KD-G541
Maximum Power Output
Continuous Power Output (RMS) Front/Rear
Load Impedance
Tone Control Range
Frequency Response
Signal-to-Noise-Ratio
Line-Out Level/Impedance
Output Impedance
Subwoofer-Out Level/Impedance
Other Terminal
Frequency Range
FM Tuner
MW Tuner
LW Tuner
Type
Signal Detection System
Number of Channels
Frequency Response
Dynamic Range
Signal-to-Noise Ratio
Wow and Flutter
MP3 Decoding Format
(MPEG1/2 Audio Layer 3)
WMA (Windows Media® Audio)
Decoding Format
Power Requirement
Grounding System
Allowable Operating Temperature
Dimensions (W × H × D) (approx.) Installation Size
Mass
Design and specifications are subject to change without notice.
1-2 (No.MA384<Rev.001>)

SPECIFICATION

AUDIO AMPLIFIER SECTION
Front/Rear
Bass
Middle
Treble
TUNER SECTION
FM
AM
Usable Sensitivity
50 dB Quieting Sensitivity
Alternate Channel Selectivity (400 kHz) 65 dB
Frequency Response
Stereo Separation
Sensitivity/Selectivity
Sensitivity
CD PLAYER SECTION
Max. Bit Rate
Max. Bit Rate
GENERAL
Operating Voltage
Panel Size
50 W per channel
19 W per channel into 4 Ω 40 Hz to 20 000 Hz at no more than 0.8%
total harmonic distortion.
4 Ω (4 Ω to 8 Ω allowance)
±12 dB at 60 Hz
±12 dB at 1 kHz
±12 dB at 7.5 kHz
40 Hz to 20 000 Hz
70 dB
2.5 V/20 kΩ load (full scale)
1 kΩ
2.5 V/20 kΩ load (full scale)
CD changer jack AUX (auxiliary) input jack Steering wheel remote input
87.5 MHz to 108.0 MHz
(MW) 522 kHz to 1 620 kHz
(LW) 144 kHz to 279 kHz
11.3 dBf (1.0 µV/75 Ω)
16.3 dBf (1.8 µV/75 Ω)
40 Hz to 15 000 Hz
30 dB
20 µV/35 dB
50 µV
Compact disc player
Non-contact optical pickup (semiconductor laser)
2 channels (stereo)
5 Hz to 20 000 Hz
96 dB
98 dB
Less than measurable limit
320 kbps
320 kbps
DC 14.4 V (11 V to 16 V allowance)
Negative ground
0°C to + 40°C
182 mm × 52 mm × 160 mm
188 mm × 58 mm × 13 mm
1.4 kg (excluding accessories)
