SimworX Pro F1/GT LC Series User Manual

Pedal set

Download this manual

INTRODUCTION

Thank you for purchasing our latest F1 style LC 2 Pedal Set. We are sure you will enjoy your purchase.

Primarily designed to be used on our SX02Msport series Simulator platforms the design of the Pedals makes it suitable for fitting in

to a variety of cockpits with a little bit of skill.

The Pro Series range of controls are products that were designed and developed by SimworX with the ultimate aim of supplying the

most realistic motorsport inspired controls for the ultimate virtual racing experience. Each product is pre-tested prior to shipping to

ensure your investment is ready to go once you've received it. We continually upgrade our controls to ensure the pedals are robust

and give positive feel and feedback. A 16 bit resolution USB interface ensures accurate pedal control whilst the unique Hydraulically

loaded Load Cell activation system enables the braking system to be fully tuned in to your racing style.

A load cell works the way it feels. It is measuring force (same as a brake) and feels like a brake because it gets harder to get it to

"max" due to the progressive resistance that gets harder and harder. The perfect pedal for sim racing is to have hydraulics in the

system because that's what real brakes are, and in conjunction with the load cell, the force outputs to a 16 bit high resolution circuit

board for accuracy. Simworx has also introduced a rocker arm that the load cell cylinder system pressures up, and by introducing

variable durometer dampers that works against the rocker arm's action, a very finely tuned end stop feel can be attained. In a good

race pedal system, the pedal barely moves once the pads touch the rotor. A good racecar brake pedal feels like stepping on a brick

once full pad pressure has been attained and that is achievable with this system. If that's not to your liking, you can back it off by

using the thumb screw and/or interchanging the supplied dampers. Brake feel is very subjective, that's why all of these adjustments

have been introduced.

The following instructions will guide you through the installation process and the various adjustability options built into the

unit

CONTENTS

1x Pro Series F1/GT LC Pedal Set

1 x A to B USB Cable

3 x Urethane Load Cell Rocker Arm Dampers

1x Stainless Steel Bolt Pack with Washers

1 x Allen Key Set

1 x 10mm spanner

1 x Heel Riser

Need help?

Do you have a question about the Pro F1/GT LC Series and is the answer not in the manual?

Page 1 The Pro Series range of controls are products that were designed and developed by SimworX with the ultimate aim of supplying the most realistic motorsport inspired controls for the ultimate virtual racing experience. Each product is pre-tested prior to shipping to ensure your investment is ready to go once you’ve received it.
Page 2 FITTING For owners of existing Simworx simulators and/or chassis units, the mounting points for the pedals are already in place. Locate the pedals and with the supplied bolt set insert them in to the pre-tapped bolt holes. . For fitting to other simulators, make sure the frame is strong enough to withstand the forces you can exert on the brake pedal.
Page 3 ADJUSTMENT Brake Pedal Face Angle The pedal face on the brake pedal is fitted with angle and height adjustments. To adjust, using a 5mm allen key and 10mm spanner, loosen off the two nuts (pointed out by the red arrows) a few turns to loosen the pad assembly. Once loose, you will be able to adjust the pad upwards & down, as well as tilt the pedal face backward and forwards until you’re comfortable with the position.
Page 4 Plug in the supplied USB A to B cable into the pedal set at point A, and then into a spare USB port on your computer. The pedal set should be automatically be detected by Windows and self-install. You can confirm this by going to the ‘devices and printers” and confirming that “Simworx Pro Series Pedals” is listed there.
