................6 TECHNICAL SPECIFICATION (M, KG) ..................7 REACH DIAGRAM (FT, LBS) ......................8 TECHNICAL SPECIFICATION (FT, LBS) .................. 9 GENERAL SAFETY DIRECTIVES ..................... 10 REGULAR INSPECTION ......................12 INSPECTION ON THE WORKSITE ................... 13 SAFETY DEVICES .........................
  • Page 5 DINO 180XT INSPECTING THE LIFT ....................... 60 FIRST INSPECTION ........................60 DAILY INSPECTIONS ........................61 INSPECTIONS ONCE A MONTH ....................62 REGULAR INSPECTION (ANNUAL) ..................63 EXTRAORDINARY INSPECTION ....................66 TEST LOADING IN CONJUNCTION WITH THE REGULAR SERVICE ......... 67 FAULT FINDING ..........................

  • Page 6: Reach Diagram (M, Kg)

    DINO 180XT REACH DIAGRAM (m, kg)

  • Page 7: Technical Specification (M, Kg)

    DINO 180XT TECHNICAL SPECIFICATION (m, kg) Max. working height 18,0 m Max. platform height 16,0 m Max. outreach 10,9 m Boom rotation continuous Platform rotation 90° Reach when turned refer to reach diagram Support width 3,80 m Transport width 1,78 m...

  • Page 8: Reach Diagram (Ft, Lbs)

    DINO 180XT REACH DIAGRAM (ft, lbs)

  • Page 9: Technical Specification (Ft, Lbs)

    DINO 180XT TECHNICAL SPECIFICATION (ft, lbs) Max. working height 59'1" Max. platform height 52'6" Max. outreach 35'9" Boom rotation continuous Platform rotation 90° Reach when turned refer to reach diagram Support width 12'6" Transport width 5'10" Transport length 21'6" Transport height 7'3"...

  • Page 10: General Safety Directives

    DINO 180XT GENERAL SAFETY DIRECTIVES Make yourself familiar with the operators manual before using the lift! The operator's manual should be stored in the space reserved for it. Make sure that all persons working with the lift are familiar with the operator's manual.Inform new users about the operation of the lift and the manual.
  • Page 11 DINO 180XT No ladders, steps or other similar equipment may be used on the platform. Objects may under no circumstances be thrown out from the platform. The lift must not be used to move persons or objects between floors or different work levels.

  • Page 12: Regular Inspection

    DINO 180XT REGULAR INSPECTION A thorough inspection must be made at least once every twelve (12) months. The inspection should be made by a person who is technically trained and is familiar with the function, use and construction of the lift.

  • Page 13: Inspection On The Worksite

    DINO 180XT INSPECTION ON THE WORKSITE 1. General Is the lift suited for the job at hand? Is the performance of the lift sufficient for the job (reach, loadability etc.)? Is the lift located safely on a site so that no negative influence on work safety is possible? Is there enough illumination for safe working? 2.
  • Page 14 DINO 180XT PRESSURE SPRING LIMIT SWITCHES RK4 AND RK5 LIFT LINK CYLINDER...

  • Page 15: Safety Devices

    DINO 180XT SAFETY DEVICES 1. Support outriggers (fig A) A safety limit switch RK3 prevents use of the outriggers and the drive mechanism when the boom is lifted off the transport support. The limit switch is mounted on the tow bar boom support point.
  • Page 16 DINO 180XT...

  • Page 17: Operating Controls

    DINO 180XT OPERATING CONTROLS CONTROLS MOUNTED ON THE CHASSIS Operating switch 0 = Off 1 = Operation of support outriggers, moving the lift by hydraulic power (driving device) and platform inclination 2 = Controlling the boom from the platform 3 = Controlling the boom from the chassis...

  • Page 18: Platform Panel Controls

    DINO 180XT PLATFORM PANEL CONTROLS Close the chassis control panel cover before using the platform controls (the cover must not be locked when using the lift). 17. Operating lever 18. Warning lights green = inside the reach limits = at the reach limit 20.

  • Page 19: Measures To Be Taken If Stability Is Threatened

    DINO 180XT MEASURES TO BE TAKEN IF STABILITY IS THREATENED The following factors can lead to loss of standing stability: a technical fault in the lift wind or other factors that can create sideways forces a decrease in ground firmness...
  • Page 20 DINO 180XT Notes...

  • Page 21: Starting Up The Lift

    DINO 180XT STARTING UP THE LIFT 1. Ground stability - Make sure that the ground is even and level, and hard enough to support the lift in a steady, level position (see table below). Ground material Density Max. ground pressure P kg/cm²...
  • Page 22 DINO 180XT...
  • Page 23 DINO 180XT 3. Power connection A. AC power - Connect the mains cable (230VAC or 110VAC) - Turn on the mains switch (fig. A) - Voltage should be - 230VAC (-10%/ +6%), frequency 50Hz, and mains fuse 16A - 110V ± 15V, frequency 50Hz, and mains fuse 16A (GB) - 110V ±...
  • Page 24 DINO 180XT...
  • Page 25 DINO 180XT 6. Start the motor with push button 2 (green) Petrol/ gasoline engine - switch off the choke - adjust the motor running speed Diesel engine Lower control centre: Motor running speed can be raised by turning switch no 35 (fig. B) Upper control centre: Motor running speed raises by turning switch no 30 (fig.

  • Page 26: Operating The Unit From The Chassis Control Panel

    DINO 180XT OPERATING THE UNIT FROM THE CHASSIS CONTROL PANEL 10. Turn the operating switch (1) into position 3 - The boom can be operated using the levers 7, 8, 9 and 33 - Test the emergency descent function as follows: 1.

  • Page 27: Operating The Unit From The Work Platform

    DINO 180XT OPERATING THE UNIT FROM THE WORK PLATFORM 11. Turn the operating switch (1) into position 2 and take away the key. The cover of the chassis control panel must not be locked with key. - now you can operate the lift from the work platform lever 17.
  • Page 28 DINO 180XT 12. Test function of the overload limit switch RK4. - Platform load about 120 kg (265 lbs) - Move the boom to horizontal position - Extend the telescope. When the movement stops the red overload warning light (18) should light up.
  • Page 29 DINO 180XT 16. Move the work platform to the working area. The platform can be driven with continually adjustable speed from the platform controls (not from the lower control panel). It is not possible to make more than one movement at a time. If more than one of the operating levers is used simultaneously, the movement demanding the least effort (power) will be executed.
  • Page 30 DINO 180XT 19. When moving the platform, remember the following - special care should be taken in the vicinity of high voltage cables - do not exceed the max. allowed sideways load (400N) (88 lbs) - make sure that no part of the platform or the operator can...

  • Page 31: Emergency Descent System

    DINO 180XT EMERGENCY DESCENT SYSTEM As a precaution for a possible power failure, the lift is equipped with a battery operated emergency descent system. 1. Emergency descent system - Battery, 12V 26Ah - Charger - 12 VDC hydraulic unit 2. Servicing the battery...

  • Page 32: Driving Device

    DINO 180XT DRIVING DEVICE The hydraulic driving device should be used for those short moves on the working site for which the towing vehicle cannot be used. - Start up the aggregate - Adjust the running speed to ¾ of the maximum (gasoline/ petrol) Adjust the running speed by turning switch no 35 (diesel) The speed of the driving device depends on the aggregate running speed.
  • Page 33 DINO 180XT - Release the parking brake - Switch on the driving device by turning the switch 27 to position 1 - Drive with press buttons: forwards backwards left-forwards 28A + 28L right-forwards 28A + 28R left-backwards 28B + 28R...

  • Page 34: Special Instructions For Winter Use

    DINO 180XT SPECIAL INSTRUCTIONS FOR WINTER USE - The lift must not be used in temperatures below -20°C (-4°F) - When the lift is used in cold conditions the power unit should be run for a couple of minutes before attempting hydraulically actuated movements - Start by making short warm-up movements to force warmed-up oil into the cylinders, which improves the functioning of the valves.

  • Page 35: Ending The Days Work

    DINO 180XT ENDING THE DAYS WORK 1. Retract the telescoping boom fully. 2. Check that the platform is perpendicular to the boom. 3. Lower the boom and platform onto the towbar - The limit switch mounted on the transport support prevents operating the support outriggers if the platform is not lowered completely 4.

  • Page 36: Preparing The Lift For Transport

    DINO 180XT PREPARING THE LIFT FOR TRANSPORT 1. Retract the telescoping boom fully. 2. Check that the platform is perpendicular to the boom. 3. Lower the boom and platform onto the towbar - The limit switch mounted on the transport support prevents operating the support outriggers if the platform is not lowered completely 4.

  • Page 37: Connecting To The Towing Vehicle

    DINO 180XT CONNECTING TO THE TOWING VEHICLE 1. Lift the handle of the ball coupling at the same time as you push it forwards. This opens the ball coupling. 2. Place the ball coupling onto the towing ball and push lightly downwards. The coupling automatically locks into place.

  • Page 38: Service And Maintenance

    DINO 180XT SERVICE AND MAINTENANCE GENERAL - Inspections and service should always be performed as described in this manual. - More complicated repairs and service measures should be performed by specially trained personnel (the manufacturer, or manufacturers representative). - No changes or additions may be made to the lift without written consent from the manufacturer.

  • Page 39: Inspections And Service

    DINO 180XT INSPECTIONS AND SERVICE 1. The first service inspection should be made after 20 hours of use: - Change the pressure filter cartridge. - Adjust the braking system, refer to page 44. - Check the tightness of the wheel bolts after about 100 km (about 60 miles) driving (325 Nm) 2.

  • Page 40: Lubrication Plan

    DINO 180XT LUBRICATION PLAN...
  • Page 41 DINO 180XT Every 50 hours 1. Overload protection (articulated shaft) bearings 2. Outrigger cylinder joint bearing surfaces 3. Outrigger joint bearing surfaces 4. Outrigger footplate joint bearing surfaces 5. Boom and lifting arms bearing surfaces 6. Platform bearing surfaces 7. Stabilization cylinder bearing (except for the joint bearing on the upper stabilization cylinder piston rod side) 8.
  • Page 42 DINO 180XT...

  • Page 43: Hold- And Load Regulating Valves

    DINO 180XT HOLD- AND LOAD REGULATING VALVES Functional check 1. Checking the outrigger cylinder holding valves with respect to leaks is made by lifting the unit up with the outriggers and measuring, separately at each outrigger, chassis height from the ground.

  • Page 44: Wheel Brakes And Bearings

    DINO 180XT WHEEL BRAKES AND BEARINGS Adjusting the brakes Jack up the lift so that the wheels will rise off the ground and support it in this position. Make sure that the wheels can rotate freely. The brake rods must be slack (with the handbrake released).
  • Page 45 DINO 180XT Apply the handbrake and push the lift backwards until both its wheels lock; when doing so the handbrake lever should rise up and move 5-10 mm backwards from the limiter. 5 –10 mm Release the handbrake. Adjust the length of the return springs to 90 mm.
  • Page 46 DINO 180XT Adjusting the bearings The wheel bearings are lubricated for life and do not need any service. (they do not need additional lubrication and they cannot be adjusted). Service intervals 500 km (300 miles) Running in 5000 km (3000 miles) Brake adjustment, lubricate the moving parts in the overrun device.

  • Page 47: Service, Platform Stabilization System

    DINO 180XT SERVICE, PLATFORM STABILIZATION SYSTEM - The stabilization is effected with a slave cylinder: mounted under the platform and controlled by the master cylinder the levelling of the platform depends on the tightness of the stabilization system valves the system consists of the following parts:...

  • Page 48: Regular Servicing

    DINO 180XT REGULAR SERVICING The lift should be serviced regularly at 11 - 12 month intervals. If it is used in corrosive and demanding ambient conditions (Moist, corrosive chemicals etc.), the technical devices and structure are subjected to harder stresses. In these conditions it is recommended that the servicing and checks be made at shorter intervals.
  • Page 49 DINO 180XT 2. Change the hydraulic oil and filter cartridge. (protect your skin against hydraulic oil) - Drain the oil tank through the draining plug, with all cylinders in retracted position, except lifting arms, which has to be raised 0,5 m (20") - Clean the tank with a suitable solvent and then rinse it.
  • Page 50 DINO 180XT 4. Inspect the support outrigger joints. - Lower the outriggers slightly. - Turn the outriggers back and forth horizontally and check for play in the joints. - Inspect function and condition of the outrigger limit switch mechanism - If necessary, renew the joints and pins.
  • Page 51 DINO 180XT 6. Inspecting the boom and the frame. - Inspect the platform, its attachment, the lifting arms and the boom, with the telescope extended. - Check boom joints and gliding surfaces and adjust if necessary. Lubricate the gliding surfaces.
  • Page 52 DINO 180XT 7. Inspect the towbar/overrun device - Fastening, bolt and nut condition and tightness - Play - Ball coupling condition - Locking mechanism condition - Check that the overrun brake mechanism moves freely: stop the lift, as described on page 36...
  • Page 53 DINO 180XT 10. Inspect safety device functions, operating from chassis control panel. - Lift the platform slightly off transport position. - the outriggers must not function in any position of the operating switch - Lift the arm and check the following 1.

  • Page 54: Testing The Load Limits

    DINO 180XT TESTING THE LOAD LIMITS - Load the platform with exactly 120 kg (265 lbs) 100 mm (4 ") from the trail edge of the platform bottom - Operating from the lower control panel, move boom to horizontal position.
  • Page 55 DINO 180XT...

  • Page 56: Setting The Overload Devices

    DINO 180XT SETTING THE OVERLOAD DEVICES When servicing, always test both overload limit switches - Load the platform with for example 120 kg (265 lbs) - Move the boom into horizontal position...
  • Page 57 DINO 180XT Setting procedure, alternative 1. - Set the actuating point of RK4 far enough to ensure that RK5 is actuated before RK4 - Extend the boom, and measure one part of it (stroke) - The stroke should be 2900 ± 50 mm (114 ± 2 in)
  • Page 58 DINO 180XT 11. Pressure measurements - Connect the pressure gauge to the measuring point - Max. pressure, oil at working temperature (40 - 60 °C) (105 - 140 ˚F), 21 - 21,5 MPa (210 - 215 bar) (3050 - 3100 psi) - When turning, max.
  • Page 59 DINO 180XT 13. Warning signs - Make sure that all warning signs are in good condition and can be easily read. Replace damaged signs. 14. Inspect the brakes and driving device - Remove the wheels - Clean the brake system and check the adjustment, the brake shoes should be...

  • Page 60: Inspecting The Lift

    DINO 180XT INSPECTING THE LIFT Lifting and hoisting equipment used at construction sites should always be inspected before use. The lift should be inspected periodically, at least once a week during the work period. If defects are discovered, they should be noted in a logbook and reported to the foreman.

  • Page 61: Daily Inspections

    DINO 180XT DAILY INSPECTIONS At the beginning of every work shift, or after the lift has been moved to another work site, the user maust always make the following inspections: - Ascertain the carrying capacity of the ground where the lift is to be used (refer to table on page...

  • Page 62: Inspections Once A Month

    DINO 180XT INSPECTIONS ONCE A MONTH (MAINTENANCE INSPECTION) These inspections must be performed by a trained mechanic familiar with the lift. Inspection list: - All the above mentioned daily inspections - Boom and platform attachment - Platform stabilization unit, condition and function...

  • Page 63: Regular Inspection (Annual)

    DINO 180XT REGULAR INSPECTION (ANNUAL) This inspection must be made by a technically trained mechanic who is familiar with the specifications and use of the equipment. Steel structures, safety devices and operating controls should be inspected with special care. Clean the unit thoroughly.
  • Page 64 DINO 180XT - Manually operated directional valves - Check that the support outrigger and driving device valves work correctly and that there are no movements when the spindle is in mid- position - Slipring-hydraulical swivel - Check that there are no oil leaks...
  • Page 65 DINO 180XT - Inspect the boom pivot joints - Check that the boom joint spindle, bearings and spindle fixations are in good condition - Check that the articulating arm joint spindle, bearings and spindle fixations are in good condition - Inspect the support outriggers and support plates - Inspect the mechanical structure and welds.

  • Page 66: Extraordinary Inspection

    DINO 180XT - Inspecting the chassis - General condition - Inspect the tow-bar/frame fastening - Check the condition and fastening of the overrun device - Inspect the axle and its fixation - Inspect brake wires and rods. - Inspect the wheel rims, bolts, tires and tire pressures...

  • Page 67: Test Loading In Conjunction With The Regular Service

    DINO 180XT TEST LOADING IN CONJUNCTION WITH THE REGULAR SERVICE 1. Place the lift on an even surface with good carrying capacity, and lift it up with the supporting outriggers. Lift it as high as possible with the support outriggers (the support area is as small as possible) 2.

  • Page 68: Fault Finding

    DINO 180XT FAULT FINDING CAUSE REMEDY 1. The electric motor does not start when the operating switch is in position 1, 2 or 3 and the start button is pressed. - Emergency push button jammed on - Lift up the emergency push button...
  • Page 69 DINO 180XT CAUSE REMEDY 4. Platform movement problems. Only one movement can be executed. - Irregular and undefined malfunctions - Check that the hydraulic fluid and filter have been replaced on time - thoroughly clean the solenoid valve spindles and housings. Observe utmost cleanliness,...
  • Page 70 DINO 180XT CAUSE REMEDY 8. The boom cannot be raised - refer to item 4 - the solenioid valve is open - other causes, ref. solenoid valve sticking - Turning function activated when using raise - turning solenoid valve stuck in position control "turning"...
  • Page 71 DINO 180XT CAUSE REMEDY 12. Platform moves forwards - boom load regulating (2-way) valve leaks - as above 13. The support outriggers do not work, although the switch is in position 1 - boom does not rest on the support...
  • Page 72 DINO 180XT CAUSE REMEDY 17. Braking power too weak - braking system adjustment too loose, (also - adjust the braking system (ref.to page 44) check linkage) - brake linings not run-in - apply the handbrake very lightly and drive slowly about 1-2 miles - brake linings "glazed", dirty or polluted by oil...
  • Page 73 DINO 180XT CAUSE REMEDY 23. Ball coupling does not lock itself onto the ball - ball bearing cup dirty - clean and lubricate - ball on towing vehicle too big - measure the ball. According to DIN74058 the ball diameter should be between 50 mm and 49,5 mm.

  • Page 74: Hydraulic System, General Information

    DINO 180XT HYDRAULIC SYSTEM, GENERAL INFORMATION To be able to carry out any movement two solenoid valves must always be actuated. Thus: OUTRIGGERS/ BOOM - actuator valve and boom (PROPO) - actuator valve and telescope - actuator valve and platform...

  • Page 75: Electric Components' Function

    DINO 180XT ELECTRIC COMPONENTS' FUNCTION LOWER CONTROL PANEL (PK), RELAYS RL2: AUXILIARY RELAY FOR INTERRUPTING BOOM-DOWN FUNCTION. THE SAFETY LIMIT SWITCH RK4 CONTROLS THE RELAY RL2. RELAY DELAY IS INDUCED BY THE PROCESSOR CARD POTENTIOMETER TR2 (PICTURE ENCLOSED). TIME IS READY-SET AT ABOUT 0,6 SEC.
  • Page 76 DINO 180XT RL22: WHEN RK4 HAS ACTUATED (RED LIGHT ON) THE RL22 AUXILIARY RELAY PREVENTS THE BOOM FROM DESCENDING WHEN JUMPING ABOUT ON THE PLATFORM. DELAY TIME, (APPR. 2,5 S.) FOR THE PROSESSOR BOARD POTENTIOMETER TR3 READY-SET (PICTURE ENCLOSED). RL24: AUXILIARY RELAY, HYDRAULIC UNIT OFF.

  • Page 77: Lower Control Panel (Pk), Switches

    DINO 180XT LOWER CONTROL PANEL (PK), SWITCHES S1: SELF LOCKING MANUALLY RESET EMERGENCY STOP -SWITCH, STOPS ALL FUNCTIONS WITH THE EXCEPTION OF EMERGENCY DESCENT AND SIGNAL HORN. S2: NON-LOCKING STARTING SWITCH S3: NON-LOCKING STOP SWITCH S13: NON-LOCKING START EMERGENCY DESCENT SWITCH.

  • Page 78: Upper Control Panel (Ok), Relays

    DINO 180XT UPPER CONTROL PANEL (OK), RELAYS RL13: CONTROL RELAY FOR GREEN (H1) AND RED (H2) LED SIGNAL LIGHTS. RELAY RL13 IS CONTROLLED BY SAFETY LIMIT SWITCH RK4 RL14 AND RL15: FUNCTION RELAYS CONTROLLED BY THE INDUCTIVE LIMIT SWITCHES RK9 AND RK10 FOR CONTROLLING THE PLATFORM TURNING (RIGHT-...

  • Page 79: Limit Switches

    DINO 180XT LIMIT SWITCHES OUTRIGGER SAFETY LIMIT SWITCHES (RK11, RK12, RK13 AND RK14) PREVENTS BOOM FUNCTIONS IF THERE IS A LOAD ON THE TYRES. RK3: PREVENTS THE OUTRIGGER FUNCTIONS WHEN THE BOOM IS NOT SET DOWN ONTO THE SUPPORT (IN TRANSPORT POSITION) AS WELL AS DRIVING DEVICE FUNCTIONING (CONTROLS RELAY RL30) RK4: SAFETY LIMIT SWITCH FOR THE REACH AREA.

  • Page 80: Other Markings

    DINO 180XT OTHER MARKINGS F4: PROPO -CONTROL BOARD FUSE 1,6A F5: JOYSTICK CONTROL FUSE 1,6A SPV1: MAIN POWER SWITCH CONNECTS - BREAKS BATTERY (-) CONNECTION. Q1: CONTROL FUNCTION SELECTOR SWITCH. I = SUPPORT OUTRIGGERS, II = PLATFORM CONTROL PANEL, III = CHASSIS CONTROL PANEL ÄM1: SIGNAL HORN...

  • Page 81: Propo -Control Card

    DINO 180XT PROPO -CONTROL CARD (48.2127) 1. MAXIMUM MOVEMENT SPEED 2. MINIMUM START-UP 3. FUNCTIONAL DELAY (0) 4. FREQUENCY Propo-control card is adjusted before regulating potentiometers TR1, TR2 and TR3 (Exist on the mainboard 48.2197). (Propo -control card has been adjusted at the factory.) Instructions for the setting of the propo card IN FOLLOWING ORDER: 2.

  • Page 82: Mainboard

    DINO 180XT MAINBOARD Regulating potentiometers BOOM LOWERING MOVEMENT SPEED (MUST BE FIRST ADJUSTED; IT HAS ALSO AN EFFECT ON LIFTING ARMS DOWN -MOVEMENT) MOVEMENT SPEEDS FOR LIFTING ARMS MOVEMENT SPEEDS FOR CHASSIS CONTROL PANEL Setting instructions: 10 rotations to the right from minimum n. 65 k...

  • Page 83: Processor Card

    DINO 180XT PROCESSOR CARD TR1 = RL19 0-5 s. 1,2 s. TR2 = RL2 0-5 s. 0,6 s. TR3 = RL22 0-5 s. 2,5 s. TR4 = RL4 0-5 s. 1,2 s. TR5 = RL25 0-25 s. standard 5 s.

  • Page 84: Electric Components

    DINO 180XT ELECTRIC COMPONENTS 18154 – 18222, 18226, 18228 REF. PART NR. DESCRIPTION 48.2194 BATTERY DL8.058 (110VAC: 48.2221) THERMAL RELAIS 48.647 10A FUSE 48.3023 16A FUSE 48.640 10A FUSE F4, F5 48.3030 1,6A FUSE 48.3036 + 48.1034 AUTOMATIC FUSE 48.640 10A FUSE 48.2204...

  • Page 85: Electric Schema; 230Vac

    DINO 180XT ELECTRIC SCHEMA; 230VAC 18004  Colours Black Yellow Blue Green White Brown Orange Light blue Light green Pink Grey...

  • Page 86: Electric Schema; 110/ 230Vac

    DINO 180XT ELECTRIC SCHEMA; 110/ 230VAC 18094 ...

  • Page 87: Electric Schema; 110Vac

    DINO 180XT ELECTRIC SCHEMA; 110VAC 18004  Colours Colours Black Black Yellow Yellow Blue Blue Green Green White White Brown Brown Orange Orange Light blue Light blue Light green Light green Pink Pink Grey Grey...

  • Page 88: Electric Schema; Drive Unit, Operating Panel

    DINO 180XT ELECTRIC SCHEMA; DRIVE UNIT, OPERATING PANEL Colours Black Yellow Blue Green White Pyöriväliitin Brown Roterande adapter Orange Drehdurchführung Light blue Rotating adapter Light green Pink Grey...

  • Page 89: Electric Schema; Drive Unit, Remote Control

    DINO 180XT ELECTRIC SCHEMA; DRIVE UNIT, REMOTE CONTROL Värit Colours musta Black keltainen Yellow sininen Blue vihreä Green punainen valkoinen White ruskea Brown oranssi Orange vaalean sininen Light blue vaalean vihreä Light green vaalean punainen Pink harmaa Grey...

  • Page 90: Electric Schema; 12Vdc, (230Vac, Petrol/ Gasoline Aggreg.)

    DINO 180XT ELECTRIC SCHEMA; 12VDC, (230VAC, PETROL/ GASOLINE AGGREG.) 18154 – 18222, 18226, 18228...

  • Page 91: Electric Schema; 12Vdc, (110/ 230Vac, Petrol/Gasoline Aggr.)

    DINO 180XT ELECTRIC SCHEMA; 12VDC, (110/ 230VAC, PETROL/GASOLINE AGGR.) 18154 – 18222, 18226, 18228...

  • Page 92: Electric Schema; 12Vdc, (230Vac, Diesel Aggregate)

    DINO 180XT ELECTRIC SCHEMA; 12VDC, (230VAC, DIESEL AGGREGATE) 18154 – 18222, 18226, 18228...

  • Page 93: Electric Schema; 12Vdc, (110/ 230Vac, Diesel Aggregate)

    DINO 180XT ELECTRIC SCHEMA; 12VDC, (110/ 230VAC, DIESEL AGGREGATE) 18154 – 18222, 18226, 18228...
  • Page 94 DINO 180XT Notes...

  • Page 95: Electric Schema; Petrol/ Gasoline Aggregate

    DINO 180XT ELECTRIC SCHEMA; PETROL/ GASOLINE AGGREGATE 18069 ...

  • Page 96: Electric Schema; Diesel Aggregate

    DINO 180XT ELECTRIC SCHEMA; DIESEL AGGREGATE...
  • Page 97 DINO 180XT ELECTRIC SCHEMA; DIESEL AGGREGATE...

  • Page 98: Hydraulic Components 230Vac

    DINO 180XT HYDRAULIC COMPONENTS 230VAC 18154  Ref. Part nr. Description 47.816 Electric motor 47.2049 Hydraulic pump 47.171 Pressure filter 47.2749 Pressure limiting valve 47.378 Solenoid valve 47.2630 Solenoid valve 47.2713 Solenoid valve 47.2750 Pressure limiting valve 47.2731 Solenoid valve 47.2733...

  • Page 99: Hydraulic Scheme 230Vac

    DINO 180XT HYDRAULIC SCHEME 230VAC 18001 ...

  • Page 100: Hydraulic Components 110Vac

    DINO 180XT HYDRAULIC COMPONENTS 110VAC 18154  Ref. Part. nr. Description (GB 47.815) (US 47.812) Electric motor (GB 47.2054) (US 47.2051) Hydraulic pump 47.171 Pressure filter 47.2749 Pressure limiting valve 47.378 Solenoid valve 47.2630 Solenoid valve 47.2713 Solenoid valve 47.2750 Pressure limiting valve 47.2731...

  • Page 101: Hydraulic Scheme 110Vac

    DINO 180XT HYDRAULIC SCHEME 110VAC 18001 ...
  • Page 102 DINO 180XT Notes...
