This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in
manuals, be alert to the potential for personal injury or death.
Unit Dimensions ..........................................................2
Parts Arrangement.......................................................3
Gas Furnace ................................................................4
Shipping and Packing List ...........................................4
Safety Information .......................................................4
General ........................................................................6
Combustion, Dilution & Ventilation Air .........................6
Installation ...................................................................9
Filters .........................................................................12
Duct System ..............................................................12
Venting Practices .......................................................14
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional installer (or
equivalent), service agency or the gas supplier.
Manufactured By
Allied Air Enterprises LLC
A Lennox International, Inc. Company
215 Metropolitan Drive
West Columbia, SC 29170
507769-04
INSTALLATION INSTRUCTIONS
Warm Air Gas Furnace
Downflow Air Discharge
This manual must be left with the homeowner for future reference.

Table of Contents

WARNING
Save these instructions for future reference
96G1DFE
Condensate Piping ....................................................28
Gas Piping .................................................................31
Electrical ....................................................................34
Unit Start-Up ..............................................................37
Air for Non-Direct Vent Applications ..........................41
Other Unit Adjustments..............................................42
Blower Performance Data .........................................43
Service.......................................................................44
Planned Service ........................................................46
Repair Parts List ........................................................52
As with any mechanical equipment, personal injury can
result from contact with sharp sheet metal edges. Be
careful when you handle this equipment.
Issue 1927
CAUTION
*P507769-04*
(P) 507769-04
Page 1 of 53
