Planar Q2 Manual

The portability of the Dome Surgery Review Cart allows you to implement a DICOM-compliant, PACS referral viewing station—
on demand—in any area of a healthcare facility. When it is fully integrated, the cart consists of the computer unit that you
supply and these components:
• Review cart for attaching a computer and two displays
• Dual Dome displays for side-by-side image review
• Display controller and driver
To facilitate integration at your location, Planar has partially assembled the review cart by prerouting power and video cables.
You need only to install the display controller into your computer, attach the computer and the displays to the cart, and
connect the power and video cables. Check the display documentation for safety guidelines on handling the components.

System requirements

Check that the computer unit you are mounting to the cart
meets the requirements of the Dome displays, display
controller and driver, and Dome CXtra software.
Dome P2 or Q2 display using the EX2 display controller
• Intel Pentium 4/Xeon clocked at 2.0 GHz (or faster),
AMD Athlon/Opteron with 2000+ rating (or faster)
• Microsoft Windows XP or Windows 2000
operating system
• AGP 8X/4X bus with full height AGP slot: H 4.2"
• 256 MB system memory (512 MB or more
recommended)
• CD-ROM drive
• 300 Watt (or greater) power supply
Dome CX display using the DX or DX2 display controller
• Intel Pentium 4/Xeon clocked at 2.0 GHz (or faster),
AMD Athlon/Opteron with 2000+ rating (or faster), or
equivalent CPU
• Microsoft Windows XP or Windows 2000
operating system
• Full height half length PCI slot: H 4.2" x L 6.95"
(PCI64/66 slot recommended for maximum
performance)
• 256 MB system memory (512 MB or
more recommended)
• CD-ROM drive
• 200 Watt (or greater) power supply
Computer specifications
Your computer unit must not exceed these specifications:
• Weight – 35 lb (16 kg)
• Size (W x H x D) – 7.5" x 16" x 20"
(190 mm x 406 mm x 508 mm)
Dome Surgery Review Cart
• Dome CXtra software for DICOM compliance
• Cleanable keyboard and mouse
• Power adapters (display dependent)
Here, dual Dome C3i displays are mounted to the cart.
Other display configurations may have variations for
power supply connection and peripherals.
