SERVICE MANUAL
95G1UHEX Gas Furnace
This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in manuals, be alert to
the potential for personal injury or death.
95G1UHEX series units are high-efficiency gas furnaces
available in heating input capacities of 40,000 to 100,000
Btuh and cooling applications from 2 through 5 tons. Refer
to Engineering Handbook for proper sizing.
Units are factory equipped for use with natural gas. All
95G1UHEX units are equipped with a hot surface ignition
system. The gas valve is redundant to assure safety shut-
off as required by C.S.A.
The heat exchanger, burners and manifold assembly can
be removed for inspection and service. The maintenance
section gives a detailed description on how this is done.
All specifications are subject to change. Procedures
outlined in this manual are presented as a recommendation
only and do not supersede or replace local or state codes.
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional HVAC installer (or
equivalent), service agency or the gas supplier.
As with any mechanical equipment, contact with sharp
sheet metal edges can result in personal injury. Take
care while handling this equipment and wear gloves
and protective clothing.
508034-02
WARNING
CAUTION

Table of Contents

Technical Specifications ..............................................2
Blower Performance ....................................................3
Parts Arrangement.......................................................5
Unit Components .........................................................6
Placement and Installation ........................................15
Joint Cementing Procedure .......................................16
Venting Practices .......................................................16
Vent Piping Guidelines ..............................................17
Start-Up .....................................................................37
Heating System Service Checks ...............................38
Typical Operating Characteristics ..............................41
Maintenance ..............................................................42
Electric shock hazard.
Can cause injury or death. Before attempting
to perform any service or maintenance,
turn the electrical power to unit OFF at
disconnect switch(es). Unit may have
multiple power supplies.
*P508034-02*
Issue 2135
WARNING
(P) 508034-02
Page 1 of 49
