- Page 1 76553 Rev 76553-20100203 10006 Santa Fe Springs Road Santa Fe Springs, CA 90670 USA Made in China Owner’s Manual and Operating Instructions SAVE THESE INSTRUCTIONS Important Safety Instructions are included in this manual 3000 PSI – 2.5 GPM PRESSURE WASHER...
-
Page 3: Table Of Contents
Table of Contents Introduction ........1 Storage ........... 14 Pressure Washer ........1 Engine Storage ........14 Accessories ..........1 Pressure Washer Storage ......14 This Booklet ..........1 Winter Storage ........14 ... -
Page 5: Introduction
Record the model and serial numbers as well as date and place of purchase for future reference. Have this information available when ordering parts and when making technical or warranty inquiries. Champion Power Equipment Support 1-877-338-0999 Model Number 76553 Serial Number Date of Purchase Purchase Location Rev 76553-20100203 - English... -
Page 6: Manual Conventions
If you have questions regarding your pressure WARNING washer, we can help. Please call our help line at 1-877-338-0999. WARNING indicates a potentially hazardous could situation which, if not avoided, result in death or serious injury. Rev 76553-20100203 - English... -
Page 7: Safety Rules
When starting engine, pull the starter cord slowly MINUTES. until resistance is felt and then pull rapidly to avoid kickback. DANGER Rotating parts can entangle hands, feet, hair, clothing and/or accessories. Traumatic amputation or severe laceration can result. Rev 76553-20100203 - English... - Page 8 • DO NOT remove fuel tank cap or fill fuel tank while engine is hot or running (allow engine to cool two minutes before refueling). Always fill the tank slowly. • Never disconnect the high pressure discharge hose from the machine while the system is pressurized. Rev 76553-20100203 - English...
- Page 9 If water has frozen in the pressure washer, thaw the pressure washer in a warm room before starting. DO NOT pour hot water on or into the pump; internal parts will be damaged and your warranty will be voided. Rev 76553-20100203 - English...
-
Page 10: Controls And Features
Pressure Lance for power washing. (6) Throttle – Controls the engine speed. (7) Choke Lever – Used to start the engine. (8) Air Cleaner – Protects the engine by filtering dust and debris from the intake air. Rev 76553-20100203 - English... -
Page 11: Parts Included
Controls and Features Parts Included Your 76553 Gasoline Powered Pressure Washer ships with the following parts: Gun Assembly Pressure Gun 1 piece Lance 1 piece Hose 1 piece Oil Funnel 1 piece Spark Plug Socket 1 piece Rev 76553-20100203 - English... -
Page 12: Assembly
The engine is equipped with a low-oil-shutoff and will stop when the oil level in the crankcase falls Connect to Garden Hose below the threshold level. Secure a garden hose (not included) to the inlet connection on the pump. Rev 76553-20100203 - English... -
Page 13: Operation
Choose the appropriate nozzle tip for the job you are performing. 3. Move the choke lever (Item A) to the CAUTION “Choke” position (to the left). The narrow high impact spray can damage some surfaces. Rev 76553-20100203 - English... -
Page 14: Distance From Cleaning Surface
Use only detergents specially formulated for supply valve. pressure washers. You can effectively clean surfaces by combining the chemical action of detergents with high pressure rinses. On vertical surfaces, apply the detergent starting at the Rev 76553-20100203 - English... -
Page 15: Operating Tips
In the event that the pump gets too hot, a thermal relief valve will open to release the hot water. Running the unit without spraying water can damage pump components and will void your warranty. Rev 76553-20100203 - English... -
Page 16: Maintenance
9. Reattach the air filter cover and tighten Remove the oil drain plug with a 12 mm wing nut. socket and extension. 2. Allow the oil to drain completely. 3. Replace the drain plug. 4. Remove oil fill cap/dipstick to add oil. Rev 76553-20100203 - English... -
Page 17: Cleaning
Detach the wand from the spray gun. Flush Contact our help line at 1-877-338-0999 to the wand with water and use a small wire locate the nearest Champion Power rod (paper clip) to loosen up any particles. Equipment certified service dealer for your maintenance needs. -
Page 18: Storage
5. Pour the antifreeze into the funnel, then direct sunlight. pull on the engine recoil starter to create suction in the pump housing. Pull the recoil several times until antifreeze comes out of the pump outlet. Rev 76553-20100203 - English... -
Page 19: Specifications
Fuel capacity is 0.93 gallons (3.5 L). Use Valve Clearance regular unleaded gasoline with a minimum Intake 0.13-0.17mm (0.005 – 0.007 in.) octane rating of 85. Exhaust 0.18-0.22mm (0.007 – 0.009 in.) Oil capacity is 0.63 qt (0.6 L). Rev 76553-20100203 - English... -
Page 20: Pressure Washer Parts Diagram
Specifications Pressure Washer Parts Diagram Rev 76553-20100203 - English... -
Page 21: Pressure Washer Parts List
GB6182 M10 Nut M10 13.012000.01 12in Wheel 08.010095.10 Bolt M10×95 ST29QXG-2100200 Bottom rubber GB5789 M8×55 Flange boltM8×55 816.201400.00 Frame rubber GB6187.1 M8 NutM8 ST168F-1090100-C Screw cap 819.250200.00 Detergent tank 819.250201.00 Tie-in 819.200701.00 Handle(1) 08.006045.10 Bolt M6×45 Rev 76553-20100203 - English... -
Page 22: Engine Parts Diagram
Specifications Engine Parts Diagram Rev 76553-20100203 - English... -
Page 23: Engine Parts List
ST168F--1120100 Fly wheel ST168F--1080200 Side place ST168F--1030100 Oil seal ST160F-1126000 Diode comp ST160F--1030003 Drain plug bolt ST160F--1030004 Drain bolt washer ST168F-2-1030012-G Crankcase GB/T-276-94 Radial ball bearing 6205 ST160F-1127000-A Oil level switch assembly ST160F--1110101 Governor weight holder Rev 76553-20100203 - English... - Page 24 Exhaust valve spring retainer ST160F--1040003 Valve spring ST160F--1124000 Spark plug ST168F--1040025 Locknut ST168F--1040023 Exhaust rocker ST168F--1040026 Valve rocker arm ST168F--1040027 Pivot bolt ST168F--1040005 Push rod GB16674.1-FB5-8 Flange bolt M5*8 GB848-85-W5 Washer φ5 GB859-87-SW5 Spring washer φ5 Rev 76553-20100203 - English...
- Page 25 Piston pin clip ST168F--1050003 Piston pin ST168F--1050100 Connecting rod comp ST160F--1030005-B Oil filler cap ST160F-1070006 Fuel filter ST1P68F-1070006-F Clip GB848-85-W6 Washer φ6 GB859-87-SW6 Spring washer φ6 GB5789--86-FB6-35 Flange bolt M6*35 GB5789--86-FB6-15 Flange bolt M6*15 GB6187-86-N6 Lock nutM6 Rev 76553-20100203 - English...
-
Page 26: Troubleshooting
Filter on detergent hose is clogged Clean with warm water or replace Garden hose connection leaks Loose fittings Tighten Missing/worn-out rubber washer Replace rubber washer Spray wand leaks Spray wand not properly attached Tighten all connections Rev 76553-20100203 - English... -
Page 27: Warranty
Warranty Qualifications Champion Power Equipment (CPE) will Installation, Use and register this warranty upon receipt of your Maintenance Warranty Registration Card and a copy of... -
Page 28: Contact Information
Santa Fe Springs, CA 90670 Customer Service Mon – Fri 8:30 AM – 5:00 PM (PST/PDT) Toll Free: 1-877-338-0999 Fax no.: 1-562-236-9429 Technical Service Mon – Fri 8:30 AM – 5:00 PM (PST/PDT) Toll Free: 1-877-338-0999 tech@championpowerequipment.com Rev 76553-20100203 - English... -
Page 29: Notes
Notes Notes Rev 76553-20100203 - English...
