1.
To make assembly easier, read the
information on page 5 before you begin.
Orient the Rear Stabilizer (14) so that the indi-
cated holes are at the bottom. While another
person lifts the rear of the Frame (1), attach the
Rear Stabilizer to the Frame with two M10 x
54mm Patch Screws (33) and two M10 Split
Washers (34).
2. Slide the Right Cap (73), which is marked with
a "Right" sticker, onto the right side of the Rear
Stabilizer (14). Attach the Right Cap with two
M4 x 16mm Screws (40).
Attach the Left Cap (4) in the same way.
3. While another person lifts the front of the Frame
(1), attach the Front Stabilizer (2) to the Frame
with two M10 x 78mm Patch Screws (67) and
two M10 Split Washers (34).
All manuals and user guides at all-guides.com
6
1
Holes
34
33
2
4
3
2
1
1
14
Holes
14
73
40
67
34
