Quick Links
ACCESSORIES
Fisher
®
Padded Carry Bag
Rugged double stitched construction. Includes handy exterior
pocket for extra batteries or small accessories. – 103693000C
Fisher
Camo Backpack
®
Large camouflage and black with Fisher
logo. – FCBACKPACK
®
Fisher
Camo Pouch
®
Camo pouch with two inside pockets, belt included. – PCH-F
Stereo Deluxe Headphones
Adjustable single-volume control, 1/4 jack" jack, aluminum cones and coiled cord. 9720971000
Stereo Headphones
Use with Fisher
metal detectors. Lightweight and adjustable with true stereo sound, adjustable
®
volume, 1/4 jack with 1/8 adaptor, 4' cable. – 9720950000
Metal Sand Scoop
Large galvanized metal scoop with filtering holes. Strong Rubberized grip. – SAND SCOOP
Gold Pick
Tempered steel head is 10" long, edge is 3-1/4" wide, overall length 19". Durable fiberglass
handle, rubberized grip and super magnet attached to the head. – GOLDPICK
Lesche Knife
Made from high quality heat-treated tempered steel. The ultimate digging tool.
Comes with a durable sheath. 12" in length with a 7" serrated blade. – LESCHE KNIFE
Fisher
®
Baseball Cap
One-size-fits-all. – FCAP
Fisher
Camo Baseball Cap
®
One-size-fits-all. Velcro closure, camouflage with Fisher
Fisher
Coffee Mug
®
16oz, stainless steel and plastic – FMUG
Fisher
T-Shirt
®
100% cotton with Fisher
Logo. Sizes: S, M, LG, XL & XXL – FTSHIRT
®
Replacement/Accessory Searchcoils
11" DD Elliptical, Open Standard Coil – 11COIL-GB
10" DD Elliptical, Closed Accessory Coil – 10COILDD-GB
5" DD Round Accessory Coil – 5COIL-GBUG
Coil Covers*
Specially made to protect your coil from abrasion and damage.
11" DD Coil Cover – COVER-11DD
10" Biaxial Accessory Coil Cover – 202319000
5" DD Coil Cover – 5COVER-BLK
Rain Cover
Specially designed to protect your detector from dirt and water – RAINCOV-GB
Gold
Prospecting Kits
FOR COMPLETE DETAILS VISIT WWW.FISHERLAB.COM • 1-800-685-5050
FOR COMPLETE DETAILS VISIT WWW.FISHERLAB.COM • 1-800-685-5050
*Image not shown.
MGBuGPro
®
logo. – FCCAP
rev.8
OWNER'S MANUAL
If you do not have prior experience with a metal
detector, we strongly recommend that you:
1) Adjust the Gain to a low
setting in the event
of
false
Always begin use at
a reduced Gain level;
increase Gain only after
you
have
familiar with the detector.
2) Do not use indoors. This detector is for
outdoor use only.
appliances emit electromagnetic energy,
which can interfere with the detector. If
conducting an indoor demonstration, turn
the Gain down and keep the searchcoil
away from appliances such as computers,
televisions and microwave ovens. If your
detector
appliances and lights.
Also keep the searchcoil away from
objects containing metal, such as
floors and walls.
3) use a 9-volt ALKALINE battery.
Do not use Heavy Duty Batteries.
060415
signals.
become
Many household
beeps
erratically,
turn
off
