Shale Wall-Mounted Cabinet
D E S I G N E D I N 2 0 1 3
A S S E M B LY N O T E S | R E V 0 0
B E A U T I L I T Y !
Pick the height that is right for your space. Door units feature adjustable
shelves and wire management holes.
N E E D A H A N D ?
Contact us at service@bludot.com or
844.425.8368 for assistance.
Advertisement
Table of Contents
Related Manuals for BluDot Shale 2 Door 2 Drawer Wall-Mounted Cabinet
Summary of Contents for BluDot Shale 2 Door 2 Drawer Wall-Mounted Cabinet
- Page 1 B E A U T I L I T Y ! N E E D A H A N D ? Contact us at service@bludot.com or Pick the height that is right for your space. Door units feature adjustable 844.425.8368 for assistance.
- Page 2 Parts & Hardware Wall Bar 1 | 8 4 4 . 4 2 5 . 8 3 6 8 S H A L E W A L L - M O U N T E D C A B I N E T...
- Page 3 Step 01 I N S TA L L T H E B A R . Attach Wall Bar using outermost holes first, then distribute the other screws based on the wall studs.* Position the top of the wall bar 1-1/4” lower than your desired height of the Shale unit. Desired Height 1-1/4 in.
- Page 4 Step 03 H A N G I N G / A D J U S T I N G . To make sure each of the three cabinet hangers within the console latch over the wall bar, extend the cabinet hanger brackets by turning the front Front adjustment screw adjustment screw counter clockwise.
