Page 1: Pressure Washer
76503 Rev 76503-20100120 10006 Santa Fe Springs Road Santa Fe Springs, CA 90670 USA Made in China Owner’s Manual and Operating Instructions SAVE THESE INSTRUCTIONS Important Safety Instructions are included in this manual 3000 PSI – 2.5 GPM PRESSURE WASHER... -
Page 3: Table Of Contents
Parts Included .......... 7 Oil............15 Assembly .......... 8 Spark Plugs ..........15 Remove the Pressure Washer from the Valve Clearance ........15 Shipping Carton........8 Pressure Washer Parts Diagram .... 16 ... -
Page 5: Introduction
This unit is a gasoline engine driven without prior notice. pressure washer. It is designed for use in cleaning with or without detergent and is suitable for decks, patios, house siding, vehicles, lawn furniture, barbecue grills, gardening tools and more. -
Page 6: Manual Conventions
Manual Conventions CAUTION Manual Conventions CAUTION indicates a potentially hazardous This manual uses the following symbols to situation which, if not avoided, may result in help differentiate between different kinds of minor or moderate injury. information. The safety symbol is used with a key word to alert you to potential hazards in operating and owning power equipment. -
Page 7: Safety Rules
If you start to feel dizzy or weak, get to fresh air immediately. WARNING Operate pressure washer outdoors only in a well ventilated area Rapid retraction of the starter cord will pull hand DO NOT operate the pressure washer inside any... - Page 8 • Always engage the trigger safety latch in the operation. safe position when spraying is stopped even if DO NOT tip the pressure washer or allow fuel or only for a few moments. oil to spill. When transporting or servicing the...
- Page 9 DO NOT let water in the pump freeze. See Storage section in the manual for instructions regarding winter storage. If water has frozen in the pressure washer, thaw the pressure washer in a warm room before starting. DO NOT pour hot water on or into the pump;...
-
Page 10: Controls And Features
Controls and Features Controls and Features Read this owner’s manual before operating your pressure washer. Familiarize yourself with the location and function of the controls and features. Save this manual for future reference. Pressure Washer (1) Muffler (9) Garden Hose Connection... -
Page 11: Parts Included
Controls and Features Parts Included Your 76503 Gasoline Powered Pressure Washer ships with the following parts: Gun Assembly Pressure Gun 1 piece Lance 1 piece Hose 1 piece Oil Funnel 1 piece Spark Plug Socket 1 piece Rev 76503-20100120 - English... -
Page 12: Assembly
DO NOT fill fuel tank indoors. recommended type and amount of oil. Damage DO NOT fill fuel tank when the engine is running to the pressure washer as a result of failure to or hot. follow these instructions will void your warranty. -
Page 13: Operation
If the engine starts but does not run make certain that the pressure washer is on a flat, level Starting the Engine surface. The engine is equipped with a low oil Make certain the pressure washer is on a sensor that will prevent the engine from running when the oil level falls below a critical threshold. -
Page 14: Distance From Cleaning Surface
2. Turn the unit off. removal of difficult stains. Many detergents 3. Remove the ignition cable from the are customized for pressure washer use on spark plug. specific cleaning tasks. Pressure washer 4. Shut off the water supply. -
Page 15: Operating Tips
CAUTION Never connect your pressure washer to a hot water supply. Connecting your pressure washer to a hot water source will significantly reduce the life of the pump and will void your warranty. -
Page 16: Maintenance
2. Use the spark plug tool that shipped Improper maintenance will void your warranty. with your pressure washer to remove the plug. 3. Inspect the electrode on the plug. It must be clean and not worn to produce the spark required for ignition. -
Page 17: Cleaning
Cleaning Pressure Washer Maintenance CAUTION Make certain that the pressure washer is kept clean and stored properly. Only operate DO NOT spray engine with water. the unit on a flat, level surface in a clean, dry operating environment. DO NOT expose the Water can contaminate the fuel system. -
Page 18: Storage
Apply all storage instructions from previous sections. Engine Storage 2. Make sure pressure washer hose is free of all water before storing for winter Allow the engine to cool completely 3. In order to prevent the pump from before storage. -
Page 19: Specifications
Specifications Specifications Spark Plugs Your pressure washer comes equipped with a ¾” (19 mm) long reach plug. Engine Specifications Intermittent use (less than 1 hour/month) or Engine 196 cc OHV CPE colder temperatures (below 60°F) NGK BR6ES or equivalent Pressure Washer... -
Page 20: Pressure Washer Parts Diagram
Specifications Pressure Washer Parts Diagram Rev 76503-20100120 - English... -
Page 21: Pressure Washer Parts List
Specifications Pressure Washer Parts List Part Number Description ST30QXG-0000101 Chemical Hose ST29QXG-3300200 Inlet Filter Gasket ST30QXG-3300300 Hot Protection ST29QXG-2000001 Bolt 5/16-24 D22 GB93 8 Spring Washer 8 ST29QXG-2000006 Key Sq 3/16 1.57 ST168F-II-1000000-G1 Engine (Q) 819.251000.00 Pump 819.252200.00 Connect Wand... -
Page 22: Engine Parts Diagram
Specifications Engine Parts Diagram Rev 76503-20100120 - English... -
Page 23: Engine Parts List
Specifications Engine Parts List Part Number Description GB818-88-B4-12 Bolt M4X12 ST168F-1070003-G Fuel valve knob GB16674-1-FB6-12 Flange bolt M6*12 ST168F-1070002-G Fuel tank veil GB5787--86-FB5-12 Flange bolt M5*12 ST168F-1070200-G Fuel valve ST168F-1070008-G Tube clip φ9.5 ST168F-1070004-G Tube 1 ST188FD--1070006A ClipФ8 168.120700.00 Wire flame out 21.001000.00 Switch ST168F-1070005-G... - Page 24 Specifications Part Number Description ST160F--1110102 Governor weight pin ST160F--1110104 Governor shaft ST160F--1110103 Governor holder clip ST160F--1110107 Governor weight ST168F-1040014 Valve Oil seal ST160F--1110105-A Governor cover ST168F-2-1050001-Q Crankshaft comp ST168F--1030008-G Case over packing ST160F--1030001-B Oil filler cap assembly ST160F--1030002 Oil filler cap packing ST168F-1030007-5/16-G Crankcase cover GB5789--86-FB8-32...
- Page 25 Specifications Part Number Description ST160F--1101100-G Muffler protector ST160F--1101200-G Muffler comp GB6170--86-N8 Nut M8 GB848-85-W8 washer φ8 GB859-87-SW8 Spring washer φ8 ST168F-1100200-G Muffler packing ST160F-1010002 Stud bolt ST168F--1080002-G Shroud comp ST168F-1050007 First ring set ST168F-1050006 Second ring set ST168F-1050200 Oil ring comp ST168F-II-1050005 Piston ST168F--1050004...
-
Page 26: Troubleshooting
Replace spark plug Pressure washer will not start; Low oil level Fill crankcase to the proper level Pressure washer starts but runs Place pressure washer on a flat, level roughly surface Choke in the wrong position. Adjust choke. Spark plug wire loose... -
Page 27: Warranty
CPE's retail This warranty will not apply to parts and/or locations as proof of purchase. labor if this pressure washer is deemed to Please submit your warranty registration have been misused, neglected, involved in an... -
Page 28: Contact Information
Contact Information Address Champion Power Equipment, Inc. Customer Service 10006 Santa Fe Springs Rd. Santa Fe Springs, CA 90670 Customer Service Mon – Fri 8:30 AM – 5:00 PM (PST/PDT) Toll Free: 1-877-338-0999 Fax no.: 1-562-236-9429... - Page 29 United States Environment Protection Agency (U.S. EPA.) Emission Control System Warranty Your Champion Power Equipment (CPE) engine complies with U.S. EPA emission regulations. YOUR WARRANTY RIGHTS AND OBLIGATIONS: The US EPA AND CPE are pleased to explain the Federal Emission Control Systems Warranty on your 2010 small off-road engine.
- Page 30 Warranty EMISSION CONTROL SYSTEM WARRANTY The following are specific provisions relative to your Emission Control System Warranty Coverage. Emission Control System Warranty (ECS Warranty) for 1997 and later model year engines): 1. APPLICABILITY: This warranty shall apply to 1997 and later model year engines). The ECS Warranty Period shall begin on the date the new engine or equipment is delivered to its original, end-use purchaser, and shall continue for 24 consecutive months thereafter.
- Page 31 You must take your CPE engine or the product on which it is installed, along with your warranty registration card or other proof of original purchase date, at your expense, to any Champion Power Equipment dealer who is authorized by Champion Power Equipment, Inc. to sell and service that CPE product during his normal business hours.
-
Page 32: Notes
Notes Notes Rev 76503-20100120 - English...
