BluDot DODU BED-TWIN Assembly Notes

A s s e m b l y N o t e s
1
Larger hole pattern
A s s e m b l e o n c a r p e t o r p r o t e c t i v e m a t .
1 Orient each siderail A as shown in diagram 2. Note that the end closest to the headboard should have a larger hole pattern on the side.
Push the hooks on the side rails into the slots in the headboard and footboard. Firmly press down on the siderails to make sure the hooks
engage.
2 Attach the rails together by screwing in the corner brackets. First attach the smaller brackets
bracket in place, add a washer, and then a screw. Use the hex key to tighten the screws. Repeat to attach the larger brackets
footboard and side rails.
H A R D W A R E I N V E N T O R Y
16 screws
A
B to the headboard and side rails. Place the
1 hex key 16 washers
D O D U B E D - T W I N
C
C
to the
2
B
