Grove Wiring Table

Note - again, make sure you are connecting things to the right places. It all matters. Optional: We find the
plastic clips on the Grove cable plugs annoying and often cut them off with wire clippers.
Select the proper grove cables and connect them as shown in the table.
Grove Wiring Table
From
GW1 Part H - Mini Pro
Plus
GW2 Part H - Mini Pro
Plus
GW3 Part H - Mini Pro
Plus
Page 20
Version 1.1 September 2021
To
I2C Part C - INA3221
I2C Part I - HDC1080
Temp/Humidity
Part D - Solar
D3/D4 (White is no
connect) Controller Board
Table 1
I2C
I2C
OUT1 EN1 - Yellow,
Red ON, Black OFF
- No White
connection (See
picture below)
