11. Identify the Right Pedal (26), which is marked
with an "R."
Using an adjustable wrench, firmly tighten the
Right Pedal (26) clockwise into the right arm of
the Crank (13). Tighten the Left Pedal (not
shown) counterclockwise into the left arm of the
Crank.
IMPORTANT: Tighten both pedals as firmly
as possible. After using the exercise cycle
for one week, retighten the pedals. For best
performance, keep the pedals tightened.
Adjust the strap on the Right Pedal (26) to the
desired position, and press the end of the strap
onto the tab on the side of the Right Pedal.
Adjust the strap on the Left Pedal (not
shown) in the same way.
12. Make sure that all parts are properly tightened before you use the exercise cycle. Note: After assembly is
completed, some extra parts may be left over. Place a mat beneath the exercise cycle to protect the floor.
