Planar QE Series RS232
User Manual

Advertisement

Table of Contents
loading

Related Manuals for Planar QE Series

Summary of Contents for Planar QE Series

  • Page 1 Planar QE Series RS232 User Manual...
  • Page 2 Planar employees. When you purchase a Planar product, you get more than a display, you get the service and support you need to maximize your investment. To find the latest warranty and service information regarding your Planar product, please visit http://www.planar.com/support...

  • Page 3: Table Of Contents

    Using the QE Series USB Connection ........
  • Page 4 Planar QE Series RS232 User Manual...

  • Page 5: Rs232 Communication

    RS232 control is not necessary for operation, but is a convenient way to control Planar® QE Series displays from a computer at a distance. Most things you can do with the remote, you can do with RS232 commands. Plus, you can send inquiries to the displays and find out the current settings and values.

  • Page 6: Rs232 Protocol

    • ‘^NAK’ indicates that the message is a negative acknowledgment (NAK) to a command. This indicates that the command was received but cannot be processed at this time. • [No operator] denotes an action. In this case, there’s no operator and no operand. Planar QE Series RS232 User Manual...

  • Page 7: Protocol Encoding

    ‘;’ termination character instead of [CR]. The response uses the same termination character. 200=100 [CR] 200:100 [CR] “200” is the numeric command code for “BRIGHTNESS” brightness+ [CR] BRIGHTNESS:101 [CR] Increments the current Brightness value Planar QE Series RS232 User Manual...
  • Page 8 The name will appear on the remote and \\” and \\” monitor as Name containing “ and \ power.on.delay = .1 POWER.ON.DELAY:0.1 Example of a fixed point operand. Sets the Power On Delay to 0.1 seconds. Planar QE Series RS232 User Manual...

  • Page 9: Rs232 Codes

    • ‘!’ in the Operators column indicates that the command accepts the execute operator, which uses no operator symbol. The ‘!’ symbol is not included in the command. • Many commands have modifiers or operands called “OPS”. These refer to the ContentSmart input on the display. Planar QE Series RS232 User Manual...
  • Page 10 4 = BLUE.X 5 = BLUE.Y 6 = CYAN.X 7 = CYAN.Y MAGENTA.X MAGENTA.Y 10 = YELLOW.X 11 = YELLOW.Y 12 = WHITE.X 13 = WHITE.Y [None = Set all 14 values at once] Planar QE Series RS232 User Manual...
  • Page 11 12 = WHITE.X 13 = WHITE.Y Allow Pop OSD.ALLOW. 1300 =?+- 0 = NO OSD.ALLOW.POPUP=YES See Main -> Advanced POPUP 1 = YES OSD.ALLOW.POPUP:YES Settings -> Menus and Messages Messages -> Allow Pop Up Messages Planar QE Series RS232 User Manual...
  • Page 12 INTENSITY BACKLIGHT.INTENSITY:75 Settings -> Backlight -> Backlight Intensity Balance AUDIO.BALANCE 1000 =?+- 0-100 AUDIO.BALANCE=50 See Main -> Audio -> Balance AUDIO.BALANCE:50 Bass AUDIO.BASS 1001 =?+- 0-100 AUDIO.BASS=50 See Main -> Audio -> Bass AUDIO.BASS:50 Planar QE Series RS232 User Manual...
  • Page 13 0 = ZONE.1 COLOR(ZONE.1)=50 Color 1 = ZONE.2 COLOR(ZONE.1):50 2 = ZONE.3 3 = ZONE.4 [For the current zone] 253 = COLOR=55 ALL.INPUT COLOR:55 254 = ALL 254 = ALL.ZONE 255 = CURRENT [None = CURRENT] Planar QE Series RS232 User Manual...
  • Page 14 Information -> Image [Reading the actual Color Space for the ALL.ZONE current zone] Information -> Color Space. 255 = COLORSPACE(CURRENT, ACTUAL)? CURRENT COLORSPACE(CURRENT ACTUAL):RGB Mod 2: Value Type 0 = SETTING 1 = ACTUAL Planar QE Series RS232 User Manual...
  • Page 15 180 = 180 ROTATE(ZONE.1):90 2 = ZONE.3 270 = 270 3 = ZONE.4 [For the current zone] 253 = ROTATE=NONE ALL.INPUT ROTATE:NONE 254 = ALL 254 = ALL.ZONE 255 = CURRENT [None = CURRENT] Planar QE Series RS232 User Manual...
  • Page 16 [None = [Write the default gateway for static IP] STATIC (for IPV4.NETMASK(STATIC)="192.168.12.1" writes only] IPV4.NETMASK(STATIC):"192.168.12.1" DHCP NETWORK.DHCP 1207 0 = OFF NETWORK.DHCP=ON See Main -> Advanced 1 = ON NETWORK.DHCP:ON Settings -> Network -> DHCP Planar QE Series RS232 User Manual...
  • Page 17 [Read the current DNS server 2 value] Selects a secondary DNS [None = NETWORK.DNS2? server Current (for NETWORK.DNS2:"172.16.0.191" reads only] [None = [Write the DNS server 2 for static IP] STATIC (for NETWORK.DNS2(STATIC)="8.8.4.4" writes only] NETWORK.DNS2(STATIC):"8.8.4.4" Planar QE Series RS232 User Manual...
  • Page 18 ERROR.LOG(1):"Wed Sep 16 13:39:33 2015 - occurred in the system. Entry 1-65535 CRIT- Power supply 2 issue" #1 is the most recent. An empty string returned means that there are no more error log entries after that entry. Planar QE Series RS232 User Manual...
  • Page 19 ALL.ZONE Red Gain: 0-200 255 = Green Gain: 0- CURRENT [None = Blue Gain: 0-200 CURRENT] Mod 2: Color 0 = RED 1 = GREEN 2 = BLUE 255 = ALL [None = ALL] Planar QE Series RS232 User Manual...
  • Page 20 No Modifiers\ following command: 1 Operand(s)\ HELP(FIRST)? Operand #1: Unsigned Integer\ DISABLE 0\ Then enter the following ENABLE 1\ command continuously until it OFF 0\ returns NAK: HELP(NEXT)? YES 1\ FALSE 0\ TRUE 1\ " Planar QE Series RS232 User Manual...
  • Page 21 Mod 2: Parameter 0 = HACTIVE 1 = VACTIVE 2 = PCLK 3 = HTOTAL 4 = VTOTAL 5 = VREFRESH HREFRESH INTERLACE VFIELDRATE VREFRESH.X. 10 = COLORDEPTH 11 = TMDS [None = ALL] Planar QE Series RS232 User Manual...
  • Page 22 See Main -> Inputs and Views -> Multi-Source View -> Advanced Layouts Local LOCAL.DIMMING 1415 =?+- 0 = OFF LOCAL.DIMMING=ON See Main -> Advanced Dimming 1 = ON LOCAL.DIMMING:ON Settings -> Backlight -> Local Dimming Planar QE Series RS232 User Manual...
  • Page 23 [For Zone 1] See IR remote control keys 0 = ZONE.1 SOURCE.NEXT(ZONE.1) ZONE 1/2/3/4 1 = ZONE.2 SOURCE.NEXT(ZONE.1)@ACK 2 = ZONE.3 3 = ZONE.4 [For the current zone] 254 = ALL SOURCE.NEXT 255 = SOURCE.NEXT@ACK CURRENT Planar QE Series RS232 User Manual...
  • Page 24 ALL.ZONE Red Offset: 0- 255 = CURRENT Green Offset: 0- [None = Blue Offset: 0- CURRENT] Mod 2: Color 0 = RED 1 = GREEN 2 = BLUE 255 = ALL [None = ALL] Planar QE Series RS232 User Manual...
  • Page 25 1 = ON PIXEL.ORBIT:ON Settings -> System Settings -> Pixel Orbit Power On POWER.ON.DELAY 1420 =?+- Unsigned fixed POWER.ON.DELAY=1.4 See Main -> Advanced Delay point POWER.ON.DELAY:1.4 Settings -> Power -> Power On 0.0-10.0 Delay Planar QE Series RS232 User Manual...
  • Page 26 0 = TURN.ON [Change the action for event 3 to Turn On] See Main -> Advanced Action 1-20 1 = TURN.OFF SCHEDULE.ACTION(3)=TURN.ON Settings -> Schedule -> Set 3 = PANEL. SCHEDULE.ACTION(3):TURN.ON Event 1-20 -> Action BRIGHTNESS Planar QE Series RS232 User Manual...
  • Page 27 1227 0 = NONE NETWORK.SMTP.AUTHENTICATION=AUTO See Remote Monitoring Authentica- AUTHENTICATION 1 = AUTO NETWORK.SMTP.AUTHENTICATION:AUTO Software -> Notifications -> tion 2 = PLAIN Authentication SCRAM_SHA1 4 = CRAM_MD5 DIGEST_MD5 6 = LOGIN 7 = NTLM Planar QE Series RS232 User Manual...
  • Page 28 If no signal 2 = ZONE.3 60Hz" is detected in that zone, the 3 = ZONE.4 string will read “Searching” or 255 = [For the current zone] “No Signal”. CURRENT SOURCE.MESSAGE? [None = SOURCE.MESSAGE:"Searching" CURRENT] Planar QE Series RS232 User Manual...
  • Page 29 Test Email NETWORK.SMTP. 1229 Event NETWORK.SMTP.TEST(SOURCE.LOST) See Remote Monitoring TEST 0 = POWER. NETWORK.SMTP.TEST(SOURCE.LOST)@ACK Software -> Notifications -> STATE. Test Email CHANGED 1 = ERROR. OCCURRED 2 = SOURCE. DETECTED SOURCE.LOST 4 = SOURCE. SELECTED Planar QE Series RS232 User Manual...
  • Page 30 8 = AUGUST 9 = SEPTEMBER 10 = OCTOBER 11 = NOVEMBER 12 = DECEMBER Time - String TIME.STRING 1103 String TIME.STRING? See Main -> Advanced TIME.STRING:"2015-09-01 13:21" Settings -> Schedule -> Date / Time Planar QE Series RS232 User Manual...
  • Page 31 See Main -> Information -> BUILD.INFO(PKG.VERSION):"1.0.600" System Information VERSION.SCP 3 = DATE.VP VERSION.VP SRC.INFO.VP 6 = VERSION. HDMI VERSION.FRC 8 = PKG.DATE PKG.VERSION Volume AUDIO.VOLUME 1006 =?+- 0-100 AUDIO.VOLUME=50 See Main -> Audio -> Volume AUDIO.VOLUME:50 Planar QE Series RS232 User Manual...

  • Page 32: Current Zone Layout

    Number button 5 KEY.6 Number button 6 KEY.7 Number button 7 KEY.8 Number button 8 KEY.9 Number button 9 MUTE MUTE Audio mute KEY.0 Number button 0 STDBY.TOGGLE [None] Toggles the power on and off Planar QE Series RS232 User Manual...
  • Page 33 Not used Selects ContentSmart for the current zone WALL VIDEO WALL Not used COLOR COLOR Not used MISC MISC Opens the Image Information menu  ARROW.LEFT Not used  ARROW.RIGHT Not used STAR.STAR Not used Planar QE Series RS232 User Manual...

  • Page 34: Timezone

    UTCM0400.GEORGETOWN.LA.PAZ.MANAUS.SAN.JUAN (UTC-04:00) Georgetown, La Paz, Manaus, San Juan UTCM0330.NEWFOUNDLAND (UTC-03:30) Newfoundland UTCM0300.BRASILIA (UTC-03:00) Brasilia UTCM0300.CAYENNE.FORTALEZA (UTC-03:00) Cayenne, Fortaleza UTCM0300.CITY.OF.BUENOS.AIRES (UTC-03:00) Buenos Aires UTCM0300.GREENLAND (UTC-03:00) Greenland UTCM0300.MONTEVIDEO (UTC-03:00) Montevideo UTCM0300.SALVADOR (UTC-03:00) Salvador UTCM0300.SANTIAGO (UTC-03:00) Santiago UTCM0200.COORDINATED.UNIVERSAL.TIMEM02 (UTC-02:00) Coordinated Universal Time -02 Planar QE Series RS232 User Manual...
  • Page 35 (UTC+02:00) Tripoli UTCP0300.BAGHDAD (UTC+03:00) Baghdad UTCP0300.KUWAIT.RIYADH (UTC+03:00) Kuwait, Riyadh UTCP0300.MINSK (UTC+03:00) Minsk UTCP0300.MOSCOW.ST.PETERSBURG.VOLGOGRAD. (UTC+03:00) Moscow, St. Petersburg, RTZ.2 Volgograd (RTZ 2) UTCP0300.NAIROBI (UTC+03:00) Nairobi UTCP0330.TEHRAN (UTC+03:30) Tehran UTCP0400.ABU.DHABI.MUSCAT (UTC+04:00) Abu Dhabi, Muscat UTCP0400.BAKU (UTC+04:00) Baku Planar QE Series RS232 User Manual...
  • Page 36 (UTC+09:00) Osaka, Sapporo, Tokyo UTCP0900.SEOUL (UTC+09:00) Seoul UTCP0900.YAKUTSK.RTZ.8 (UTC+09:00) Yakutsk (RTZ 8) UTCP0930.ADELAIDE (UTC+09:30) Adelaide UTCP0930.DARWIN (UTC+09:30) Darwin UTCP1000.BRISBANE (UTC+10:00) Brisbane UTCP1000.CANBERRA.MELBOURNE.SYDNEY (UTC+10:00) Canberra, Melbourne, Sydney UTCP1000.GUAM.PORT.MORESBY (UTC+10:00) Guam, Port Moresby UTCP1000.HOBART (UTC+10:00) Hobart UTCP1000.MAGADAN (UTC+10:00) Magadan Planar QE Series RS232 User Manual...
  • Page 37 (UTC+11:00) Solomon Is., New Caledonia UTCP1200.ANADYR.PETROPAVLOVSK.KAMCHATSKY. (UTC+12:00) Anadyr, Petropavlovsk- RTZ.11 Kamchatsky (RTZ 11) UTCP1200.AUCKLAND.WELLINGTON (UTC+12:00) Auckland, Wellington UTCP1200.COORDINATED.UNIVERSAL.TIMEP12 (UTC+12:00) Coordinated Universal Time +12 UTCP1200.FIJI (UTC+12:00) Fiji UTCP1300.NUKU.ALOFA (UTC+13:00) Nuku'alofa UTCP1300.SAMOA (UTC+13:00) Samoa UTCP1400.KIRITIMATI.ISLAND (UTC+14:00) Kiritimati Island Planar QE Series RS232 User Manual...

  • Page 38: Sending Serial Commands Via Usb

    If you’re unsure whether your machine is 32-bit or 64-bit, try both installation programs. If the selected program is for a different architecture, the installer will inform you to use the other installation program. When the Planar USB Driver Installer page opens, click “Next”. Planar QE Series RS232 User Manual...
  • Page 39 Installing the QE Series USB drivers The USB drivers will be automatically installed. When the installation completes, click “Finish”. The USB driver installation process is now complete. Planar QE Series RS232 User Manual...
  • Page 40 USB drivers. The USB flash drive in your accessory kit contains the USB drivers for manual installation. Plug in the USB cable to your computer and to the QE Series panel. Windows will detect the new hardware and attempt to install the drivers on its own.
  • Page 41 Installing the QE Series USB drivers Open the Start menu and select “Control Panel”. Select Hardware and Sound. In the following menu, under Devices and Printers, select “Device Manager”. Planar QE Series RS232 User Manual...
  • Page 42 Installing the QE Series USB drivers In the Device Manager, there will be a “Planar Display” item in the “Other Devices” section. Right-click on Planar Display and select “Update Driver Software”. Follow the steps defined in the Update Driver Software wizard as follows.
  • Page 43 Make sure the “Include subfolders” checkbox is checked. The USB drivers are included on the USB flash drive in the accessory kit; they can also be obtained from http://www.planar.com/support. Use the “Browse” button to locate the directory where the USB drivers are located. Click “Next”.

  • Page 44: Using The Qe Series Usb Connection

    Using the QE Series USB Connection When the installation completes, click “Close”. The USB driver installation process is now complete. Using the QE Series USB Connection Once the USB drivers are installed, the PC will recognize the USB-B connection as a regular serial port.

  • Page 45: Sending Rs232 Commands Via Tcp Or Udp

    Notice the following in the TCP example below using Tera Term: • The IP address is 10.15.0.75 • Port 57 is selected • Service is set to “Other” to indicate that TCP is being used without Telnet or SSH Planar QE Series RS232 User Manual...
  • Page 46 • “444953504C41592E504F5745523D310D” in the Send box is hex for “DISPLAY.POWER=1” Note: Most UDP terminal programs won’t automatically send the [CR] at the end of the command, so the hex command is used to do this manually. Planar QE Series RS232 User Manual...
