FlashLogic FLC-CH(RS)-CH5-[FLRSCH5]-EN Install Manual page 6

MODULE
A
RF PORT/WEBLINK PORT
G
F TELEMATIC PORT
B
E
C
D
REMOVE THE WHITE/GREEN WIRE FROM THE BLUE
CONNECTOR AND RE-INSERT IT IN PIN 6 (AS SHOWN)
A
(SEE DETAILED INSTRUCTIONS ON THE NEXT PAGE)
2 2 1
02 WHITE/RED
4 3
6 6 5
06 WHITE/GREEN
B
CONNECT THE WHITE/GREEN WIRE TO THE PINK WIRE
AND CONNECT THE WHITE/RED WIRE TO THE RED WIRE
2 1
(SEE DETAILED INSTRUCTIONS ON THE NEXT PAGE)
4 3
6 5
8 7
10 9
12 11
14
13
16 15
18 17 17
02 PINK
20 19 19
06 RED
C
2 1 01 BROWN/BLACK - PARKING LIGHT (-) OUTPUT
4 3 02 GRAY - RAP SHUTDOWN (-) OUTPUT
6 5
8 7
10 9
12 11 11 GRAY/GREEN - HORN (-) OUTPUT
D
2 1
4 3
04 GRAY/WHITE - HOOD STATUS (-) INPUT
6 5
8 7
10 9 WITHOUT OEM HOOD SWITCH:
INSTALL AND CONNECT TO
AFTERMARKET HOOD SWITCH
U.S. Patent No. 8,856,780
Automotive Data Solutions Inc. © 2015
TYPE 1 - WIRING DIAGRAM - 1 OF 2
THIS WIRING DIAGRAM IS APPLICABLE
OF THE T-HARSNESS IS BEFORE:
NOTE 1
MS2 MS2
PURPLE - STARTER (+) OUTPUT
NOTE 2
WHITE/YELLOW - CONTROL (MUX) OUTPUT
MS1 MS1
WHITE/GREEN
WHITE/RED
WHITE/BROWN (NC) INSULATE WIRE
AFTERMARKET HOOD SWITCH (-)
WARNING
(NEXT TO WHITE/GRAY WIRE)
ONLY IF THE REVISION DATE
2013/11/04
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (-)
OR
CONNECT IF VEHICLE
IS EQUIPPED WITH
PARKING LIGHT (+)
FLC-CH(RS)-CH5-[FLRSCH5]-EN
CUT AND INSULATE
THE WHITE/YELLOW WIRE
A1
VS2 VS2
A2
VS1 VS1
B1
STARTER (+) - 04
CONTROL (MUX) - 02
PARKING LIGHT CONNECTION
10 AMPS
87
85 86
87A
30
OPTIONAL
PAGE 6 OF 24
• 20151222
DOC.: #25395
VEHICLE IGNITION SWITCH
SKIM CONNECTOR
SKIM HARNESS
5 4 4 3 2 2 1
A1
B1
VEHICLE
PARKING LIGHT (-)
12V (+)
PARKING LIGHT (+)
DRIVER DOOR PIN (-)
HORN (-)
