SimworX Pro Series User Manual

INTRODUCTION

Thank you for purchasing our V3.1 LC Pedal Set. We are sure you will enjoy your purchase.
Primarily designed to be used on our SX02Msport series Simulator platforms, the design of the Pedals makes it suitable for fitting in
to a variety of cockpits with a little bit of skill.
There is the added capability of converting these pedals to an inverted position so the pedals hang down for those wanting to
replicate a specific car.
The Brake Pedal module can also be moved left and right on the base independent of the brake and clutch modules.
The Pro Series range of controls are products that were designed and developed by SimworX with the ultimate aim of supplying the
most realistic motorsport inspired controls for the ultimate virtual racing experience. Each product is pre-tested prior to shipping to
ensure your investment is ready to go once you've received it. We continually upgrade our controls to ensure the pedals are robust
and give positive feel and feedback. A 16 bit resolution USB interface ensures accurate pedal control whilst the unique Hydraulically
loaded Load Cell activation system enables the braking system to be fully tuned in to your racing style.
A load cell works the way it feels. It is measuring force (same as a brake) and feels like a brake because it gets harder to get it to
"max" due to the progressive resistance that gets harder and harder. The perfect pedal for sim racing is to have hydraulics in the
system because that's what real brakes are, and in conjunction with the load cell, the force outputs to a 16 bit high resolution circuit
board for accuracy. Simworx has also introduced a rocker arm that the load cell cylinder system pressures up, and by introducing
variable durometer dampers that works against the rocker arm's action, a very finely tuned end stop feel can easily be attained. In
a good race pedal system, the pedal barely moves once the pads touch the rotor. A good racecar brake pedal feels like stepping on
a brick once full pad pressure has been attained and that is achievable with this system. If that's not to your liking, you can back it
off by using the thumb screw and/or interchanging the supplied dampers. Brake feel is very subjective, that's why all of these
Adjustments have been introduced.
The following instructions will guide you through the installation process and the various adjustability options built into the
unit

PACKAGE CONTENTS

1x Pro V3.1 LC Pedal Set
1 x Heel Riser with adjustable heel rest
1 x A to B USB Cable
3 x Urethane Load Cell Rocker Arm Bushes
1x Stainless Steel Bolt Pack with Washers
1 x Allen Key Set
1 x 10mm + 8mm spanner
