Wall mount

Advertisement

Attach wall bar using
outermoust screw
holes first then find
wall studs and attach
using closest holes.
*
*
Installation of the Wall
Mounted Shale is not for
the faint of heart. We
recommend professional
installation to ensure
proper mounting.
WWW.BLUDOT.COM
SHALE
WALL MOUNT
Assembly Notes

CARE

Clean with a
slightly damp, soft
cloth. To remove dirt
and fingerprints, use a
quality cleaner formulated
for wood furniture. Wipe
completely dry with
a soft cloth in the
direction of the
wood grain.
*
*
*
1
To determine the hardware
best suited for your type of
wall and anticipated load,
consult your local hardware
professional.

HARDWARE

x1
8027

WALL BAR

Remove top drawer
for easy installation.
Open drawer and place
hands underneath front
of drawer, pulling on
levers on each end.
SHALE WALL MOUNT rev00 - PAGE 1 OF 2
