- Page 1 FACTORY AUTOMATION MANUAL IUH-F117-V1-EU IUH-F117-V1-US IUH-F117-V1-CN Read / Write Head for IDENTControl...
- Page 2 IUH-F117-V1-* With regard to the supply of products, the current issue of the following document is applicable: The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation of proprietorship"...
-
Page 3: Table Of Contents
IUH-F117-V1-* Contents 1 Introduction................. 5 2 Declaration of Conformity ..........6 3 Safety ................... 7 Symbols relevant to safety ................7 Intended Use ....................7 General notes on safety.................8 4 Product Description ............9 RFID Frequency Bands.................9 UHF general ....................9 4.2.1 Advantages of UHF ..................9 4.2.2 Permissible Transmitting Power of UHF ............9 4.2.3 Permissible Frequency Range of UHF............9 4.2.4 Applications for UHF systems..............9... - Page 4 IUH-F117-V1-* Contents 6 Commissioning ..............25 Definitions ....................25 6.1.1 Display....................25 6.1.2 Legend ....................25 Device Settings ..................26 Operation via the Command Interface............26 7 Operation ................29 General....................... 29 Basic Command Process................29 Command Overview................... 30 Read/Write Commands ................31 Configuration Commands ................
-
Page 5: Introduction
Introduction Introduction Congratulations You have chosen a device manufactured by Pepperl+Fuchs. Pepperl+Fuchs develops, produces and distributes electronic sensors and interface modules for the market of automation technology on a worldwide scale. Before you install this device and put it into operation, please read the operating instructions thoroughly. -
Page 6: Declaration Of Conformity
Notice: Changes or modifications made to this equipment not expressly approved by Pepperl+Fuchs GmbH may void the FCC authorization to operate this equipment. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. -
Page 7: Safety
Pepperl+Fuchs GmbH provides no guarantee that the information contained in this document does not contain third-party industrial property rights. Pepperl+Fuchs GmbH does not issue any licenses to its own or third-party patents or other industrial property rights in this document. -
Page 8: General Notes On Safety
If serious faults occur, stop using the device. Secure the device against inadvertent operation. In the event of repairs, return the device to your local Pepperl+Fuchs representative or sales office. The connection of the device and maintenance work when live may only be carried out by a qualified electrical specialist. -
Page 9: Product Description
IUH-F117-V1-* Product Description Product Description RFID Frequency Bands 1000 10000 Frequency [MhZ] 100–135 kHz: Low frequency LF ■ 13.56 MHz: High frequency HF ■ 865–868 MHz (Europe), ■ 902–928 MHz (USA), 920–925 MHz (China): Ultra-high frequency UHF 2.45 GHz and 5.8 GHz: Microwave MW ■... -
Page 10: Memory Structurein Accordance With Epc Gen 2 (Iso/Iec 18000-63)
IUH-F117-V1-* Product Description 4.2.5 Memory Structure of a Tag in Accordance with EPC Gen 2 (ISO/IEC 18000-63) [7:0] DSFID [7:0] Commands Read / write head Memory module [15:0] SR/ER Bank 11 USER [31:16] SW/EW Bank 10 SF/EF SS/ES Bank 01 UII/EPC SP/EP Optional XPC_W2... - Page 11 IUH-F117-V1-* Product Description Bank 00: Password Management The segment Bank 00 contains the password management information, comprising the access password and the kill password. The read/write head manages the kill password with the standard read/write commands SW and SR. The access password is not supported. see "Single Read Words SR" on page 33 and see "Single Write Words SW"...
-
Page 12: Electronic Product Code (Epc)
IUH-F117-V1-* Product Description Bank 11: User Memory Segment Bank 11 contains an area to which the user has free access. This size of this area depends on the chip type, or the area may not be present. The data in segment Bank 11 is addressed via the single read words (SR), single write words (SW), enhanced read words (ER), and enhanced write words (EW) commands. -
Page 13: Influence Of Various Materials On The Sensing Range
IUH-F117-V1-* Product Description To work with unique number sequences without having to use sometimes expensive EPC codes, we recommend using the TID of the tag, which is programmed into the tag chips by the semiconductor manufacturer. 4.2.7 Influence of various materials on the sensing range In the UHF range, the nature of the surrounding area and the surface to which the transponder is secured have a serious influence on the range that the system can attain. -
Page 14: Frequency Hopping Method
Other countries in which the device can be used The IUH-F117-V1-EU read/write head has a transmission license in accordance with DIN EN 302208-2. Note! -
Page 15: Relevant Standards For Uhf
IUH-F117-V1-* Product Description The ISM band from 902 to 928 MHz is available in the USA. The band is split into 50 channels, each with a 500 kHz bandwidth. FHSS with a maximum retention time of 4 seconds is employed. All channels must be used. Channel restriction is not permitted. -
Page 16: Indicators And Controls
IUH-F117-V1-* Product Description Measurement Range The measurement range is normally 6 meters. Tags that comply with EPC Gen 2 (ISO/IEC 18000-63) are supported. Features The IUH-F117-V1-* read/write head is equipped with the following features: Two dual LEDs for function display ■... -
Page 17: Accessories
IUH-F117-V1-* Product Description Accessories 4.7.1 IDENTControl The read/write head can be connected to Pepperl+Fuchs IDENTControl control interfaces. Interface Designation 4 read/write heads: Ethernet IC-KP-B17-AIDA1 2 read/write heads: PROFIBUS IC-KP2-2HB6-V15B Ethernet IC-KP2-2HB17-2V1D Serial IC-KP2-2HRX-2V1 1 read/write head: PROFIBUS IC-KP2-1HB6-V15B IC-KP2-1HB6-2V15B Ethernet... -
Page 18: Connection Cable For R/W Heads And Trigger Sensors
IUH-F117-V1-* Product Description 4.7.3 Connection cable for R/W heads and trigger sensors Compatible connection cables with shielding are available for connecting the R/W heads and trigger sensors. Figure 4.7 Accessories Description 2 m long (straight female, angled male) V1-G-2M-PUR-ABG-V1-W 5 m long (straight female, angled male) V1-G-5M-PUR-ABG-V1-W 10 m long (straight female, angled male) V1-G-10M-PUR-ABG-V1-W... -
Page 19: Cable Connectors For The Power Supply
IUH-F117-V1-* Product Description 4.7.4 Cable connectors for the power supply Compatible M12 sockets with an open cable end for connecting the IDENTControl to a power supply are available in different lengths. Figure 4.8 Accessories Designation Length 2 m (straight socket) V1-G-2M-PUR Length 5 m (straight socket) V1-G-5M-PUR... -
Page 20: Installation
Retain the original packaging in case you have to store or ship the device again at a later date. Should you have any questions, please contact Pepperl+Fuchs. Mounting The read/write head is intended for wall mounting or mounting on brackets in internal areas. -
Page 21: Room Orientation
IUH-F117-V1-* Installation 5.3.1 Room Orientation The alignment of the read/write tag antennae in relation to the antennae of the read/write head influences the detection range of the system. Make sure the antennae are aligned parallel to each other. Optimum alignment of the tag Good communication between the ■... -
Page 22: Polarization
IUH-F117-V1-* Installation During simultaneous operation of several read/write heads, only one read/write head may ever communicate with a tag at any given time. When arranging the read/write heads, make sure that the measurement ranges do not overlap. You can enlarge or reduce the size of the measurement range by changing the transmitting power. -
Page 23: Connection
IUH-F117-V1-* Installation Polarization plane Figure 5.2 Polarization plane IUH-F117-V1-* with linear polarization Connection Connect the read/write head to the IDENTControl control interface using a shielded connection cable (see chapter 4.7.2). Ensure that the shield fully encapsulates the connection cable to avoid EMC interference. (see chapter 5.5) Warning! Incorrect electrical connection Damage to the device or plant caused by incorrect electrical connection. -
Page 24: Emc Concept
IUH-F117-V1-* Installation EMC Concept The outstanding noise immunity of the IDENTControl against emission and immission is based on its consistent shielding design, which uses the principle of the Faraday cage. Interference is caught in the shield and safely diverted via the ground connections. -
Page 25: Commissioning
IUH-F117-V1-* Commissioning Commissioning Definitions 6.1.1 Display Angle brackets contain the abbreviated meaning of a command structure, e.g., <Data> The index or .xx denotes a hexadecimal number. denotes a value in the hexadecimal system, specified in ASCII ASCII characters. Example: 10 corresponds to A corresponds to 41 . -
Page 26: Device Settings
IUH-F117-V1-* Commissioning <SystemCode>: = U (for read/write head IUH*) <TagType>: 2 ASCII characters <UII/EPC>: Unique Item Identifier, memory area of a tag in accordance with EPC Gen 2 (ISO/IEC 18000-63), in which the EPC code is stored <WordAddr>: Word start address in the read/write tag, 4 hex characters, range ASCII from "0000h"... - Page 27 IUH-F117-V1-* Commissioning Example: In the examples below, the read/write head is connected to channel 1 of the control interface. Reading Tags Enhanced Read Read-Only Code Send the enhanced read read-only code command to the read/write head. The LEDs on the read/write head flash green. Serial Ethernet PROFIBUS...
- Page 28 IUH-F117-V1-* Commissioning Single Read Special Read-Only Code As confirmation, read out the read-only code of the tag within the read/write head's measurement range via the single read special read-only code command. see "Single Read Special Read-Only Code SS" on page 31. Serial Ethernet PROFIBUS...
-
Page 29: Operation
IUH-F117-V1-* Operation Operation General The sections below contain the details on the commands that specifically address the IUH-F117-V1-* read/write head. The commands are described using the example of an IDENTControl control interface with serial interface. All other generally applicable commands and error messages or status messages can be found in the manual for your IDENTControl control interface. -
Page 30: Command Overview
IUH-F117-V1-* Operation The reflections and the resulting inhomogeneity of the field strength depend on the frequency used. The absolute value of the field strength depends on the transmission power. Since the tags move in the measurement range of the read/write head, and the environment can change, it is advisable to repeat the commands at different transmission frequencies. -
Page 31: Read/Write Commands
IUH-F117-V1-* Operation Read/Write Commands Single Read Read-Only Code SF One attempt is made to read a read-only code (TID). The read-only code is 4, 8, or 12 bytes long, and comprises a 4-byte part number, which denotes the tag type, and optionally a tag with a unique serial number of 4 or 8 byte. Command: SF <ChanNo>... - Page 32 IUH-F117-V1-* Operation Enhanced Read Special Read-Only Code ES This command continuously attempts to read the UII segment from tags according to EPC Gen2 (ISO/IEC 18000-63). If the <SpecialFixcode> of a tag is read, this is reported once to the control interface. If there is no tag in the measurement range, or if the tag leaves the measurement range, a status 5 is reported to the control interface.
- Page 33 IUH-F117-V1-* Operation When using this command, make sure that the protocol control word contains the correct length of the following UII/EPC. If this is not executed correctly, the complete data is not output on the subsequent read operation because the command SS uses the length in the protocol control word for the output.
- Page 34 IUH-F117-V1-* Operation Example: SR1000101 reads a 4-byte word from memory address "0001." Note! The memory bank MB parameter defines the bank which this command accesses. . Enhanced Read Words ER Continuous attempts are made to read <WordNum> 32-bit words from the address <WordAddr>.
-
Page 35: Configuration Commands
IUH-F117-V1-* Operation Enhanced Write Words EW This command continuously attempts to write <WordNum> 32-bit words from the address <WordAddr>. If the command was executed successfully, a status 0 is reported to the control interface. If there is no tag in the measurement range, or if the tag leaves the measurement range, a status 5 is reported to the control interface. - Page 36 IUH-F117-V1-* Operation Note! The IUH-F117-V1-* read/write head uses only tag type 80. Tag Types UHF 868 MHz Chip Pepperl+ Fuchs UII / User desig- Bank data type Type Designation nation 00 [bit] [bit] Type Unique? [byte] NXP UCode-EPC- IUC72 32 + E2006003 Class 1 G2XM...
-
Page 37: Read And Write Parameters
IUH-F117-V1-* Operation 7.5.2 Read and Write Parameters With the read parameter (RP) and write parameter (WP) configuration commands, you can read/write the following parameters: Parameter is readable/writeable IUH-F117-V1- Abbre- viation Page See "Antenna Polarization AP" on page 38 Readable/writeable See "Transmission Power "Power Transmit" PT" on page 38 Readable/writeable See "Channel Dense Reader Mode CD (EU version Readable... -
Page 38: Parameters
Transmission Power "Power Transmit" PT This parameter sets the transmission power or reads out the set transmission power. The transmission power is stated in mW for the IUH-F117-V1-EU and IUH- F117-V1-CN read/write heads. The transmission power is stated in mW for the IUH-F117-V1-US read/write eirp head. - Page 39 IUH-F117-V1-* Operation Note! You can operate the IUH-F117-V1-* read/write head only with internally specified transmission power. For the software, you can enter any transmission power between 300 mW and 2000 mW or between 500 mW and 4000 mW eirp eirp using the command WP1UPT.00.02.xx.xx.
- Page 40 IUH-F117-V1-* Operation Number of Attempts "Tries Allowed" TA This parameter sets the permitted number of write or read attempts, or outputs the permitted number of attempts. ParamTyp: Default: TA = 2 Value range: 1 ... 255 Example: WP1UTA.00.01.01 permits precisely one attempt (= no repeats) WP1UTA.00.01.03 permits 3 attempts RP1UTA.00.00 outputs the permitted number of attempts If the permitted number of write or read attempts between the read/write head and...
-
Page 41: Error/Status Messages
IUH-F117-V1-* Operation Memory Module for Tag Accesses to the "Memory Bank" MB This parameter specifies the bank accessed by the read/write commands SR, ER, SW, and EW. ParamTyp: Default: MB = .03 = User Memory Value range: .00 = reserved (password area) .01 = UII/EPC .02 = TID .03 = User Memory... -
Page 42: Service And Maintenance
IUH-F117-V1-* Service and Maintenance Service and Maintenance The device is designed and constructed to function stable over long periods of time. For this reason, regular cleaning or maintenance is unnecessary. -
Page 43: Troubleshooting
IUH-F117-V1-* Troubleshooting Troubleshooting Problem Solution Interference from several Change the setting of the transmission channels ■ read/write heads in the local Reduce the transmission power ■ vicinity Status A message Check whether there are multiple tags in the ■ measurement range: Remove the tag from the measurement range by placing the tag in a sealed metal container Repeat the read or write operation... -
Page 44: Ascii Table
IUH-F117-V1-* ASCII table ASCII table ASCII ASCII ASCII ASCII Space " & < >... -
Page 45: Appendix
IUH-F117-V1-* Appendix Appendix 11.1 Dimensions 300.5 11.2 Technical Data General specifications Device IUH-F117-V1-EU IUH-F117-V1-US IUH-F117-V1-CN Operating frequency 865.1 ... 867.9 MHz 902 ... 928 MHz 920.5 ... 924.5 MHz Emitted power ERP 2 W EIRP 4 W ERP 2 W... -
Page 46: Measurement Range
IUH-F117-V1-* Appendix Standard conformity Electromagnetic EN 301489- EN 301489- compatibility 1 V1.9.2:2011 , 1 V1.9.2:2011 , EN 301489- EN 301489- 3 V1.4.1:2003 3 V1.4.1:2003 Safety EN 60950- EN 60950- 1:2006/A1:2010 1:2006/A1:2010 Protection degree EN 60529:2000 EN 60529:2000 EN 60529:2000 Standards EN 50364:2010 EN 50364:2010 Ambient conditions... - Page 47 IUH-F117-V1-* Appendix A list of all available documents is displayed. Measurements produced the following far field for the IUH-F117-V1-* read/write head. This diagram shows the detection range for horizontal polarization under ideal conditions. The detection range shown is an example and varies depending on the tag types.
- Page 48 The time required for this repeat is taken into account when calculating a maximum speed under real conditions. The maximum speed in this case is therefore 150 km/h. Please consult Pepperl+Fuchs for specific data on read and write times, as well as passing speeds.
