51GGTCM (W) 601GGDOTm (W) OPERATING AND INSTALLATION INSTRUCTIONS OF FREESTANDING GAS DOUBLE CAVITY...
Page 2
Dear Customer, Our goal is to offer you products with high quality that exceed your expectations. Your appliance is produced in modern facilities carefully and particularly tested for quality. This manual is prepared in order to help you use your appliance that is manufactured by the most recent technology, with confidence and maximum effciency.
CONTENTS: 1. Part : PRESENTATION AND SIZES OF PRODUCT 2. Part : WARNINGS 3. Part : INSTALLATION AND PREPARATIONS FOR USE 3.1 Environment where the appliance will be installed 3.2 Installation of oven 3.3 Adjustment of feet 3.4 Gas connection 3.5 Electric connection and security 3.6 General warnings and measures 3.7 Gas conversions...
1. Part : PRESENTATION AND SIZES OF PRODUCT PRESENTATION: 2. Rack 1. Rack 5. Rack 4. Rack 3. Rack 3. Ra 2. Rack 1. Rack List of Components: 1- Cooktop 2- Control Panel 3- Oven Door Handle 4- Supply Leg 5- Oven Door MODEL DEPTH WIDTH HEIGHT...
2. Part : WARNINGS TAKE ALL IMPORTANT SECURITY MEASURES AND READ THE MANUAL COMPLETELY BEFORE USING THE APPLIANCE This appliance has been designed for non-professional, domestic use only • When you unpack the appliance, make sure that it is not damaged during •...
Page 6
2. Part : WARNINGS ventilation device (mechanical extractor hood) Prolonged intensive use of the appliance may call for additional ventilation, for example opening of a window or more effective ventilation, for example increasing thelevel of mechanical ventilation where present. This manual is prepared for more than one model in common. Your •...
3. Part : INSTALLATION AND PREPARATIONS FOR USE This modern, functional and practical oven, that was manufactured with the parts and materials of highest quality, will meet your cooking needs in every aspect. You must surely read this manual so that you don't have any problem in future and to be able to have satisfactory results.
3. Part : INSTALLATION AND PREPARATIONS FOR USE access to fresh air. This electric fan must have the capacity to change the air of the kitchen environment 4-5 times of its own volume of air per hour. Cooker hood flue Electrical ventilator Air inlet section Air inlet section...
3. Part : INSTALLATION AND PREPARATIONS FOR USE • Pay attention not to place it near the refrigerator, there must be no flammable or inflammable materials such as curtain, waterproof cloth, etc. that will begin to burn quickly It is required that there must be least a 2cm blank space around the oven for •...
Page 10
3. Part : INSTALLATION AND PREPARATIONS FOR USE As gas is turned on, all connection parts and hose must be checked with soapy water or leakage fluids. Do not use naked flame to check gas leakage. All metal components used during gas connection must be clear of rust. Also check the expiry dates of components used.
Page 11
3. Part : INSTALLATION AND PREPARATIONS FOR USE 3.5. Electrical connection For your safety please read the following information. WARNING: This appliance must be earthed. • The appliance must be connected to a 240 volts 50 Hz AC supply by means of a three pin socket, suitably earthed and should be protected by a 3 amp fuse in the plug.
3. Part : INSTALLATION AND PREPARATIONS FOR USE 3.6 General warnings and measures Your appliance is produced in accordance with the local and international • standards and regulations applicable. The maintenance and repair works must be made only by authorized service •...
3. Part : INSTALLATION AND PREPARATIONS FOR USE Gas conversion Caution : The following procedures must be undertaken by authorized service people. Your appliance is adjusted to be operated with LPG/NG gas. The gas burners can be adapted to different types of gas, by replacing the corresponding injectors and adjusting minimum flame length suitable to the gas in use.
Page 14
3. Part : INSTALLATION AND PREPARATIONS FOR USE Screw Figure 11 Figure 10 Oven Injector: The oven burner is fixed in its cradle by a single clip that is placed on the left- hand side of the burner. Pull the clip (Figure 12) further left, and with your other hand, lift the burner up holding from the thermocouple/spark plug holder.
Page 15
3. Part : INSTALLATION AND PREPARATIONS FOR USE Adjusting The Reduced Flame Position The flame length in the minimum position is adjusted with a flat screw located on the valve. For valves with FFD, the screw is located on the side of the valve spindle.
4. Part : USE OF YOUR OVEN 4.1 Use of gas burners Ignition of the burners To determine which knob controls which burner, check the position symbol above the knob. Manual Ignition of the Gas Burners • If your appliance is not equipped with any ignition aid or in case there is a failure in the electricity network, follow the procedures listed below For Hob Burners: To ignite one of the burners, press and turn its knob counter-clockwise so that the knob is in max.
4. Part : USE OF YOUR OVEN burner. Continue pressing the knob until you see a stable flame on the burner. Flame safety device: Hob Burners Hobs equipped with flame failure device provide security in case of accidentally extinguished flame. If such a case occurs, the device will block the burners gas channels and will avoid any accumulation of unburned gas.
4. Part : USE OF YOUR OVEN Rapid Burner: 22-26cm Medium Burner: 14-22cm Auxiliary Burner: 12-18cm Make sure that the tips of the flames do not spread out of the outer circumference of the pan, as this may also harm the plastic accessories around the pan (handles etc.) Figure 14 When the burners are not in use for prolonged periods, always turn the main...
Page 19
4. Part : USE OF YOUR OVEN Preheating When you need to preheat the oven, we recommend you do so for 10 minutes. For recipes needing high temperatures, e.g. bread, pastries, scones, soufflés etc., best results are achieved if the oven is preheated first. For best results when cooking frozen or cooked chilled ready meals always preheat the oven first.
4. Part : USE OF YOUR OVEN MAIN OVEN (51EETCM(W)) MARK TEMPERATURE( C) These temperature settings may change slightly when both top and main ovens are operated together. 4.1.3 Control of the grill burner The grill burner can be operated with the oven door in two positions regarding your choice: completely open or partially open (30°...
4. Part : USE OF YOUR OVEN 4.1.4 Using the Digital Minute Timer Simultaneously press (+) and (-) buttons of the digital timer. The display will start flashing, and then you can set the time by using (+) and (-) buttons. When you press (+) or (-) buttons after setting the time ( ) symbol is displayed, and the desired time is set.
4. Part : USE OF YOUR OVEN 4.2 Accessories used in oven The oven already supplied with accessories. You can also use accessories you • purchase from the market, but they must be heat and flame resistant. You can also use glass dishes, cake molds, special oven trays that are appropriate for use in oven.
Page 23
4. Part : USE OF YOUR OVEN Removal of catalitic panel (601GGDOTm(W)) Remove G screws on the each catalitic enamel coated panel. Figure 15...
5. Part : CLEANING AND MAINTENANCE 5.1 Cleaning Be sure that all control switches are off and your appliance cooled before cleaning your oven. Plug off the appliance. Check whether they are appropriate and recommended by the manufacturer before using the cleaning materials on your oven.
5. Part : CLEANING AND MAINTENANCE Burner Caps: Periodically, enameled pan support, enameled covers, burner heads must be washed with soapy warm water rinsed and dried. After drying them thoroughly, replace them correctly. Enamelled Parts: In order to keep them a new, it is necessary to clean them frequently with mild warm soapy water and then dry with cloth.
6. Part : SERVICE AND TRANSPORT 6.1 Basic troubleshooting before contacting service If the oven does not operate : The oven may be plugged off, there has been a black out. • If the oven does not heat : The heat may be not adjusted with oven's heater control switch. •...
Page 28
Service Help Line For the UK: please call 0844 815 8880 For Ireland: please call 0818 46 46 46 The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment.
