Alpine CDE-196DAB Owner's Manual

Cd/dab receiver with advanced bluetooth digital media /dab receiver with advanced bluetooth
Hide thumbs Also See for CDE-196DAB:
Table of Contents

Advertisement

Quick Links

FOR CAR USE ONLY/NUR FÜR AUTOMOBIL GEBRAUCH/POUR APPLICATION AUTOMOBILE UNIQUEMENT/PARA USO EN
AUTOMÓVILES/SOLO PER L'UTILIZZO IN AUTOMOBILE/ENDAST FÖR BILBRUK/ALLEEN VOOR GEBRUIK IN DE AUTO/
ТОЛЬКО ДЛЯ ИСПОЛЬЗОВАНИЯ В АВТОМОБИЛЯХ/DO UŻYCIA TYLKO W SAMOCHODZIE
CD/DAB RECEIVER WITH ADVANCED BLUETOOTH
DIGITAL MEDIA/DAB RECEIVER WITH ADVANCED BLUETOOTH
• OWNER'S MANUAL
Please read before using this equipment.
• BEDIENUNGSANLEITUNG
Lesen Sie diese Bedienungsanleitung bitte vor
Gebrauch des Gerätes.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
• ISTRUZIONI PER L'USO
Si prega di leggere prima di utilizzare il
attrezzatura.
ALPINE ELECTRONICS MARKETING, INC.
1-7, Yukigaya-Otsukamachi, Ota-ku,
Tokyo 145-0067, JAPAN
Phone: 03-5499-4531
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
161-165 Princes Highway, Hallam
Victoria 3803, Australia
Phone 03-8787-1200
CDE-196DAB
UTE-93DAB
• ANVÄNDARHANDLEDNING
• GEBRUIKERSHANDLEIDING
• РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
• INSTRUKCJA OBSŁUGI
ALPINE ELECTRONICS GmbH
Wilhelm-Wagenfeld-Str. 1-3, 80807 München, Germany
Phone 089-32 42 640
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
Fletchamstead Highway, Coventry CV4 9TW, U.K.
www.alpine.co.uk
ALPINE ELECTRONICS France S.A.R.L.
184 allée des Erables
CS 52016 – Villepinte
95 945 Roissy CDG cedex
FRANCE
Phone : + 33(0)1 48 63 89 89
Innan du använder utrustningen bör du läsa
igenom denna användarhandledning.
Lees deze aanwijzingen aandachtig alvorens dit
toestel te gebruiken.
Прочтите настоящее руководство перед
началом использования оборудования.
Prosimy zapoznać siç z tą instrukcją przed
przystąpieniem do użytkowania urządzenia.
ALPINE ITALIA S.p.A.
Viale Cristoforo Colombo, 8
20090 Trezzano sul Naviglio MI, Italy
Phone +39 02 484781
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
Phone 945-283588
EN
R R
DE
FR
ES
IT
SE
NL
RU
PL
Designed by ALPINE Japan
68-30368Z34-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDE-196DAB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alpine CDE-196DAB

Summary of Contents for Alpine CDE-196DAB

  • Page 1 01013 Vitoria (Alava)-APDO 133, Spain Phone 1-800-ALPINE-1 (1-800-257-4631) Phone 945-283588 ALPINE ELECTRONICS France S.A.R.L. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 184 allée des Erables 161-165 Princes Highway, Hallam CS 52016 – Villepinte Victoria 3803, Australia 95 945 Roissy CDG cedex...

  • Page 3: Table Of Contents

    Service Component Search Function....15 Getting Started PTY (Programme Type) Search Function..15 Accessory List ...............9 About DAB/DAB+/DMB..........15 Turning Power On and Off........9 CD/MP3/WMA/AAC (CDE-196DAB only) Demonstration Function..........9 Turning the Demonstration mode Off ....9 Playback ...............16 Source Selection............9 Repeat and Random Play ........16 Detaching and Attaching the Front Panel ..9...
  • Page 4 Using the Front AUX Input Terminal ....26 Smartphone (ALPINE APP)........34 Option Menu Setting..........27 Setting the TTS (Text To Speech) volume..34 Applying Alpine TuneIt App ........ 27 BT Hands Free Calling Adjusting the sound via the Smartphone............28 Setup Before Using ..........35 Facebook Notification Function .....
  • Page 5 Answering a Call........... 38 Basic................45 Hanging up the Telephone ......38 Radio .................45 Calling ..............38 CD (CDE-196DAB only) ........45 Redialling a Number In Outgoing History..38 MP3/WMA/AAC.............46 Dialling a Number In Incoming History .....38 Audio.................46 Dialling a Number In Incoming Missed Call iPod................46...

  • Page 6: Operating Instructions

    CHILDREN. If you have problems, do not attempt to repair the unit yourself. Swallowing them may result in serious injury. If swallowed, consult Return it to your Alpine dealer or the nearest Alpine Service Station a physician immediately. for servicing.
  • Page 7 We remove the bumps, rub the inside edge of the hole and outside edge recommend not using these accessories on discs played in Alpine of the disc with a ballpoint pen or other such instrument, and then CD players.
  • Page 8 Avoid connecting USB memory and Front Aux at the same time. owned by Bluetooth SIG, Inc. and any use of such marks by Alpine • If a USB device is inserted in the unit, it projects out and may be a Electronics, Inc.

  • Page 9: Getting Started

    Bluetooth Connection (BT IN)” on page 36. *4 Refer to “Using the Front AUX Input Terminal” on page 26. Note • The buttons on this Owner’s Manual use CDE-196DAB as an example. Detaching and Attaching the Front Panel Accessory List Detaching •...

  • Page 10: Attaching

    Adjusting Volume Controllable with Remote Control This unit can be controlled with an optional Alpine remote control. For details, consult your Alpine dealer. Point the optional remote control transmitter at the remote control Turn the Rotary encoder until the desired sound is sensor.

  • Page 11: Radio

    Presetting Stations Automatically Radio Press BAND repeatedly until the desired radio band is displayed. Rotary encoder /ENTER  /SOURCE Press and hold TUNEA.ME for at least 2 seconds.  The frequency on the display continues to change while the automatic memory is in progress. The tuner will automatically seek and store 6 strong stations in the selected band.

  • Page 12: Rds

    Receiving RDS Regional (Local) Stations Press and hold YSETUP for at least 2 seconds to activate the SETUP mode. Rotary encoder /ENTER/OPTION  /SETUP Turn the Rotary encoder to select the TUNER mode, and  then press ENTER. Turn the Rotary encoder to select the REGIONAL mode, and then press ENTER.

  • Page 13: Pty (Programme Type) Tuning

    Notes Press and hold BANDTA for at least 2 seconds to • If the traffic information broadcast signal falls below a certain level, the deactivate the Traffic Information mode. unit remains in the receiving mode for 1 minute. If the signal remains The “G”...

  • Page 14: Dab/Dab+/Dmb

    Presetting Service Components Manually DAB/DAB+/DMB Select the band and ensemble, and then tune in a desired service component you wish to store in the preset Rotary encoder memory.  /ENTER /SOURCE  Press and hold, for at least 2 seconds, any one of the preset buttons (1 through 6) into which you wish to store the service component.

  • Page 15: Service Component Search Function

    Service Component Search Function About DAB/DAB+/DMB You can search for a service component in the current ensemble. What is DAB? DAB (Digital Audio Broadcasting) is the third generation broadcasting Press ENTER to activate the search mode. technology following the traditional analog technologies such as FM. The advantages of DAB include being more robust with regard to noise, The “”...

  • Page 16: Cd/Mp3/Wma/Aac (Cde-196Dab Only)

    Repeat and Random Play CD/MP3/WMA/AAC (CDE-196DAB only) During playback, Press z 4 or 5 x repeatedly until the setting appears. RPT ONE: Track/file is played back repeatedly. Rotary encoder RPT FOLDER /ENTER  Files in a folder are played back repeatedly.

  • Page 17: File Name Search Mode

    • Press t in the search mode to return to the previous mode. Method for creating MP3/WMA/AAC files Or, the search mode is cancelled if no operation is performed for Audio data is compressed using software with MP3/WMA/AAC codecs. 60 seconds. For details on creating MP3/WMA/AAC files, refer to the user’s manual for that software.

  • Page 18: Terminology

    Order of files Sound Setting Files are played back in the order that the writing software writes them to the disc. Therefore, the playback order may not be what is expected. Verify the writing order in the software’s documentation. The playback order of the folders and files is as follows.

  • Page 19: Sound Setting

    *8 This item is also related to BASS ENGINE SQ mode when you appealing to your personal taste. adjust sound settings via the Alpine TuneIt App on a Smartphone. Refer to “Adjusting the sound via the Smartphone” After selecting a BAND (BAND1 ~ BAND9) from the 9BAND on page 28.

  • Page 20: Adjusting The Level

     Further setting items: TUNER / DAB / DISC / USB / iPod / system are linkage. BT AUDIO / AUX • The adjustable cross-over range might be different between Alpine Setting contents: TuneIt App and the unit. −14 dB ~ +14 dB (Initial setting: ±0) Turning Subwoofer ON/OFF * Only for CDE-196DAB.

  • Page 21: Setting The Time Correction Unit (Length)

     CMPM  USB  iPod  BT AUDIO  AUX The speakers are driven by the built-in amplifier. *1 CDE-196DAB only. *2 Be applied for MP3/WMA/AAC files in disc. OFF: Use this mode when the line output of this unit is used to drive an external amplifier.

  • Page 22: Bass Engine Sq Function

    • You can access the Sound menu mode directly by pressing BASS when BASS ENGIN is set to OFF. • You can set this item via the Alpine TuneIt App on a Smartphone. Refer to “Adjusting the sound via the Smartphone” on page 28.
  • Page 23 Calculate the difference between the distance correction Time Delay Distance Distance value to the farthest speaker and the other speakers. Difference Number (cm) (inch) (msec) L = (distance to farthest speaker) – (distance to other speakers) 146.2 57.6 These values are the time correction values for the different 149.6 59.0 speakers.

  • Page 24: About The Crossover

    Adjusting to a frequency range outside that recommended may cause damage to the speakers. For the recommended crossover frequencies of Alpine speakers, refer to the respective Owner’s Manual. We are not responsible for damage or malfunction of speakers caused by...
  • Page 25 Switching the 2WAY/3WAY system mode About the 2WAY/3WAY system mode 1 Press the Y/SETUP and f at the same time. The X-OVER for a 2WAY system (frequency range is divided between highs for front/rear and lows for the Subwoofer). Note 2WAY mode •...

  • Page 26: Other Functions

    *4 Displayed during playback of a disc with CD text. If there is Other Functions no Text (Disc Name or Track Name), “DISC TEXT”/ “TRACK TEXT” is displayed. *5 Displayed during playback of MP3/WMA/AAC with folder/ file information. If there is no folder/file information, “FOLDER”/“FILE”...

  • Page 27: Option Menu Setting

    Alpine dealer. *1 Refer to “PTY (Programme Type) Tuning” on page 13. Before these operations, set ALPINE APP to USB or BT depending on *2 The setting items are the same as TUNER setting in SETUP the connected Smartphone. For details, refer to “Setting the mode.

  • Page 28: Adjusting The Sound Via The Smartphone

    When the Smartphone connected to this unit receives notification from Facebook, the unit’s back lighting and the V indicator blink (depending on the Alpine TuneIt App settings on the phone). At the same time, the user’s name is shown in the display (20 characters maximum).

  • Page 29: Setup

    • The Owner’s Manual only describes the setup menu display when APP: ENGLISH is set. ALPINE APP  TTS VOLUME *1 Refer to “Sound Setting” on page 19. Setting the AUX SETUP mode *2 Refer to “Bluetooth SETUP” on page 36.

  • Page 30: Setting The Aux Name Mode

    ON and pressing ENTER. situations, playback of an enhanced CD may be difficult. In this case, For details, consult your nearest Alpine dealer. you can choose to play back the CD data session only. When a disc contains both CD and MP3/WMA/AAC data, playback starts from the ...

  • Page 31: Setting The Opening Screen Update

    (maximum 10 bits), and change it’s suffix to “.bin”. Note (For example: SOUND HU.bin) • For CDE-196DAB, you can also adjust this item by pressing and holding DIM. Switch this unit to USB source, then select “OPENING”  “UPDATE YES” in SETUP, and then press ENTER.

  • Page 32: Adjusting The Dimmer Level

    Adjusting the Dimmer Level Setting the DAB/DAB+/DMB display (DAB DISP) After set “DIMMER” to “AUTO” or “ON”, you can adjust the brightness You can flexibly customize the display of DAB/DAB+/DMB to fit your of the display & button lighting at night with the dimmer. own preferences.

  • Page 33: Setting The Dab Antenna On/Off (Dab Ant)

    Setting the DAB Antenna ON/OFF (DAB ANT) Priority News You can choose whether to supply power to DAB Antenna Connector by This function allows you to preset to give priority to the News this setting. Confirm the type of DAB antenna (sold separately) before programme.

  • Page 34: Receiving Programme Information

    Smartphone (ALPINE APP) OFF / ON (Initial setting) OFF: Set ALPINE APP to USB when an iPhone is connected, or set to BT Programme information will not be received. when an Android Smartphone is paired. Programme information is heard when it is broadcasting.

  • Page 35: Bt Hands Free Calling

    “Setting the If pairing is successful, “CONNECTED” is displayed for a Opening Screen Update” (page 31). (Default name: ALPINE) few seconds. The head unit then returns to its previous state.

  • Page 36: Bluetooth Setup

    Setting the Auto Pairing with iPod/iPhone Bluetooth SETUP By setting this item to ON, the unit will auto pair when an iPod/iPhone The following steps 1 to 5 are common to the various Bluetooth is connected to this unit via the USB port. functions.

  • Page 37: Setting The Bluetooth Sound Quality

    Setting the Bluetooth sound quality Setting the Phone Book Update Change these settings to improve the quality of the outgoing or You can update the phone book automatically or manually. incoming call.  Setting item: PB UPDATE  Setting item: CALL SOUND ...

  • Page 38: Displaying The Firmware Version

    The outgoing method list is displayed. For information to update your Bluetooth firmware, please visit your local Alpine website or choose your country from Alpine Europe top Turn the Rotary encoder to select the outgoing mode. page (http://www.alpine-europe.com). Setting contents: DIALLED / RECEIVED / MISSED / PHONE BOOK ...

  • Page 39: Dialling A Number In Incoming Missed Call History

    Dialling a Number In Incoming Missed Call • If the selected name has more than one number registered in the phone book, you need to turn the Rotary encoder to select the desired History number, and then press ENTER. • Press  in step 3 or 4 to delete the current entry and return to the Telephone numbers for received calls (maximum number of call records previous step.

  • Page 40: Dialling The Preset Number

    Notes Bluetooth Audio Operation • If the name has several numbers registered in the phone book, press ENTER after selecting the name. Turn the Rotary encoder to choose the desired number. Press and hold any one of the preset With a Bluetooth compatible Smartphone or music player, it’s possible to buttons (1 through 6) for at least 2 seconds.

  • Page 41: Usb Memory (Optional)

    • This unit plays back files in USB Memory with the same controls and modes used for playback of CDs containing MP3/WMA/AAC. For details, refer to “CD/MP3/WMA/AAC (CDE-196DAB only)” on page 16. • Before disconnecting USB Memory, be sure to change to another source or set to pause.

  • Page 42: Ipod/Iphone (Optional)

    iPod nano (4th generation): Ver.1.0.4 iPod/iPhone (optional) iPod classic (120 GB): Ver.2.0.1 iPod touch (1st generation): Ver.3.1.3 iPod nano (3rd generation): Ver.1.1.3 iPod classic (80 GB, 160 GB): Ver.1.1.2 • The following devices have been certified following Made for iPhone Rotary encoder guidelines.

  • Page 43: Searching For A Desired Song

    To pause playback, press . Notes • This function is unavailable when iPod MODE is selected in “Setting Pressing  again will resume playback. the iPod Control” (refer to “Setting the iPod Control” on page 42). And Notes “iPod CONT” will be displayed. •...

  • Page 44: Select Playlist/Artist/Album/Genre/Composer/Episode

    Notes Random Play Shuffle (M.I.X.) • This function is inactive during Alphabet Search mode. • This function is also applicable to CD/MP3/WMA/AAC/FLAC search. The Shuffle function of the iPod/iPhone is displayed as s on this unit. Select Playlist/Artist/Album/Genre/ Shuffle Albums: The songs on each album are played back in the order they were Composer/Episode recorded.

  • Page 45: Displaying The Text

    Otherwise, make sure the rest of your system is properly  SONG TITLE  TRACK NO./CLOCK  ALBUM NAME connected or consult your authorized Alpine dealer. TRACK NO./ELAPSED TIME * TAG information Basic “ARTIST”/“ALBUM”/“SONG” is displayed if there is no tag information.

  • Page 46: Mp3/Wma/Aac

    – Clean the disc. switch (refer to “Initial System Start-Up” on page 10) and press  • The disc has scratches. again. If the disc still cannot be ejected, consult your Alpine dealer. – Change the disc. • The pick-up lens is dirty.

  • Page 47: Indication For Ipod Mode

    • Abnormal current is run to the USB Memory device. • Abnormal current is run to the iPod/iPhone. – You can solve the problem by turning ACC off/on, or turning – You can solve the problem by reconnecting the iPod/iPhone, power off/on.

  • Page 48: Specifications

    S/N (with JIS-A) 85 dB CAUTION Distortion 0.1% Difference of Output Level 0 dB CD PLAYER SECTION (CDE-196DAB only) CLASS 1 Frequency Response 5 ~ 20,000 Hz (±1 dB) Wow & Flutter (% WRMS) Below measurable limits LASER PRODUCT Total Harmonic Distortion 0.008% (at 1 kHz)

  • Page 49: Installation And Connections

    When connecting CHILDREN. the CDE-196DAB/UTE-93DAB to the fuse box, make sure the fuse Swallowing them may result in serious injury. If swallowed, consult for the intended circuit of the CDE-196DAB/UTE-93DAB has the a physician immediately.

  • Page 50: Installation

    • If you add an optional noise suppressor, connect it as far away This unit from the unit as possible. Your Alpine dealer carries various * For the screw , provide a proper screw to the chassis installing noise suppressors, contact them for further information.

  • Page 51: Mounting The Microphone

    Mounting the Microphone For the sake of safety, mount the microphone in the following location. • In a stable and secure location. • In a location that does not inhibit safely driving the vehicle. • Mount the microphone in a location where the driver’s voice can easily be picked up.

  • Page 52: Connections

    Connections Antenna (Black) ADAPTIVE STEERING REMOTE G.GND To adaptive steering remote control interface box (Brown/Yellow) ADAPTIVE STEERING REMOTE CONTROL IN1 To adaptive steering remote control interface box (Brown/Orange) ADAPTIVE STEERING REMOTE CONTROL IN2 To adaptive steering remote control interface box Microphone (Black) To Vehicle Display Interface...
  • Page 53  Front AUX Input Terminal To adaptive steering remote control interface box. For details about connections, consult your nearest Alpine dealer. This terminal allows for input of audio from an external device (such as a portable player), using a commercially-available converter cable.
  • Page 54 No. AC146018 Declaration of Conformity We, authorized representative in Europe , Alpine Electronics (Europe) GmbH Wilhelm Wagenfeld Strasse 1-3, 80807 Munich, Germany certify and declare under our sole responsibility that the following product(s) Product name Car Audio Manufacturer Alpine Electronics, Inc.
