Chapter 1
1. 2. 2.

The Back Panel

The following parts (view from left to right) are located on the back panel.
Item
Power Port
Power On/Off Button
Reset Button
USB 2.0 Port
Internet Port
Ethernet Ports (1/2/3/4)
WPS/Wi-Fi On/Off
Button
Antennas
For connecting the router to a power socket via the provided power adapter.
Press this button to power on or off the router.
Press and hold this button for more than 5 seconds to reset the router to its
factory default settings.
For connecting to a USB 2.0 device or a USB 2.0 printer.
For connecting to a DSL/Cable modem, or an Ethernet jack.
For connecting your wired devices to the router.
Press and hold this button for less than 5 seconds to enable the WPS
function.
Press and hold this button for about 2 seconds to turn on or off the wireless
function of your router.
Used for wireless operation and data transmit. Upright them for the best
Wi-Fi performance.
Get to Know About Your Router
Description
4
