Preface
Welcome to the world of Hytera and thank you for purchasing this product. This manual includes a description of
the functions and step-by-step procedures for use. To avoid personal injury or property loss caused by incorrect
operation, please carefully read the Safety Information Booklet before use and visit www.hyterapush2talk.com for
more information.
This manual is applicable to the following product:
TF-612 Portable Radio

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TF-612 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hytera TF-612

Summary of Contents for Hytera TF-612

  • Page 1 Preface Welcome to the world of Hytera and thank you for purchasing this product. This manual includes a description of the functions and step-by-step procedures for use. To avoid personal injury or property loss caused by incorrect operation, please carefully read the Safety Information Booklet before use and visit www.hyterapush2talk.com for more information.
  • Page 2 Copyright Information Hytera is the trademark or registered trademark of Hytera Communications Corporation Limited (the Company) in the People's Republic of China (PRC) and/or other countries or areas. The Company retains the ownership of its trademarks and product names. All other trademarks and/or product names that may be used in this manual are properties of their respective owners.
  • Page 3 The antenna should be kept away from the face and eyes. When worn on the body, always place the radio in a Hytera-approved holder, holster, case, or body harness or by use of the correct clip for this product. Use of non-approved accessories may result in exposure levels which exceed the...
  • Page 4 Use of non-approved antennas, batteries, and accessories causes the radio to exceed the FCC RF exposure guidelines. Contact your local dealer for the optional accessories of the product. IC Statement The device has been tested and complies with SAR limits, users can obtain Canadian information on RF exposure and compliance.

  • Page 5: Table Of Contents

    7.9 Keypad Tone ........................... 10 7.10 Room Monitor ..........................10 7.11 Sleep Level ........................... 11 7.12 Stopwatch and Timer ........................11 7.13 Weather Mode (TF-612 only)......................12 7.14 Battery Save ..........................13 7.15 Low Battery Alert ........................... 13 7.16 Time-out Timer (TOT) ........................13 7.17 Auto Squelch ..........................

  • Page 7: Packing List

    1. Packing List Please unpack carefully and check if all items listed below are received. If any item is missing or damaged, please contact your local dealer. Item Quantity (PCS) Item Quantity (PCS) Radio Charger Battery Power Adapter Belt Clip Documentation Kit Lanyard...

  • Page 8: Product Controls

    2. Product Controls TF-612...

  • Page 9: Before Use

    3. Before Use 3.1 Inserting Batteries You can use the Ni-MH battery provided by us or three AA alkaline batteries prepared by yourself. To insert batteries, do as follows: 1. Slide the battery latch to the unlock position and then remove the battery cover. 2.

  • Page 10: Attaching The Belt Clip

    3.3 Attaching the Belt Clip To attach the belt clip, do as follows: 1. Align the rails on the belt clip with the groove on the battery. 2. Press the belt clip downwards into place.

  • Page 11: Basic Operations

    4. Basic Operations 4.1 Turning the Radio On/Off To turn the radio on or off, rotate the On-Off knob clockwise or counter-clockwise until you hear a click. 4.2 Adjusting the Volume To increase or decrease the volume, rotate the Volume Control knob clockwise or counter-clockwise after turning on the radio.

  • Page 12: Lcd Icons

    5. LCD Icons CTCSS/CDCDS Code Channel Number Icon Description Icon Description Battery Room Monitor Radio Mode Battery Save Silent Mode Talk End Tone Keypad Tone Call Tone Keypad Lock Transmit Scan Receive Vibra Mode High Power Low Power Weather Mode Weather Alert...

  • Page 13: Call Services

    6. Call Services 6.1 Initiating a Call You can initiate calls to other radios on the same channel and CTCSS/CDCSS code as yours. To initiate a call, do as follows: 1. Select a channel and a CTCSS/CDCSS code. 2. Hold the radio vertically 2.5 to 5 cm from your mouth. 3.

  • Page 14: Supplementary Features

    7. Supplementary Features 7.1 Keypad Lock The Keypad Lock feature allows you to lock the keypad to avoid accidental operations when the radio is not in use. In the keypad lock mode, you can initiate calls and turn the radio on or off. To lock or unlock the keypad, press and hold the Keypad Lock key until appears or disappears on the screen.

  • Page 15: Talk End Tone

    Setting the call tone to OFF turns off the Call Tone feature. c. Press the PTT key to confirm your selection. 2. Press the Call Tone key to transmit the call tone. 7.5 Talk End Tone The Talk End Tone feature allows you to send a tone when you release the PTT key. This tone notifies others that you have finished your talk.

  • Page 16: Vibra Mode

    this mode, the backlight of the radio is turned on and on the screen flashes when the radio receives calls. When the call disappears, the backlight becomes off and the icon still flashes indicating missed calls. To turn on or off this feature, do as follows: 1.

  • Page 17: Sleep Level

    To turn on or off this feature, do as follows: 1. Press the Menu key for nine consecutive times until the radio displays 2. Press the Up or Down key to select L1, L2, or L3 to turn on the feature, or select OFF to turn off the feature. L1, L2, and L3 mean different sensitivity levels, as shown below: L1: low sensitivity applicable to noisy environments L2: medium sensitivity applicable to common environments...

  • Page 18: Weather Mode (Tf-612 Only)

    6. To turn off the feature, press the PTT key or the Menu key. 7.13 Weather Mode (TF-612 only) The Weather Mode feature allows you to listen to weather reports and set the radio to alert you to extreme weather broadcasted by the United States National Oceanic and Atmospheric Administration (NOAA) Weather Radio.

  • Page 19: Battery Save

    To turn the Weather Alert feature on or off, do as follows: 1. In the weather mode, press the Menu key twice. The radio displays and the current setting flashes. 2. Press the Up or Down key to select ON or OFF. 3.

  • Page 20: Troubleshooting

    8. Troubleshooting Phenomena Analysis Solution The battery may be installed Remove and reattach the battery. improperly. The radio cannot be The battery power may run out. Recharge or replace the battery. turned on. The battery may suffer from poor contact caused by dirtied or Clean the battery contacts or replace the battery.
  • Page 21 Phenomena Analysis Solution underground areas. It could be the result of external Stay away from equipment that may cause disturbance (such interference. electromagnetic interference). You cannot use the The keypad may fail to function Restart the radio. keys. temporarily. The LCD does not The LCD may fail to work display any Restart the radio.

  • Page 22: Optional Accessories

    9. Optional Accessories Contact your local point of purchase for the optional accessories used with the product. Use the approved accessories only. We will not be liable for any loss or damage arising out of the use of any unauthorised accessories.

  • Page 23: Channels And Frequencies

    Channels and Frequencies Channel Frequency (MHz) Description Channel Frequency (MHz) Description 462.5625 GMRS/FRS 467.6625 462.5875 GMRS/FRS 467.6875 462.6125 GMRS/FRS 467.7125 462.6375 GMRS/FRS 462.5500 GMRS 462.6625 GMRS/FRS 462.5750 GMRS 462.6875 GMRS/FRS 462.6000 GMRS 462.7125 GMRS/FRS 462.6250 GMRS 467.5625 462.6500 GMRS 467.5875 462.6750 GMRS 467.6125...
  • Page 24 When the radio is transmitting on GMRS frequencies, that operation on GMRS frequencies requires an FCC license and such operation is subject to additional rules specified in 47 C.F.R. Part 95. The information listed above provides the user with information needed to make him or her aware of a RF exposure, and what to do to assure that this radio operates within the FCC exposure limits of this radio.
