Operating Instructions - CW40 Wall Control

1. Restore electrical power to the outlet box by turning the
electricity on at the main fuse box.
2. Your fan model is equipped with a 4-position, 3-speed,
slide switch wall control. The operating sequence is as
follows:
• 4th Position = low speed
• 3rd Position = medium speed
• 2nd Position = medium high speed
• 1st Position = high speed
• — Position = fan off
3. If airflow is desired in the opposite direction, turn the fan
off and wait for the blades to stop turning. Dis-assemble
the Lower Cover, slide the reverse switch to the opposite
position, re-assemble the Lower Cover and turn fan on
again.
Periodic cleaning of your new ceiling fan is the only
maintenance that is needed.
When cleaning, use only a soft brush or lint free cloth to
avoid scratching the fi nish.
Abrasive cleaning agents are not required and should be
avoided to prevent damage to fi nish.
Periodic light dusting of the blades is recommended.
A feather duster will work best.

Maintenance

Do not use water when cleaning your ceiling fan. It
could damage the motor or the blades and create the
possibility of electrical shock.

Blade Cleaning

Avoid using water, cleansers, or harsh rags, which can
warp and ruin the blades.
11
Figure 1
CAUTION
