Summary of Contents for Intex PureSpa SJB-HS-10-1

  • Page 1 SJB-HS-10-1 / SJB-HS-11 110-120 V~, 60 Hz, 12 A For illustrative purposes only. Do not forget to try these other fi ne Intex products: pools, pool accessories, in-home toys, airbeds and boats available at fi ne retailers or visit our website.

  • Page 2: Table Of Contents

    (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English TABLE OF CONTENTS Warning..................3-4 Parts....................Product Specifi cations..............Set-up..................... 7-11 Salt Level Information..............Operation..................13-14 LED Code Chart................15 Maintenance and Chemicals............16-23 Storage................... 23 Troubleshooting................24-26 Filter pump motor disassembly...........

  • Page 3: Warning

    (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English IMPORTANT SAFETY INSTRUCTIONS When installing and using this electrical equipment, basic safety precautions should always be followed, including the following. READ AND FOLLOW ALL INSTRUCTIONS DANGER • Risk of Accidental Drowning. Extreme caution must be exercised to prevent unauthorized access by children.
  • Page 4 • Do not allow the water in the spa to freeze. Do not turn on the spa when the water is frozen. • Do not use the spa if damaged in delivery and/or malfunctioning in any fashion. Contact the Intex service center for further direction.

  • Page 5: Parts

    (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English PARTS Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. Page 5 S AVE THESE INSTRUCTIONS...
  • Page 6 (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English PARTS (continued) Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. PART NO. REF. NO. DESCRIPTION QTY.

  • Page 7: Product Specifications

    (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English PRODUCT SPECIFICATIONS Maximum seating capacity: 4 adults 6 adults Water capacity: 210 gal (795 L) 290 gal (1098 L) Inner/outer diameter: 59/79 in (150/201 cm) 66/86 in (168/218 cm) Height: 28 in (71 cm) Jet pump:...
  • Page 8 Lay out all the parts on the ground and make sure all the parts are accounted for. For missing or damaged parts contact the appropriate Intex Service Center listed in the separate “Authorized service Centers” sheet. Safety Sign Card Posting The Safety Sign card included with the manual shall be posted in an area visible to the users of the spa to alert them of the safety rules and warnings.
  • Page 9 (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English SET UP (continued) Press the button to turn on the control unit panel buttons fi rst. Press the button to infl ate the spa tub wall for 8 to 10 minutes until it is fi rm to the touch but not hard (see drawing 5). IMPORTANT: Do not over infl...
  • Page 10 (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English SET UP (continued) IMPORTANT The spa tub infl ation/defl ation valve incorporates an “air pressure release” function that automatically releases excess air when the spa tub internal pressure is between 1.5 - 2.5 psi (0.103 - 0.172 bar). Air pressure release valve.
  • Page 11 (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English SET UP (continued) Defl ation For Spa Tub Wall: Unscrew the cap to reveal the stem, push the stem in and turn 90 degree right to secure it in the down position (see drawing 8).

  • Page 12: Salt Level Information

    (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English SALT LEVEL INFORMATION The spa comes with a built-in saltwater sanitation system. Common salt (sodium chloride) is made up of two elements, sodium and chloride. During the installation of the device, a measured quantity of salt is dissolved in the SPA water to make it slightly salty.

  • Page 13: Operation

    (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English OPERATION SPA CONTROL UNIT PANEL A: Heat Button B: Celsius/Fahrenheit Toggle Button C: Temperature Increase Button D: Temperature Decrease Button E: Water Filter Button F: Water Jet Button G: Sanitizer button H: LED Display I: On/Off Button...
  • Page 14 (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English SANITATION SYSTEM OPERATING INSTRUCTIONS 1. Activate the sanitation system: Press the sanitizer button on the control panel, this will activate the sanitation system as well as the fi lter pump. The sanitizer icon and the fi...

  • Page 15: Led Code Chart

    (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English LED CODE CHART LED Reading Defi nitions 001H Operating Hour (1 hour remaining) 002H Operating Hours (2 hours remaining) 003H Operating Hours (3 hours remaining) 004H Operating Hours (4 hours remaining) 005H Operating Hours (5 hours remaining) 006H...

  • Page 16: Maintenance And Chemicals

    Do not add chemicals if the spa is occupied. This can cause skin or eye irritation. Concentrated chlorine solutions can damage the spa tub. In no event is Intex Recreation Corp., Intex Development Co. Ltd., their related companies, authorized agents and service centers, retailers or employees liable to the buyer or any other party for costs associated with the loss of spa water, chemicals or water damage.
  • Page 17 (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English SPA WATER CHEMISTRY AND BALANCE (continued) ): refers to the amount of calcium and magnesium dissolved in the water. Calcium Hardness (CaCO Result if too low – Diffi culty balancing water, corrosion of metal components, eye & skin irritation and water foaming.
  • Page 18 (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English SPA WATER CHEMISTRY AND BALANCE (continued) Lowering Total Alkalinity Amount of Sodium Bisulfate to lower Total Alkalinity Desired level 60 ppm 80 ppm 100 ppm 120 ppm 140 ppm 0.269 Lb 0.358 Lb...
  • Page 19 (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English SPA WATER CHEMISTRY AND BALANCE (continued) Raising pH Raising pH Using Sodium Bicarbonate Volume 210 gal (795 L) 290 gal (1098 L) Total Alkalinity 120 ppm 80 ppm 120 ppm 80 ppm 0.541 Lb...
  • Page 20 (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English MAINTENANCE Maintenance of Spa Water and Cartridge Protect all the spa occupants from possible water-related illnesses by keeping the spa water clean and sanitized. Always practice good hygiene. To ensure proper spa water quality follow these procedures: Inspect and clean the fi...
  • Page 21 NOTE: Ensure the notch on the electrolytic cell is aligned with the ridge on the electrolytic cell housing. ® INTEX TEST STRIPS (PACKED WITH THE PRODUCT) The Test Strips can test the “Free Chlorine”, “pH”, “Total Alkalinity” and “Calcium Hardness” levels at the same time.
  • Page 22 (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English MAINTENANCE (continued) Spa Tub Drainage Turn off and unplug the spa control unit. Connect the drain valve adaptor to a garden hose and point the other end of the garden hose to a suitable draining area (see drawing 12).

  • Page 23: Storage

    (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English MAINTENANCE (continued) Spa Tub and Cover Air Bladder Repair Use the enclosed repair patch to repair any puncture: • Clean and dry the area to be repaired thoroughly. •...

  • Page 24: Troubleshooting

    • Turn off and unplug the spa. Let it cool down and DOES NOT WORK restart all over again. • If problem persists contact Intex Service Center. JET OUTPUT IS • Low water level. • Add water between MIN and MAX level.
  • Page 25 • Air blower pump is too hot. • Turn off and unplug the spa. Let it cool down and BLOWER DOES NOT restart all over again. WORK • If problem persists contact Intex Service Center. Page 25 S AVE THESE INSTRUCTIONS...
  • Page 26 • Possible electrolytic cell failure. • Ensure that the cell cord is plugged fi rmly into the cell receptacle. • Contact Intex Service Center. Replace the cell if needed. • High salt level. • Partially drain the pool and refi ll it with fresh water. See “Salt Level Information”.

  • Page 27: Filter Pump Motor Disassembly

    (264PO) SPA (JET + BUBBLE) ENGLISH 7.5” X 10.3” PANTONE 295U 05/10/2017 English FILTER PUMP MOTOR DISASSEMBLY IMPORTANT: You must drain out any remaining water inside the piping system of the control base before replacing any parts. Tools required: One adjustable wrench and one Philip screwdriver. NOTE: The “special wrench tool”...

  • Page 28: Warranty

    WARRANTY Your PureSpa has been manufactured using the highest quality materials and workmanship. All Intex products have been inspected and found free of defects prior to leaving the factory. This Limited Warranty applies only to the PureSpa listed below. The provisions of this Limited Warranty apply only to the original purchaser and is not transferable.
