OPERATING INSTRUCTIONS
SECURITY SYSTEM
KIT NO.: 08E51-S5D-101
1
© 2004 American Honda Motor Co., Inc. - All Rights Reserved.

Advertisement

Table of Contents
loading

Related Manuals for Honda Civic 08E51-S5D-101

Summary of Contents for Honda Civic 08E51-S5D-101

  • Page 1 OPERATING INSTRUCTIONS SECURITY SYSTEM KIT NO.: 08E51-S5D-101 © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 2: Table Of Contents

    Please write the serial number of the remote control and the main unit below. Keep this booklet as a record of your purchase. Remote Control No.: Main Unit No.: No.: © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 3: Introduction

    Congratulations on your purchase of this Honda Security System. Due to the expertise required to properly install the Honda Your Honda Security System is the product of years of research Security System, we highly recommend that the installation and development. It will give you many years of reliable be performed by your Honda dealer.

  • Page 4: Emergency Disarming

    Insert the ignition key after opening the door. Turn the ignition key to the “ON” (II) position. The security system will disarm when the ignition key is turned to the on position. © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 5: System Controls

    Insert the ignition key. The switching procedure is The result You will observe the following. • The system “beep” once. MANUAL MODE Completed Beep once AUTO MODE Not completed No beep © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 6: Arming Mode (Auto Manual)

    Insert the ignition key. The switching procedure is The result You will observe the following. AUTO MODE Completed Beep twice • The system “beeps” twice. MANUAL MODE Not completed No beep © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 7: Valet (Auto Arming Mode Only)

    Insert the ignition key, and remove the ignition key from the ignition switch. (All the way out.) 4713010M Insert the ignition key. The Status LED will flash once, indicating that the system is in the Valet mode. Status LED © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 8: In The Valet Mode

    LED blinks once. Keyless/Security during the Valet Mode. Lock/Unlock of Keyless Panic of Keyless Set/Unset of Security VALET MODE is ON Active Active Non-Active VALET MODE is OFF Active Active Active © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 9: Exit From The Valet Mode

    Insert the ignition key. The Status LED will flash twice, indicating that the system is out of the Valet mode. The system is now in the Disarm mode. Status LED © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 10: Arming

    (within 5 seconds of the first push) the horn will beep once to confirm the doors are locked the system is armed. Only on vehicles equipped with power door locks. © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 11: Auto Arming (Passive)

    • When the “LOCK” button on the remote control transmitter is pressed during the exit delay time, the arming function of the remote control transmitter has priority. The ignition key must be removed from the ignition switch before the system will arm. © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 12: Alarm Mode

    The entry delay time is functional only when the Arming mode is set to “AUTO” and the door is open. Pressing the “UNLOCK” button of the remote will cancel the alarm. © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 13: Disarming

    • The doors unlock Note: After disarm the system will rearm in 30 seconds if the doors or the trunk (tailgate) are not opened. Only on vehicles equipped with power door locks. © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 14: Panic

    1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 momentarily, or turn the ignition key to the “ON” (II) position. © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 15: Tripped Sensor Warning And Indication

    • If the system was tripped and auto rearmed you will observe the following: The status LED flashes twice per second. The parking lights flash 3 times when the system is disarmed. © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 16: Tripped Sensor Indication (Using Both The Transmitter And Ignition Key)

    Remove the key from the ignition switch. Press the “UNLOCK” button on the remote control transmitter. The status LED will flash according to the sensors tripped. (For indication examples, see next page.) © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 17: Tripped Sensor Indication (Using Only The Ignition Key)

    If the alarm is triggered twice, first by opening the door and then by opening the trunk, the Ignition Switch Status LED will flash once, pause, flash 2 times, pause and repeat this sequence for 1 Battery Disconnected minute. © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 18: Remote Control Code Programming (Only Vehicles Without Power Door Locks)

    Press the “LOCK” or “UNLOCK” button on the remote control transmitter. Turn the ignition key to the “OFF” (0) position. Turn the ignition key to the “ON” position. © 2004 American Honda Motor Co., Inc. - All Rights Reserved.
  • Page 19 Turn the ignition to the “ON” position. Press the “LOCK” or “UNLOCK” button on the remote control transmitter. Turn the ignition to the “OFF” position. Turn the ignition to the “ON” position. © 2004 American Honda Motor Co., Inc. - All Rights Reserved.
  • Page 20 Perform the programming step within 10 seconds for each remote or else the programming mode will terminate. Note: Only 3 remotes can be stored in the system’s memory. © 2004 American Honda Motor Co., Inc. - All Rights Reserved.

  • Page 21: Glossary

    When the system is set to the Automatic Arming mode, the amount of time before the system arms after the trunk (tailgate) and all the doors are closed. Functional only in the Automatic Arming mode. © 2004 American Honda Motor Co., Inc. - All Rights Reserved.
  • Page 22 The remote control transmitter won’t arm or disarm the system in the valet mode, but panic feature will work in the valet mode. Functional only in the Automatic Arming mode. © 2004 American Honda Motor Co., Inc. - All Rights Reserved.
  • Page 23 Notes © 2004 American Honda Motor Co., Inc. - All Rights Reserved.
  • Page 24 NOTE: Due to continuous product improvement, specifications and design are subject to change without notice.without e without noticenotice 08E51-S5D-1M10-81 © American Honda Motor Co., Inc. 2004 All Rights Reserved. AAM 38983 (0804) © 2004 American Honda Motor Co., Inc. - All Rights Reserved. Printed in Japan...
