Extreme Networks Summit Summit1 Hardware Installation Manual page 7

Figures
1-1 Summit1 switch front view
1-2 Summit1/LX switch front view
1-3 Summit4 switch front view
1-4 Summit4/FX switch front view
1-5 Summit24 switch front view
1-6 Summit48 switch front view
1-7 Summit switch rear view
1-8 Front view of Summit7i switch with 100BASE-TX/1000BASE-T
ports 1-16
1-9 Front view of Summit7i switch with 1000BASE-SX ports
1-10 Summit7i switch rear view
2-1 Rack-mount helper bracket
2-2 Fitting the mounting bracket
2-3 Null-modem cable pin-outs
2-4 PC-AT serial null-modem cable pin-outs
2-5 GBIC modules
1-7
1-8
1-9
1-10
1-11
1-12
1-13
1-20
2-3
2-4
2-6
2-9
1-17
2-7
VII
