SCHEMATIC DIAGRAMS
Contents
Block diagram
Standard schematic diagrams
Printed circuit boards
CD RECEIVER
KD-S595
CD-ROM No.SML200301
LOUD
SEL
COPYRIGHT
2003 VICTOR COMPANY OF JAPAN, LTD.
DIR E C T
T R A C K A C C E S S
U --------------------- Other Areas
2-1
2-2
2-5,6
KD-S595
Area suffix
No.49768SCH
2003/01
Advertisement
Related Manuals for JVC KD-S595
Summary of Contents for JVC KD-S595
- Page 1 KD-S595 SCHEMATIC DIAGRAMS CD RECEIVER KD-S595 CD-ROM No.SML200301 DIR E C T T R A C K A C C E S S LOUD Area suffix U --------------------- Other Areas Contents Block diagram Standard schematic diagrams Printed circuit boards 2-5,6 No.49768SCH...
- Page 2 KD-S595 Safety precaution Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. Please use enough caution not to see the beam directly or touch it in case of an...
- Page 3 KD-S595 Block diagram CJ701 TU701 CJ321 TU.LCH FM/AM LINE OUT TU.RCH TUNER SW1,SW2,PSW MONO FM/AM LM,MSW TRV,TVD, FM.OSC ECM,ECS, IC321 SPINDLE+ IC301 CD.SENSE KICK,TRD,FOD IC561 IC541 OUT LF POWER SPINDLE- E.VOL POSITION SET /CD.RESET SERVO S.METER OUT RF FEED+ STATUS SWITCH &...
- Page 4 KD-S595 KD-S595 Standard schematic diagrams Main amplifier section TU701 QAU0281-001 CJ701 QNB0100-002 Q861 L701 4.7u UN2111-X MUTE R201 R703 R101 R701 R333 R334 CJ321 D332 R336 2.2k Q332 2SD1781K/QR/-X Q791 1SS355-X 2SB1197K/QR/-X R735 R702 R704 D333 R436 2.2k Q432 1.5k...
- Page 5 KD-S595 CD servo control section D551 1A3G-T1 C552 C551 0.01 220/10 C543 0.033 R596 8.2k C541 IC561 22/16 MN6627482WA Q541 2SA1706/ST/-T C540 CD8V CD.RESET STATUS KICK IC541 SUBQ C570 SQCK LA6589H-X 0.022 TLOCK FLOCK C574 CD.SENSE FBAL TBAL 0.01 MDATA...
- Page 6 KD-S595 KD-S595 LCD & Key control section IC602 RPM6938-SV4 C611 0.012 C612 R662 4.7/6.3 D644 UDZS6.2B-X CJ601 VMC0355-001 R661 LCD1 ILL-10V QLD0210-002 REMOCON Main amplifier section CN801 LCD.CLK LCD.SO IC601 LCD.CE KEY0 KEY1 KEY2 R605 R604 R603 R602 R601 KEY0 1.2k...
- Page 7 KD-S595 Printed circuit boards Main board Reverse side D904 R862 C915 C901 R861 L901 R911 D869 IC901 D867 D861 C996 R904 C902 Q332 C862 D901 C910 C905 R903 R336 R902 C331 C906 D903 C303 B898 D332 C909 C302 R909 CJ701...
- Page 8 KD-S595 Front board Forward side D620 S619 D615 R616 R611 S604 D603 R610 D601 R617 S620 S603 R604 D616 D604 R638 R602 D731 R639 R615 R601 R614 S602 S607 R606 S605 D732 R637 S617 R636 D602 D605 LCD1 S618 R605...
- Page 9 KD-S595 < M E M O >...
- Page 10 KD-S595 VICTOR COMP ANY OF JAP AN, LIMITED AV & MULTIMEDIA COMPANY 10-1,1Chome,Ohwatari-machi,Maebashi-city,371-8543,Japan Printed in Japan (No.49768SCH) 2003/01...
- Page 11 KD-S595 PARTS LIST [ KD-S595 ] * All printed circuit boards and its assemblies are not available as service parts. Area suffix U ---------------------- Other Areas - Contents - 3- 2 Exploded view of general assembly and parts list (Block No.M1) 3- 4 CD mechanism assembly and parts list (Block No.MB)
- Page 12 KD-S595...
- Page 13 KD-S595 Parts list (General assembly) Block No. M1MM Item Description Parts number Parts name Q'ty Area --------------------- CD MECHA GE10043-205A TOP CHASSIS GE40135-001A EARTH PLATE GE30568-006A HEAT SINK GE30393-002A BOTTOM COVER FSMA3004-203 INSULATOR QYSDST2604Z SCREW 3 CHASSIS+CD MECH FSKZ4005-001 SCREW...
- Page 14 KD-S595 CD mechanism assembly and parts list Block No. Grease TNG-87 TN-2001-1011 GP-501MK CFD-005Z GP-501A...
- Page 15 KD-S595 Parts list (CD mechanism) Block No. MBMM Item Parts number Parts name Q'ty Description Area 30320101T FRAME 30320102T TOP COVER DANPER F 30320115T 30320116T DANPER R 303205505T CHASSIS RIVET 303205503T CHANGE P. RVT A 303205301T CLAMPER ASS'Y 303205302T SPINDLE MOTOR A...
- Page 16 KD-S595 Parts list (CD mechanism) Block No. MBMM Item Parts number Parts name Q'ty Description Area 30321103T LOADING GEAR 3 30321104T LOADING GEAR 4 30321105T LOADING GEAR 5 30321106T LOADING GEAR 6 30321107T LOADING GEAR 7 30321111T ROLLER GUIDE 30321114T...
- Page 17 KD-S595 Electrical parts list (Main board) Block No. 01 Item Parts number Parts name Remarks Area Item Remarks Parts number Parts name Area C 101 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V C 520 NDC31HJ-470X C CAPACITOR C 151 NCB31HK-102X C CAPACITOR...
- Page 18 KD-S595 Electrical parts list (Main board) Block No. 01 Item Parts number Parts name Remarks Area Item Parts number Parts name Remarks Area C 906 NCB31EK-104X C CAPACITOR Q 793 UN2211-X TRANSISTOR C 907 NCB31HK-103X C CAPACITOR Q 861 UN2111-X...
- Page 19 KD-S595 Electrical parts list (Main board) Block No. 01 Item Parts number Parts name Remarks Area Item Parts number Parts name Remarks Area R 547 NRSA63J-224X MG RESISTOR R 829 NRS181J-473X MG RESISTOR R 548 NRSA63J-562X MG RESISTOR R 830...
- Page 20 KD-S595 Electrical parts list (Front board) Block No. 02 Item Parts number Parts name Remarks Area Item Parts number Parts name Remarks Area C 601 NCB31HK-223X C CAPACITOR R 655 NRSA63J-103X MG RESISTOR C 602 NCS31HJ-681X C CAPACITOR R 656...
- Page 21 KD-S595 < M E M O > 3-11...
- Page 22 KD-S595 Packing materials and accessories parts list Block No. Block No. A1~A4 KIT : A5~A9 3-12...
- Page 23 KD-S595 Parts list (Packing) Block No. M3MM Item Parts number Parts name Q'ty Description Area FSPG4002-001 POLY BAG 1 INST.BOOK POLY BAG QPA00801205 QPA01003003 POLY BAG 1 FOR HARD CASE FSYH4036-068 SHEET QPC03004315P POLY BAG 1 SET(260X440X0.0 GE30664-001A MOUNT BOTL...
